MMooddeell4411002277,,4411002277TT

➤

OOwwnneerr’’ss//IInnssttaallllaattiioonnGGuuiiddee

Professional Series

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics (hereinafter "Directed") promises to the original purchaser to repair

or replace with a comparable reconditioned Directed DIY remote start unit if this

Directed DIY remote start unit (hereinafter "Unit"), excluding without limitation, any

remote transmitters or associated accessories, proves defective in materials or workman-

ship under normal use for the life of the vehicle which the Unit is originally installed.

During this period, so long as the Unit remained installed in the original vehicle, Directed

will at its option, repair or replace this Unit if it is proved defective in workmanship or

material PROVIDED the Unit is returned to Directed's warranty department at One

Viper Way, Vista, CA 92081, along with $20 postage and handling fee, a bill of sale or

other dated proof of purchase bearing the following information: Date of purchase, name

and location of the merchant who sold the Unit, and product description. This warranty

does not cover labor costs for the removal or reinstallation of the Unit. This warranty is

non-transferable and does not apply to any Unit that has been modified or used in a man-

ner contrary to its intended purpose, and this warranty does not cover damage to any Unit

caused by installation or removal of the Unit. This warranty is void if the Unit has been

damaged by accident or unreasonable use, neglect, improper service or other causes not

arising out of defects in materials or workmanship. Directed makes no warranty against

theft of a vehicle or its contents.

THE FOREGOING WARRANTY IS THE EXCLUSIVE PRODUCT WARRANTY,

OTHERWISE, ALL WARRANTIES INCLUDING BUT NOT LIMITED TO

EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MER-

CHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY

EXCLUDED AND DISCLAIMED TO THE MAXIMUM EXTENT ALLOWED BY

LAW, AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON

TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE OF

THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY

AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-

ERS OR INSTALLERS. SOME STATES DO NOT ALLOW THE LIMITATION ON

HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION

MAY NOT APPLY TO YOU.

LIMITATION OF DAMAGES AND LIABILITY. CONSUMER'S REMEDY IS LIM-

ITED TO REPAIR OR REPLACEMENT OF THE UNIT, AND IN NO EVENT

SHALL DIRECTED'S LIABILITY EXCEED THE PURCHASE PRICE OF THE

UNIT. IN ANY EVENT, DIRECTED SHALL NOT BE LIABLE FOR ANY DAM-

AGES INCLUDING, BUT NOT LIMITED TO, ANY DIRECT, INDIRECT, INCI-

DENTAL, SPECIAL, PUNITIVE OR CONSEQUENTIAL DAMAGES, LOST

PROFITS, LOST SAVINGS, OR, TO THE EXTENT ALLOWED BY APPLICABLE

LAW, DAMAGES RESULTING FROM DEATH OR INJURY ARISING OUT OF

OR IN CONNECTION WITH THE INSTALLATION, USE, IMPROPER USE, OR

INABILITY TO USE, THE PRODUCT, EVEN IF THE PARTY HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME STATES DO

NOT ALLOW THE EXCLUSION OF LIMITATION OF INCIDENTAL OR CON-

SEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSION

MAY NOT APPLY TO YOU. THE CONSUMER AGREES AND CONSENTS THAT

ALL DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE

RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO

COUNTY, CALIFORNIA.

IIMMPPOORRTTAANNTTNNOOTTEE::

This product warranty is automatically void if its date code or serial number is defaced,

missing, or altered.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Authorized dealer's company name and address

➤Item number

ttaabblleeooffccoonntteennttss

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy................................................................................ii

IInnssttaallllGGuuiiddee........................................................................

........................................33

what is included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

installation tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

WWiirriinnggQQuuiicckkRReeffeerreenncceeGGuuiiddee..........................

..........................................................77

H1 Harness - 6 pin connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

H2 Harness - 8 pin connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

H3 harness - 3 pin connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

relay heavy gauge wires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Step 1, Heavy Gauge Wire Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Step 2, H1, Main Harness Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Step 3, H3 Door Lock Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Step 4, H2 Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Step 5, Mounting the Receiver/Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Step 6, Immobilizer Bypass Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Step 7, Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

System Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Remote Start Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Testing the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

OOwwnneerr’’ssGGuuiiddee.........................

.................................................................................5588

Transmitter Button Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Remote Start Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Alarm and Security Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Convenience Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Glossary of terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

NNootteess.........

.................................................................................................................7744

qquuiicckkrreeffeerreenncceegguuiiddee::..............................................................

..................................7755

Install Guide

what is included

Control Module

6-Pin Main H1 Harness

8-Pin H2 Secondary Harness

Heavy Gauge Wires

Antenna and cable

5-button remote(s)

Crash code card

3-pin Keyless Entry harness

Combination Momentary Switch and LED

Hood Pin Switch

Hardware Kit

Additional parts may be required (such as relays or bypass).

installation tools

Digital Multi-Meter

Drill

1/4Drill Bit (for hood pin switch)

Screwdrivers (Phillips and Flathead)

Wire Stripper

Solder Iron

Electrical Tape

Pliers

Crimping Tool

note: The installation tools listed above may be

optional and those required will vary depending on

your vehicle.

important information

Congratulations on the purchase of your remote start keyless entry

system. This system will allow convenient access to your vehicle

with the push of a button, as well as remote start and other

optional features. Properly installed, this system will provide years

of trouble-free operation.

Please take the time to carefully read this User’s Guide in its

entirety prior to installing your system.

You can print additional or replacement copies of this manual

by accessing the Directed web site at

www.autocommand.com.

system maintenance

The system requires no specific maintenance. Your transmitter

is powered by a miniature 12-volt battery (type 23A) that will

last approximately one year under normal use. When the

battery begins to weaken, the operating range will be

reduced.

➜

important! If you are not comfortable working with

electronics or unfamiliar with the tools required,

please contact your local dealer for advice or ask to

have the remote start professionally installed to avoid

costly damages. Failure to properly install the remote

starter may result in property damage, personal injury,

or both.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following conditions: (1) This device may not

cause harmful interference, and (2) This device must accept

any interference received, including interference that may

cause undesirable operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

warning! safety first

The following safety warnings must be observed at all times:

When properly installed, this system can start the vehicle

via a command signal from the remote control trans-

mitter. Therefore, never operate the system in an area

that does not have adequate ventilation. The following

precautions are the sole responsibility of the user;

however, the following recommendations should be made

to all users of this system:

1. Never operate the system in an enclosed or partially

enclosed area without ventilation (such as a garage).

2. When parking in an enclosed or partially enclosed

area or when having the vehicle serviced, the remote

start system must be disabled by placing the system

into Valet Mode.

3. It is the user's sole responsibility to properly handle

and keep out of reach from children all remote

control units to assure that the system does not

unintentionally remote start the vehicle.

4. THE USER MUST INSTALL A CARBON MONOXIDE

DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT

➜

TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT

LIVING AREAS TO THE ENCLOSED OR PARTIALLY

ENCLOSED VEHICLE STORAGE AREA MUST AT ALL TIMES

REMAIN CLOSED.

Use of this product in a manner contrary to its intended

mode of operation may result in property damage, personal

injury, or death. Except when performing the Safety Check

outlined in this user’s guide, (1) Never remotely start the

vehicle with the vehicle in gear, and (2) Never remotely

start the vehicle with the keys in the ignition.

After the remote start module has been installed, test the

remote start module in accordance with the Safety Check

outlined in this installation guide. If the vehicle starts

when performing the Neutral Safety Shutdown Circuit test,

the remote start unit has not been properly installed. The

remote start module must be removed or properly rein-

stalled so that the vehicle does not start in gear. OPERA-

TION OF THE REMOTE START MODULE IF THE VEHICLE

STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF

OPERATION. OPERATING THE REMOTE START SYSTEM UNDER

THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR

PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE

UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE

START MODULE. DIRECTED WILL NOT BE HELD RESPON-

SIBLE OR PAY FOR INSTALLATION OR REINSTALLATION

COSTS.

Wiring Quick Reference Guide

Heavy Gauge

Wires

BLUE WHITE (+)

YELLOW

PINK

GREEN (+) output to ign/acc2 circuit

YELLOW/RED (-) lock or (+) unlock output

WHITE/RED (-) unlock or (+) lock output

MOMENTARY SWITCH PORT

ANTENNA CABLE PORT

SENSOR PORT

Fused light

flash jumper Black (-)

Heavy guage

ground wire

YELLOW (+/-) parking light output

BROWN/WHITE (-) factory alarm disarm output

VIOLET (-) negative hood pin shutdown output

ORANGE (+) brake input

WHITE/BLACK (-) 400mA status output

RED/WHITE (-) remote start activation

GREEN Tachometer input

BLUE (-) 400mA horn/siren output

RED/BLACK (-) wait-to-start input

YELLOW/GREEN (+) ignition output

GREEN/WHITE (-) 400mA trunk release output

BROWN (-) 400mA RAP, Dome light, Starter kill output

YELLOW/BROWN (-) 400mA Headlight output

GRAY/BLACK (-) Door trigger input

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Arranque remoto de Directed Electronics

Directed Electronics

Directed Electronics AutoCommand 25522 Manual de usuario

Directed Electronics

Directed Electronics Automate 552 Manual de usuario

Directed Electronics

Directed Electronics 560T Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 25523T Manual de usuario

Directed Electronics

Directed Electronics Ready Remote 23926 Manual de usuario

Directed Electronics

Directed Electronics ProSecurity RK20 Manual de usuario

Directed Electronics

Directed Electronics 4103 Series Manual de usuario

Directed Electronics

Directed Electronics Hornet 564T Manual de usuario

Directed Electronics

Directed Electronics AS-1271 Manual de usuario

Directed Electronics

Directed Electronics Valet 561T Manual de usuario

Directed Electronics

Directed Electronics Xpresskit Xpressparts Series Manual de usuario

Directed Electronics

Directed Electronics VIPER 5901 Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 41026 Guía de inicio rápido

Directed Electronics

Directed Electronics G4311A-AM15 AM15 Manual de usuario

Directed Electronics

Directed Electronics 3000 Manual de usuario

Directed Electronics

Directed Electronics Smart start Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 28623TN Guía de inicio rápido

Directed Electronics

Directed Electronics 3000 Manual de usuario

Directed Electronics

Directed Electronics AS-1775 Manual de usuario

Directed Electronics

Directed Electronics Failsafe 103T Manual de usuario

Directed Electronics

Directed Electronics AVITAL 4003 Manual de usuario

Directed Electronics

Directed Electronics Viper 5501 Manual de usuario

Directed Electronics

Directed Electronics SmartStart 5000-series Manual de usuario

Directed Electronics

Directed Electronics Python G4203P Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Code Alarm

Code Alarm CA-535 Manual de usuario

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual
