Dish Network 622 guide Manual

622

SETUP

INSTRUCTIONS

• If you are not seeing the screens listed in this guide, try changing your TV’s

input by pressing the “Source/Input” button on your TV.

• In step 7, your replacement receiver will test your Internet and phone

connection. If the results display as “not available,” ensure the cords are

connected to the appropriate ports on the back of your receiver and to your

phone/modem.

• To ﬁnd your closest UPS dropo location or to schedule a pickup at your cost,

call 1-800-742-5877 or visit ups.com/dropo.

Do you have questions?

Take a look at the back cover of this guide for this contact information!

Disconnect Your Cables and Remote

Antenna

Locate the power cable for the

receiver that you are replacing,

and unplug it from the wall.

Locate the antenna connected

to the “Remote Antenna” port.

Then unscrew the antenna

from the receiver.

Locate the cable(s) connected

to the “Satellite In” ports, and

then unscrew the cable(s) from

the receiver. Do not unscrew the

cable(s) from the wall.

Ethernet

Locate the cable connected to the “Ethernet” port. Then,

unplug the cable from the receiver. Do not unplug it from

the wall. (You may not have this cable.)

PHONE

Locate the cable connected to

the “Phone” port. Then unplug the

cable from the receiver. Do not

unplug it from the wall. (You may

not have this cable.)

Disconnect Your Cables and Remote

Antenna

HDMI 1

Determine the cable you are

using to receive audio/visual

signal. Then unplug it from the

receiver, but not from your TV.

AUDIO

VIDEO

HDMI CABLE RCA CABLES

Connect the Satellite In cable(s)

to the “Satellite In” port(s) on

your replacement receiver.

Connect the remote antenna to

the “Remote Antenna” port on

your replacement receiver.

Connect Your Cables and Remote

Antenna

Ethernet

Connect the Ethernet cable to the “Ethernet” port

on your replacement receiver. (You may not have

this cable.)

PHONE

Connect the Phone cable

to the “Phone” port on your

replacement receiver. (You may

not have this cable.)

Connect either the RCA cables

or the HDMI cable to the

corresponding port(s) on your

replacement receiver.

Connect Your Cables and Remote

Antenna

HDMI 1

AUDIO

VIDEO

HDMI CABLE RCA CABLES

Power Your Equipment

Plug the power cord from your

receiver into a power outlet,

and ensure that your TV is still

plugged in. Turn on your TV. It

could take up to 30 seconds for

you to see any images.

Make sure that the SmartCard is

secured ﬁrmly in the slot on the

front of your receiver.

Program Your Remote

If you are using a second TV with this

receiver, repeat to program the remote

that has the blue number 2 identiﬁer

at the bottom. Once complete, use the

arrow buttons on your remote to highlight

“Continue,” and then press Select.

Your screen should now display the Program

TV1 Remote to Receiver screen. Follow the

onscreen instructions to program your remote

that has a green number 1 identiﬁer at the

bottom to the replacement receiver. Once your

remote is programmed, use the arrow buttons

on your remote to highlight “Continue,” and then

press Select.

Download Receiver Software

Your receiver will start downloading

software automatically.

Once the software download is

complete, your receiver will update

automatically.

Set Your TV Conﬁguration

If you have a second TV, see what channel it

is currently tuned to by using the TV’s remote

or the buttons on the TV itself to channel

up and then channel back down. Select the

appropriate channel onscreen according to

what channel your TV is tuned to, and then

select “Continue.”

Follow the onscreen instructions to

set your TV’s video resolution so

the picture will display properly.

Once your TV resolution is set, use

the arrow buttons on your remote

to select “Save,” and then press

Select.
