Directed Electronics AM2 Manual de usuario

MMooddeellAAMM22

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics, Inc. promises to the original purchaser to repair or replace with a

comparable reconditioned model any Directed Electronics, Inc. unit (hereafter the

"unit"), excluding without limitation the siren, the remote transmitters, the associated

sensors and accessories, which proves to be defective in workmanship or material under

reasonable use during the lifetime of the vehicle provided the following conditions are

met: the unit was professionally installed and serviced by an authorized Directed

Electronics dealer; the unit will be professionally reinstalled in the vehicle in which it was

originally installed by an authorized Directed Electronics dealer; and the unit is returned

to Directed Electronics, Inc., shipping prepaid with a legible copy of the bill of sale or

other dated proof of purchase bearing the following information: consumer's name, tele-

phone number and address; the authorized dealers name, telephone number and address;

complete product description, including accessories; the year, make and model of the

vehicle; vehicle license number and vehicle identification number. All components other

than the unit, including without limitation the siren, the remote transmitters and the

associated sensors and accessories, carry a one-year warranty from the date of purchase of

the same. This warranty is non-transferable and is automatically void if: the original pur-

chaser has not completed the warranty card and mailed it within ten (10) days of the date

of purchase to the address listed on the card; the unit's date code or serial number is

defaced, missing or altered; the unit has been modified or used in a manner contrary to

its intended purpose; the unit has been damaged by accident, unreasonable use, neglect,

improper service, installation or other causes not arising out of defects in materials or con-

struction. The warranty does not cover damage to the unit caused by installation or

removal of the unit. Directed Electronics, Inc., in its sole discretion, will determine what

constitutes excessive damage and may refuse the return of any unit with excessive damage.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES,

INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WAR-

RANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR

PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL

PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED ELECTRONICS,

INC. NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO

ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION

WITH ITS PRODUCTS. DIRECTED ELECTRONICS, INC. DISCLAIMS AND

HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PAR-

TIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED

ELECTRONICS, INC. SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE

DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED ELECTRONICS, INC.

IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM,

DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;

AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,

INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE

AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS

FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR

ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A

CLAIM OR A DISPUTE INVOLVING DIRECTED ELECTRONICS, INC. OR ITS

SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE

STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FED-

ERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM

RECOVERY UNDER ANY CLAIM AGAINST DIRECTED ELECTRONICS, INC.

SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED ELEC-

TRONICS DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED ELEC-

TRONICS, INC. SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHAT-

SOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL

DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME,

LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTU-

NITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFAC-

TURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE

CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations

on how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights and you may also have

other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your

authorized Directed Electronics dealer for details of the plan or call Directed

Electronics, Inc. Customer Service at 1-800-876-0800. Directed Electronics, Inc. secu-

rity systems, including this unit, are deterrents against possible theft. Directed

Electronics, Inc. is not offering a guarantee or insurance against vandalism, damage or

theft of the automobile, its parts or contents; and hereby expressly disclaims any

liability whatsoever, including without limitation, liability for theft, damage and/or

vandalism. Directed Electronics, Inc. does not and has not authorized any person or

entity to create for it any other obligation, promise, duty or obligation in connection

with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttaabblleeooffccoonntteennttss

limited lifetime consumer warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

transmitter (standard) configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

transmitter functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

what is included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

system maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

fcc/id notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

transmitter functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

standard configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

using your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

locking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

disabling the system without a transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

silent modeTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

valet® mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

owner recognitionTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

rapid resume logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

programming options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

glossary of terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

security & convenience expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

ttrraannssmmiitttteerr((ssttaannddaarrdd))ccoonnffiigguurraattiioonn

To access the battery, use a coin to at the bottom of the trans-

mitter to open the case.

ttrraannssmmiitttteerrffuunnccttiioonnss

controls the LLoocckkfunction.

controls the UUnnlloocckkfunction.

controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt.

controls the PPaanniiccfunction.

unlock

panic

lock

auxiliary output

insert coin at this

edge to open

transmitter case

and pressed together control an additional

AAuuxxiilliiaarryyOOuuttppuutt.

wwhhaattiissiinncclluuddeedd

➤The control module

➤2 four-button transmitters

➤Pre-wired Valet®switch with integrated Red status led

➤Your warranty registration

➤Failsafe®Starter Kill Relay

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your keyless entry system.

Due to the complexity of this system, it must be installed by an

authorized dealer only. Installation of this product by anyone

other than an authorized dealer voids the warranty. All dealers

are provided with a preprinted dealer certificate to verify that

they are authorized.

By carefully reading this Owner's Guide prior to using your

system, you will maximize the use of this system and its features.

You can print additional or replacement copies of this manual by

accessing the Directed web site at www.directed.com.

system maintenance

The system requires no specific maintenance. Your remote is

that will last approximately one year under normal use. When

the battery begins to weaken, operating range will be reduced

and the LED on the remote will dim. Refer to Transmitter

(Standard) Configuration for battery access.

your warranty

Your warranty registration must be completely filled out and

returned within 10 days of purchase. Your product warranty

will not be validated if your warranty registration is not returned.

Make sure you receive the warranty registration from your dealer.

It is also necessary to keep your proof of purchase, which reflects

that the product was installed by an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesirable operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

ttrraannssmmiitttteerrffuunnccttiioonnss

The receiver uses a computer-based learn routine to learn the

transmitter buttons. This makes it possible to assign any specific

transmitter button, or combination of buttons, to any receiver

function. The transmitter initially comes programmed with the

Standard Configuration, but may also be customized by an

authorized dealer. The transmitter buttons indicated in all of the

instructions in this manual correspond to a Standard

Configuration transmitter.

standard configuration

Button

The locking function is controlled by pressing this button for one

second.

Button

The unlocking function is controlled by pressing this button for

one second.

➜

Tested to Comply

with FCC Standards

Directed Electronics, Inc. 416 Series

DRW-371

Button

Silent Mode™ and an optional auxiliary function are controlled

by this button. (An optional auxiliary function, such as trunk

release, can be controlled by pressing this button for 2 seconds.)

The auxiliary output controls __________________________.

Button

The panic feature is controlled by pressing this button for one

second.

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls_________________________.

uussiinnggyyoouurrssyysstteemm

locking

Pressing for one second locks the system by activating the

starter kill and locking the doors (if connected). The horn will

honk (if connected) and the parking lights will flash once to

confirm locking of the system. While the system is locked, the

status LED will flash once per second. The Failsafe®Starter Kill

(if installed) will also prevent the vehicle’s starter from cranking.

➜

The system can also be programmed to arm the optional Failsafe®

Starter Kill automatically (called Passive Mode). If the system has

been programmed for Passive Mode, the Failsafe®Starter Kill will

automatically activate 30 seconds after the ignition has been

turned off. After the ignition has been turned off, the status LED

will flash rapidly to indicate that the system is in Passive Mode.

If Passive Mode has been programmed on, then it is also possible

to program the system for Passive Locking. With Passive Locking,

the vehicle doors lock automatically at the same time that the Failsafe®

Starter Kill is activated. If Passive Locking is programmed on, care

must be taken to prevent the keys from being locked in the vehicle.

unlocking

Pressing for one second unlocks the system and the doors (if

connected). The horn will honk twice (if connected) and the

parking lights will flash twice to confirm unlocking of the system.

The optional Failsafe®Starter Kill will be deactivated. The status

LED will turn off, unless the system is programmed for Passive

Mode. In Passive Mode, the status LED will flash rapidly when the

system is unlocked. This indicates that the system will re-engage

the starter kill and re-lock the doors (if Passive Locking has been

➜

note: For Passive Mode to be effective, the Failsafe®

Starter Kill relay must be installed.

note: Manually locking the vehicle does not arm the sys-

tem; it will only lock the doors.

Tabla de contenidos

Otros manuales de Alarma de coche de Directed Electronics

Directed Electronics

Directed Electronics Matrix 2 Manual de usuario

Directed Electronics

Directed Electronics Python 500 Manual de usuario

Directed Electronics

Directed Electronics IntelliGuard 7000 Manual de usuario

Directed Electronics

Directed Electronics PS-7870TWE-FM Manual de usuario

Directed Electronics

Directed Electronics Python 880XP Manual de usuario

Directed Electronics

Directed Electronics 544T Manual de usuario

Directed Electronics

Directed Electronics 7900 Manual de usuario

Directed Electronics

Directed Electronics Hurricane 3 Manual de usuario

Directed Electronics

Directed Electronics PYTHON 480XP Manual de usuario

Directed Electronics

Directed Electronics G312R Guía de inicio rápido

Directed Electronics

Directed Electronics 2102T Manual de usuario

Directed Electronics

Directed Electronics Clifford 120XV Manual de usuario

Directed Electronics

Directed Electronics 3901T Manual de usuario

Directed Electronics

Directed Electronics Viper 350HV Manual de usuario

Directed Electronics

Directed Electronics 600 ESP Manual de usuario

Directed Electronics

Directed Electronics 553S Manual de usuario

Directed Electronics

Directed Electronics MERLIN 2000 Manual de usuario

Directed Electronics

Directed Electronics Python 450 ESP Manual de usuario

Directed Electronics

Directed Electronics 1000 Manual de usuario

Directed Electronics

Directed Electronics 4400 Manual de usuario

Directed Electronics

Directed Electronics G322R Guía de inicio rápido

Directed Electronics

Directed Electronics Security System and Convenience 125xv Manual de usuario

Directed Electronics

Directed Electronics PYTHON 333 Manual de usuario

Directed Electronics

Directed Electronics 551R Series Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
