Directed Electronics Valet 562T Manual de usuario

MMooddeell556622TT

OOwwnneerr''ssGGuuiiddee

LLiimmiitteeddLLiiffeettiimmee

CCoonnssuummeerrWWaarrrraannttyy

For a period of one calendar year from the date of purchase of this auto-security

device, Directed Electronics promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model), free of cost, any electronic control module

which proves to be defective in workmanship or material under normal use, SO LONG

AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO

INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY

INSTALLED. If warranty service is necessary you must have a clear copy of your sales

receipt containing all of the information shown on the following page.

After the first calendar year, from the date of purchase of this auto-security device,

Directed Electronics, promises to the ORIGINAL PURCHASER to repair or replace (with

a comparable reconditioned model) any electronic control module which proves to be

defective in workmanship or material under normal use FFOORRAACCHHAARRGGEEOOFF$$4455..0000,,SO

LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL AUTO

INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY

INSTALLED. If warranty service is necessary you must have a clear copy of your sales

receipt containing all of the information shown on the following page.

This warranty contains the entire agreement relating to warranty and supersedes all

previous and contemporaneous representations or understandings, whether written or

oral. IN ANY EVENT, DIRECTED ELECTRONICS IS NOT LIABLE FOR THE THEFT OF THE

VEHICLE AND/OR ITS CONTENTS.

This warranty is void if the product has been damaged by accident, unreasonable use,

neglect, improper service or other causes not arising out of defects in materials or

construction. This warranty is nontransferable and does not apply to any unit that

has been modified or used in a manner contrary to its intended purpose and does not

cover batteries. The unit in question must be returned to the manufacturer, postage

prepaid. This warranty does not cover labor costs for the removal, diagnosis, trou-

bleshooting or reinstallation of the unit. For service on an out-of-warranty product a

flat rate fee by model is charged. Contact your authorized dealer to obtain the ser-

vice charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics is not offer-

ing a guarantee or insuring against the theft of the automobile or its contents and

disclaims any liability for the theft of the vehicle and/or its contents. Directed

Electronics does not authorize any person to create for it any other obligation or lia-

bility in connection with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD-

ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM-

MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU-

SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-

RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF

NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR

ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH

SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT

NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,

REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE

ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR

THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

IIMMPPOORRTTAANNTTNNOOTTEE::

This product warranty is automatically void if its date code or serial number is

defaced, missing, or altered. This warranty will not be valid unless you have com-

pleted the warranty card and mailed it to Directed Electronics within 10 days after

purchase to the address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of system installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

TTaabblleeooffCCoonntteennttss

LLiimmiitteeddLLiiffeettiimmeeCCoonnssuummeerrWWaarrrraannttyy..............................................................ii

SStta

annddaarrddCCoonnffiigguurraattiioonn..............................................................................22

WWhhaattiissIInncclluuddeedd......................................................................................33

IImmppoorrttaannttIInnffoorrmmaattiioonn.............................................................................

.33

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Your Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FCC/ID Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TTrraannssmmiitttteerrFFuunnccttiioonnss...............................................................................

.55

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

UUssiinnggYYoouurrSSyysstteemm....................................................................................

Warning! Safety First. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Disabling the Starter Kill Without a Transmitter. . . . . . . . . . . . . . . . . . . . . . . 10

Valet Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Remote Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Rear Defogger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Valet Take-Over. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Short-Run/Turbo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Starter Anti-Grind Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Disabling the Remote Start System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

RRaappiiddRReessuummeeLLooggiicc..................................................................................1188

PPrrooggrraammmmiinnggOOppttiioonnss..............................................................................

..1188

GGlloossssaarryyooffTTeerrmmss..............................................................................

......2200

CCoonnvveenniieenncceeEExxppaannssiioonnss.....................................................................

.......2211

NNootteess.....................................................................................

...............2233

QQuuiicckkRReeffeerreenncceeGGuuiiddee.............................................................

.................2255

SSttaannddaarrddCCoonnffiigguurraattiioonn

controls the AArrmm//PPaanniiccOONN//PPaanniiccOOFFFFfunction.

controls the DDiissaarrmmfunction.

controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt.

controls RReemmootteeSSttaarrtt.

+controls TTiimmeerrmode.

+controls TTuurrbboo//SShhoorrttRRuunn.

+controls CChhaannnneell44output.

++ controls RReeaarrDDeeffrroosstteerr.

WWhhaattiissIInncclluuddeedd

■The control module

■An HX receiver/antenna

■Two four-button transmitters

■The red status LED indicator light

■A push-button Valet button

■Your warranty registration

■A shut-down toggle switch

IImmppoorrttaannttIInnffoorrmmaattiioonn

Congratulations on the purchase of your remote start keyless entry

system. Due to the complexity of this system, it must be installed

by an authorized dealer only. Installation of this product by any-

one other than an authorized dealer voids the warranty. All deal-

ers are provided with a preprinted dealer certificate to verify that

they are authorized.

By carefully reading this Owner's Guide prior to using your system,

you will maximize the use of this system and its features.

You can print additional or replacement copies of this manual by

accessing the Directed Electronics internet website at

www.directed.com

The system requires no specific maintenance. Your remote is powered

by a small, lightweight 3-volt lithium battery that will last approx-

imately one year under normal use. When the battery begins to weaken,

operating range will be reduced and the LED on the remote will dim.

Your warranty registration must be completely filled out and

returned within 10 days of purchase. Your product warranty

will not be validated if your warranty registration is not returned.

Make sure you receive the warranty registration from your dealer.

It is also necessary to keep your proof of purchase, which reflects

that the product was installed by an authorized dealer.

This device complies with Part 15 of FCC rules. Operation is subject

to the following conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference re-

ceived, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user's authority to operate this device.

This product is designed for fuel injected, automatic transmission

vehicles only. Use of this product in a standard transmission vehi-

cle is dangerous and contrary to the product's intended use.

CCaauuttiioonn

FFCCCC//IIDDNNoottiiccee

YYoouurrWWaarrrraannttyy

SSyysstteemmMMaaiinntteennaannccee

TTrraannssmmiitttteerrFFuunnccttiioonnss

The receiver uses a computer-based learn routine to learn the

transmitter buttons. This makes it possible to assign any specific

transmitter button, or combination of buttons, to any receiver

function. The transmitter initially comes programmed with the

Standard Configuration, but may also be customized by an autho-

rized dealer. The transmitter buttons indicated in all of the

instructions in this manual correspond to a Standard Configuration

transmitter.

BBuuttttoonn

The arming and panic functions are controlled by pressing on

the transmitter for one second.

BBuuttttoonn

The disarm function is controlled by pressing on the trans-

mitter for one second.

BBuuttttoonn

Silent Mode™and an optional auxiliary function are controlled

by pressing . Silent Mode works by pressing for less

than one second. An optional auxiliary function, such as

trunk release, is controlled by pressing and holding for

1.5 seconds.

SSttaannddaarrddCCoonnffiigguurraattiioonn

BBuuttttoonn

The remote start function of your system is controlled by pressing

this button twice within 3 seconds.

and Buttons

An optional auxiliary convenience or expansion function that you

have added to your system can be activated by pressing these but-

tons simultaneously.

The auxiliary output controls __________________________.

BBuuttttoonnss++

When simultaneously pressed these buttons control the rear win-

dow defogger during remote starting.

UUssiinnggYYoouurrSSyysstteemm

The following safety warnings must be observed at all times:

■Due to the complexity of this system, installation of this

product must only be performed by an authorized Directed

Electronics dealer.

■When properly installed, this system can start the vehicle via

a command signal from the remote control transmitter.

Therefore, never operate the system in an enclosed area or

WWaarrnniinngg!!SSaaffeettyyFFiirrsstt

partially enclosed area without ventilation (such as a garage).

When parking in an enclosed or partially enclosed area or

when having the vehicle serviced, the remote start system

must be disabled using the installed toggle switch. It is the

user's sole responsibility to properly handle and keep out of

reach from children all remote control transmitters to assure that

the system does not unintentionally remote start the vehicle.

TTHHEEUUSSEERRMMUUSSTTIINNSSTTAALLLLAACCAARRBBOONNMMOONNOOXXIIDDEEDDEETTEECCTTOORRIINN

OORRAABBOOUUTTTTHHEELLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOOTTHHEEVVEEHHIIC

CLLEE..AALLLL

DDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTTLLIIVVIINNGGAARREEAASSTTOOTTHHEE

EENNCCLLOOSSEEDDOORRPPAARRTTIIAALLLLYYEENNCCLLOOSSEEDDVVEEHHIICCLLEESSTTOORRA

AGGEEAARREEAA

MMUUSSTTAATTAALLLLTTIIMMEESSRREEMMAAIINNCCLLOOSSEEDD..These precautions are

the sole responsibility of the user.

■Use of this product in a manner contrary to its intended mode

of operation may result in property damage, personal injury,

or death. (1) Never remotely start the vehicle with the vehi-

cle in gear, and (2) Never remotely start the vehicle with the

keys in the ignition. The user must also have the neutral safe-

ty feature of the vehicle periodically checked, wherein the

vehicle must not remotely start while the car is in gear. This

testing should be performed by an authorized Directed

Electronics dealer in accordance with the Safety Check out-

lined in the product installation guide. If the vehicle starts in

gear, cease remote start operation immediately and consult

with the authorized Directed Electronics dealer to fix the

problem.

■After the remote start module has been installed, contact your

authorized dealer to have him or her test the remote start

Otros manuales para Valet 562T

Tabla de contenidos

Otros manuales de Arranque remoto de Directed Electronics

Directed Electronics

Directed Electronics Clifford G4203X Manual de usuario

Directed Electronics

Directed Electronics SmartStart 5000-series Manual de usuario

Directed Electronics

Directed Electronics ProStart CT-5472TW Manual de usuario

Directed Electronics

Directed Electronics READY REMOTE 24926 Guía de inicio rápido

Directed Electronics

Directed Electronics AutoCommand 40027 Manual de usuario

Directed Electronics

Directed Electronics 3000 Manual de usuario

Directed Electronics

Directed Electronics 440HP Manual de usuario

Directed Electronics

Directed Electronics 3000 Manual de usuario

Directed Electronics

Directed Electronics Viper 7652V Manual de usuario

Directed Electronics

Directed Electronics AS-1271 Manual de usuario

Directed Electronics

Directed Electronics Avital 4113 Manual de usuario

Directed Electronics

Directed Electronics 335912 359D Manual de usuario

Directed Electronics

Directed Electronics CT-3271 Manual de usuario

Directed Electronics

Directed Electronics CLIFFORD 1.3X Manual de usuario

Directed Electronics

Directed Electronics Python 951 Manual de usuario

Directed Electronics

Directed Electronics ProSecurity RK20 Manual de usuario

Directed Electronics

Directed Electronics Smart start Manual de usuario

Directed Electronics

Directed Electronics Viper Manual de usuario

Directed Electronics

Directed Electronics Nissan Guía de inicio rápido

Directed Electronics

Directed Electronics READY REMOTE 24921 Manual de usuario

Directed Electronics

Directed Electronics Xpresskit Xpressparts Series Manual de usuario

Directed Electronics

Directed Electronics READY REMOTE 24927 Guía de inicio rápido

Directed Electronics

Directed Electronics AutoCommand 28623TN Guía de inicio rápido

Directed Electronics

Directed Electronics AutoCommand 40026 Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Code Alarm

Code Alarm CA-535 Manual de usuario

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual
