Model 650 ESP

Owner's Guide

Limited Lifetime

Consumer Warranty

Directed Electronics, Inc. ("DEI®") promises to the original purchaser to repair or

replace with a comparable reconditioned model any DEI unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated sen-

sors and accessories, which proves to be defective in workmanship or material under

reasonable use during the lifetime of the vehicle provided the following conditions

are met: the unit was professionally installed and serviced by an authorized DEI deal-

er; the unit will be professionally reinstalled in the vehicle in which it was original-

ly installed by an authorized DEI dealer; and the unit is returned to DEI, shipping

prepaid with a legible copy of the bill of sale or other dated proof of purchase bear-

ing the following information: consumer's name, telephone number and address; the

authorized dealers name, telephone number and address; complete product descrip-

tion, including accessories; the year, make and model of the vehicle; vehicle license

number and vehicle identification number. All components other than the unit,

including without limitation the siren, the remote transmitters and the associated

sensors and accessories, carry a one-year warranty from the date of purchase of the

same. This warranty is non-transferable and is automatically void if: the original pur-

chaser has not completed the warranty card and mailed it within ten (10) days of the

date of purchase to the address listed on the card; the unit's date code or serial num-

ber is defaced, missing or altered; the unit has been modified or used in a manner

contrary to its intended purpose; the unit has been damaged by accident, unreason-

able use, neglect, improper service, installation or other causes not arising out of

defects in materials or construction. The warranty does not cover damage to the unit

caused by installation or removal of the unit. DEI, in its sole discretion, will deter-

mine what constitutes excessive damage and may refuse the return of any unit with

excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES,

INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WAR-

RANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRAN-

TY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUD-

ED; AND DEI NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO

ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS

PRODUCTS. DEI DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL

ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS.

DEI SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSI-

BLE THEFT. DEI IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VAN-

DALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND

HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITH-

OUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WAR-

RANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REIN-

STALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE

EVENT OF A CLAIM OR A DISPUTE INVOLVING DEI OR ITS SUBSIDIARY, THE PROP-

ER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFOR-

NIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE

DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DEI SHALL BE

STRICTLY LIMITED TO THE AUTHORIZED DEI DEALER'S PURCHASE PRICE OF THE

UNIT. DEI SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUD-

ING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES,

DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF

ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE

MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE

CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights and you may also

have other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your

authorized DEI dealer for details of the plan or call DEI Customer Service at 1-800-

876-0800. DEI security systems, including this unit, are deterrents against possible

theft. DEI is not offering a guarantee or insurance against vandalism, damage or theft

of the automobile, its parts or contents; and hereby expressly disclaims any liability

whatsoever, including without limitation, liability for theft, damage and/or vandalism.

DEI does not and has not authorized any person or entity to create for it any other

obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of alarm installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Expanded Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Disarming Without a Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Valet®Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Remote Valet®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Nuisance Prevention Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Arming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Disarming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Code-Hopping™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Owner Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Rapid Resume Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Power Saver Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Vehicle Recovery System (VRS®). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Arming the VRS®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

VRS®Triggered Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Disarming the VRS®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Standard Configuration

What is Included

■3-Channel Receiver

■A pair of two-button transmitters

■A Stinger®Doubleguard®dual-output shock sensor (on-board

the control module)

■

The system requires no specific maintenance. Your remote control

is powered by a miniature 12V battery, type GP23A, that will last

approximately one year under normal use. When the battery weak-

ens, operating range will be reduced and the LED on the remote

will dim.

Your warranty card must be returned and the bar code serial num-

ber must not be removed. If the warranty card is not returned, you

do not have a warranty. It is also necessary to keep your proof of

purchase, which reflects that the product was installed by an au-

thorized dealer. Make sure that you receive the warranty card from

your dealer.

This device complies with Part 15 of FCC rules. Operation is sub-

ject to the following two conditions: (1) This device may not cause

harmful interference, and (2) This device must accept any interfer-

ence received, including interference that may cause undesired

operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to oper-

ate this device.

FCC/ID Notice

Your Warranty

System Maintenance

Transmitter Functions

The receiver uses a computer-based Learn Routine to learn the

transmitter buttons. This makes it possible to assign any transmit-

ter button to any receiver function. The transmitter initially comes

programmed with Standard Configuration, but may also be cus-

tomized by an authorized dealer. The buttons in all of the instruc-

tions in this manual correspond to a Standard Configuration trans-

mitter.

Button

The arming/disarming/panic functions are controlled by .

Button

Silent Mode™and an optional auxiliary function are controlled by

. (Silent Mode works by pressing for less than one second

before arming or disarming the system. An optional auxiliary func-

tion, such as trunk release, can be controlled by pressing for

1.5 seconds.)

The auxiliary output controls _____________________________.

and Buttons

An optional auxiliary convenience or expansion function that you

have added to your system can be activated by pressing and

simultaneously.

The auxiliary output controls _____________________________.

Standard Configuration

Your system has an expanded configuration that can be utilized

when upgrading to the four-button remote. In the expanded con-

figuration, your system will operate similarly to many factory key-

less entry systems that use separate remote transmitter buttons

for the arm, disarm, panic and auxiliary output functions. Multi-

Level Security Arming is also possible in the expanded configura-

tion. Contact your dealer for details.

Using Your System

The button numbers used in the descriptions correspond to the

standard configuration. Remember, this is not the only way your

transmitter may be set up. It can be custom configured to meet

your needs.

You can activate, or arm, the system by pressing of your

transmitter for one second. When the system arms, you will hear a

short siren sound, or chirp, and see the parking lights flash once.

If the vehicle’s power door locks have been connected to the sys-

tem, the doors will lock.

While the system is armed, the status LED will flash approximate-

ly once per second, showing that the system is actively protecting

Arming

Expanded Configuration

Tabla de contenidos

Otros manuales de Alarma de coche de Directed Electronics

Directed Electronics

Directed Electronics 2000 MAX Manual de usuario

Directed Electronics

Directed Electronics Python 990 Manual de usuario

Directed Electronics

Directed Electronics 411R Series Manual de usuario

Directed Electronics

Directed Electronics 400ESP Manual de usuario

Directed Electronics

Directed Electronics Concept 550 Manual de usuario

Directed Electronics

Directed Electronics 436 Series Manual de usuario

Directed Electronics

Directed Electronics PYTHON 333 Manual de usuario

Directed Electronics

Directed Electronics VIPER 5701 Manual de usuario

Directed Electronics

Directed Electronics Auto Mate AMX 8.5 Manual de usuario

Directed Electronics

Directed Electronics Matrix RS 2 Manual de usuario

Directed Electronics

Directed Electronics 560T Manual de usuario

Directed Electronics

Directed Electronics 7900 Manual de usuario

Directed Electronics

Directed Electronics Matrix 1 Manual de usuario

Directed Electronics

Directed Electronics Python 500 Manual de usuario

Directed Electronics

Directed Electronics Python 571XP Manual de usuario

Directed Electronics

Directed Electronics 1090 Manual de usuario

Directed Electronics

Directed Electronics 791XV Manual de usuario

Directed Electronics

Directed Electronics Hornet 719T Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 20095 Manual de usuario

Directed Electronics

Directed Electronics 446 Series Manual de usuario

Directed Electronics

Directed Electronics Python 990 Manual de usuario

Directed Electronics

Directed Electronics Avital Manual de usuario

Directed Electronics

Directed Electronics Concept 650 Manual de usuario

Directed Electronics

Directed Electronics 100 ESP Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
