2211994444

➤

OOwwnneerr’’ss//IInnssttaallllaattiioonnGGuuiiddee

G21994_04-06.qxd 12/11/06 3:36 PM Page 1

G21994_04-06.qxd 12/11/06 3:36 PM Page 2

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics (hereinafter "Directed") promises to the original purchaser to repair

or replace with a comparable reconditioned Directed DIY keyless entry unit if this

Directed DIY keyless entry unit (hereinafter "Unit"), excluding without limitation, any

remote transmitters or associated accessories, proves defective in materials or workman-

ship under normal use for the life of the vehicle which the Unit is originally installed.

During this period, so long as the Unit remained installed in the original vehicle, Directed

will at its option, repair or replace this Unit if it is proved defective in workmanship or

material PROVIDED the Unit is returned to Directed's warranty department at One

Viper Way, Vista, CA 92081, along with $20 postage and handling fee, a bill of sale or

other dated proof of purchase bearing the following information: Date of purchase, name

and location of the merchant who sold the Unit, and product description. This warranty

does not cover labor costs for the removal or reinstallation of the Unit. This warranty is

non-transferable and does not apply to any Unit that has been modified or used in a man-

ner contrary to its intended purpose, and this warranty does not cover damage to any Unit

caused by installation or removal of the Unit. This warranty is void if the Unit has been

damaged by accident or unreasonable use, neglect, improper service or other causes not

arising out of defects in materials or workmanship. Directed makes no warranty against

theft of a vehicle or its contents.

THE FOREGOING WARRANTY IS THE EXCLUSIVE PRODUCT WARRANTY,

OTHERWISE, ALL WARRANTIES INCLUDING BUT NOT LIMITED TO

EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MER-

CHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY

EXCLUDED AND DISCLAIMED TO THE MAXIMUM EXTENT ALLOWED BY

LAW, AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON

TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE OF

THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY

AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-

ERS OR INSTALLERS. SOME STATES DO NOT ALLOW THE LIMITATION ON

HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION

MAY NOT APPLY TO YOU.

LIMITATION OF DAMAGES AND LIABILITY. CONSUMER'S REMEDY IS LIM-

ITED TO REPAIR OR REPLACEMENT OF THE UNIT, AND IN NO EVENT

SHALL DIRECTED'S LIABILITY EXCEED THE PURCHASE PRICE OF THE

UNIT. IN ANY EVENT, DIRECTED SHALL NOT BE LIABLE FOR ANY DAM-

AGES INCLUDING, BUT NOT LIMITED TO, ANY DIRECT, INDIRECT, INCI-

DENTAL, SPECIAL, PUNITIVE OR CONSEQUENTIAL DAMAGES, LOST

PROFITS, LOST SAVINGS, OR, TO THE EXTENT ALLOWED BY APPLICABLE

LAW, DAMAGES RESULTING FROM DEATH OR INJURY ARISING OUT OF

G21994_04-06.qxd 12/11/06 3:36 PM Page i

OR IN CONNECTION WITH THE INSTALLATION, USE, IMPROPER USE, OR

INABILITY TO USE, THE PRODUCT, EVEN IF THE PARTY HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME STATES DO

NOT ALLOW THE EXCLUSION OF LIMITATION OF INCIDENTAL OR CON-

SEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSION

MAY NOT APPLY TO YOU. THE CONSUMER AGREES AND CONSENTS THAT

ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE

RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO

COUNTY, CALIFORNIA.

IIMMPPOORRTTAANNTTNNOOTTEE::

This product warranty is automatically void if its date code or serial number is defaced,

missing, or altered. This warranty will not be valid unless you have completed the war-

ranty card and mailed it to Directed Electronics. within 10 days after purchase to the

address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Authorized dealer's company name and address

➤Item number

G21994_04-06.qxd 12/11/06 3:36 PM Page ii

ttaabblleeooffccoonntteennttss

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy................................................................................ii

wwhhaattiissiinncclluuddeedd.....................................................................

.......................................22

iinnssttaallllaattiioonnttoooollss.........................................

...................................................................22

iimmppoorrttaannttiinnffoorrmmaattiioonn..........

........................................................................................33

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

pprriimmaarryy

hhaarrnneessss((HH11)),,1144--ppiinnccoonnnneeccttoorr......................................................................

..55

uussiinnggLLEEDDtteessttpprroobbee............................................................................

........................66

iinnssttaallllaattiioonn..............................................................

........................................................77

wwiirriinnggqquuiicckkrreeffeerreenncceegguuiiddee..............

............................................................................88

step 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

step 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

step 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

step 4 (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

step 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

step 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

step 7 (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

step 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

step 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

step 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

ttrraannssmmiitttteerrffuunnccttiioon

nss...................................................................................................

.3344

standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

ccoonnttrroollmmoodduulleepprrooggrraammmmiinngg.....................................................................

.................3355

uussiinnggyyoouurrssyysstteemm...............................................................

.........................................3366

locking with transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

unlocking with transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

ignition-controlled door locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

ccooddeehhooppppiinngg®®rree--ssyynncchhrroonniizzee.........................

...........................................................3377

ssyysstteemmeexxppaannssiioonniitteemmss................

................................................................................3377

eemmeerrggeennccyyoovveerrrriiddeepprroocceedduurree......................................................................................3388

glloossssaarryyoofftteerrmmss..........................................................................................................3388

nnootteess......................................................................

......................................................3399

qquuiicckkrreeffeerreenncceegguuiiddee::.....................

.............................................................................4411

G21994_04-06.qxd 12/11/06 3:36 PM Page 1

wwhhaattiissiinncclluuddeedd

➤Control Module

➤One Pre-Programmed 4-Button Transmitter

➤14-Pin H1 Main Harness

➤10 feet of Black Electrical Tape

➤6 Six inch Zip Ties

➤LED Tester

➤Razor Knife

iinnssttaallllaattiioonnttoooollss

➤Digital Multi-Meter

➤Drill

➤Screwdrivers

(Phillips and Flathead)

➤Wire Stripper

➤Solder Iron

➤Pliers

➤Crimping Tool

note: The installation tools listed above may be optional

and those required will vary depending on your vehicle.

G21994_04-06.qxd 12/11/06 3:36 PM Page 2

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your keyless entry system.

This system will allow convenient access to your vehicle with the

push of a button, as well as other optional features. Properly

installed, this system will provide years of trouble-free operation.

Please take the time to carefully read this Owner’s/Install Guide

in its entirety prior to installing your system.

You can print additional or replacement copies of this manual by

accessing the Directed web site at www.readyremote.com.

system maintenance

The system requires no specific maintenance. Your transmitter is

last approximately one year under normal use. When the battery

begins to weaken, the operating range will be reduced.

➜

important! If you are not comfortable working with elec-

tronics or unfamiliar with the tools required, please con-

tact your local dealer for advice or ask to have the system

professionally installed to avoid costly damages. Failure

to properly install the system may result in property dam-

age, personal injury, or both.

G21994_04-06.qxd 12/11/06 3:36 PM Page 3

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesirable operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

G21994_04-06.qxd 12/11/06 3:36 PM Page 4

pprriimmaarryyhhaarrnneessss((HH11)),,

1144--ppiinnccoonnnneeccttoorr

note: H1/1 LIGHT GREEN/BLACK

use if the vehi-

cle is equipped with a factory alarm disarm.

note: H1/5 VIOLET/BLACK is connected to H1/2

VIOLET and is fused (15A).

HH11//11

HH11//22

HH11//33

HH11//44

HH11//55

HH11//66

HH11//77

HH11//88

HH11//99

HH11//1100

HH11//1111

HH11//1122

HH11//1133

HH11//1144

LIGHT GREEN/BLACK Factory Alarm Disarm

BROWN/BLACK Unlock 87A Normally Closed

VIOLET Unlock 87 Normally Open

BLUE/BLACK Unlock 30 Common-Output

GREEN/BLACK Lock 30 Common-Output

WHITE/BLACK Lock 87A Normally Closed

ORANGE (-) 500 mA Ground-When-Armed Output

WHITE (-) Parking Light Flash Output

BLACK (-) Chassis Ground Input

Empty

YELLOW (+) Ignition Input

RED (+) 12V Constant Power Input

RED/WHITE (-) 200mA Auxiliary Output

VIOLET/BLACK Lock 87 Normally Open-Input

G21994_04-06.qxd 12/11/06 3:36 PM Page 5

uussiinnggLLEEDDtteessttpprroobbee

To use the LED test probe:

1. Remove the protective cover off the probe tip. Save the

protective cover for reinstallation on the probe tip when

the LED tester is not being used.

2. Connect the Black clip to a good chassis ground.

3. Connect the Red clip to a good +12V source. Both the

Red and Green LEDs should be illuminated dimly.

4. If a positive voltage source is probed, the Red LED will

illuminate brightly, and the Green LED will extinguish.

5. If a negative source is probed the Green LED will illu-

minate brightly and the Red LED will extinguish.

Alternate procedure to use the LED test probe (only for use on

probing positive voltage wires):

1. Remove the protective cover off the probe tip. Save the

protective cover for reinstallation on the probe tip when

the LED tester is not being used.

2. Connect the Black clip to a good chassis ground.

3. If a positive voltage source is probed, the Red LED will

illuminate brightly.

warning! Do not use this test probe on

computerized equipment as damage

can result.

G21994_04-06.qxd 12/11/06 3:36 PM Page 6

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Arranque remoto de Directed Electronics

Directed Electronics

Directed Electronics READY REMOTE 24927 Guía de inicio rápido

Directed Electronics

Directed Electronics Failsafe 103T Manual de usuario

Directed Electronics

Directed Electronics Viper 5501 Manual de usuario

Directed Electronics

Directed Electronics ONE-WAY FM AUTOMATIC/MANUAL TRANSMISSION Manual de usuario

Directed Electronics

Directed Electronics AS-1775 Manual de usuario

Directed Electronics

Directed Electronics 4103 Series Manual de usuario

Directed Electronics

Directed Electronics Ready Remote 23926 Manual de usuario

Directed Electronics

Directed Electronics SmartStart 5000-series Manual de usuario

Directed Electronics

Directed Electronics SMARTSTART VSM200 Manual de usuario

Directed Electronics

Directed Electronics Valet 712T Manual de usuario

Directed Electronics

Directed Electronics AS-2371TW-FM Manual de usuario

Directed Electronics

Directed Electronics Xpresskit CANMAX400 Manual de usuario

Directed Electronics

Directed Electronics 335912 359D Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 25622 Guía de inicio rápido

Directed Electronics

Directed Electronics 20.7 Manual de usuario

Directed Electronics

Directed Electronics 50.7X Manual de usuario

Directed Electronics

Directed Electronics Automate 552 Manual de usuario

Directed Electronics

Directed Electronics READY REMOTE 24923 Manual de usuario

Directed Electronics

Directed Electronics Python 951 Manual de usuario

Directed Electronics

Directed Electronics SmartStart 5000-series Manual de usuario

Directed Electronics

Directed Electronics Python G4203P Manual de usuario

Directed Electronics

Directed Electronics PS-4461TWE-FM Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 28624TN Guía de inicio rápido

Directed Electronics

Directed Electronics 5301 Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Code Alarm

Code Alarm CA-535 Manual de usuario

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual
