Model 200

Owner's Guide

Limited Lifetime

Consumer Warranty

Directed Electronics, Inc. ("DEI®") promises to the original purchaser to repair or

replace with a comparable reconditioned model any DEI unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated

sensors and accessories, which proves to be defective in workmanship or material

under reasonable use during the lifetime of the vehicle provided the following con-

ditions are met: the unit was professionally installed and serviced by an authorized

DEI dealer; the unit will be professionally reinstalled in the vehicle in which it was

originally installed by an authorized DEI dealer; and the unit is returned to DEI, ship-

ping prepaid with a legible copy of the bill of sale or other dated proof of purchase

bearing the following information: consumer's name, telephone number and address;

the authorized dealers name, telephone number and address; complete product

description, including accessories; the year, make and model of the vehicle; vehicle

license number and vehicle identification number. All components other than the

unit, including without limitation the siren, the remote transmitters and the associ-

ated sensors and accessories, carry a one-year warranty from the date of purchase of

the same. This warranty is non-transferable and is automatically void if: the original

purchaser has not completed the warranty card and mailed it within ten (10) days of

the date of purchase to the address listed on the card; the unit's date code or serial

number is defaced, missing or altered; the unit has been modified or used in a

manner contrary to its intended purpose; the unit has been damaged by accident,

unreasonable use, neglect, improper service, installation or other causes not arising

out of defects in materials or construction. The warranty does not cover damage to

the unit caused by installation or removal of the unit. DEI, in its sole discretion, will

determine what constitutes excessive damage and may refuse the return of any unit

with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WAR-

RANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED

WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE

AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE

EXPRESSLY EXCLUDED; AND DEI NEITHER ASSUMES NOR AUTHORIZES ANY PERSON

OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNEC-

TION WITH ITS PRODUCTS. DEI DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY

FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS

OR INSTALLERS. DEI SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS

AGAINST POSSIBLE THEFT. DEI IS NOT OFFERING A GUARANTEE OR INSURANCE

AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CON-

TENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER,

INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VAN-

DALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE,

REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF

ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DEI OR ITS SUB-

SIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF

CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL

APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM

AGAINST DEI SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DEI DEALER'S PUR-

CHASE PRICE OF THE UNIT. DEI SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES

WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,

INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS,

COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITH-

STANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO

REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do

not allow limitations on how long an implied warranty will last or the exclusion or

limitation of incidental or consequential damages. This warranty gives you specific

legal rights and you may also have other rights that vary from State to State.

This product is not covered by the Guaranteed Protection Plan (“GPP”). DEI does not

and has not authorized any person or entity to create for it any other obligation,

promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of alarm installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

FCC/ID Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using Your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Multi-Level Security Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disarming Without a Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Disabling and Re-enabling the Back-Up Battery Siren . . . . . . . . . . . . . . . . . . . 9

Panic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Valet®Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Nuisance Prevention Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Arming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Disarming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Code-Hopping™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Rapid Resume Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

High Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Power Saver Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Standard Configuration

What is Included

■A control module

■A pair of two-button remote transmitters

■A Stinger®Doubleguard®dual-output shock sensor (on-board

the control module)

■A back-up battery siren

■Two back-up battery siren keys

■The red status LED indicator light

■A push-button Valet®switch

■A mercury tilt switch

■Failsafe®Starter Kill (on-board the control module)

Important Information

Congratulations on the purchase of your state-of-the-art security

system. This system has been designed to provide years of trouble-

free operation. This guide should help you to get the most out of

your system, so please take the time to review it thoroughly prior

to using the system.

The system requires no specific maintenance. Your remote is

under normal use. The remotes are disposable, so after the battery

System Maintenance

runs out, you can simply throw the transmitter away and replace

it with a new one.

Your warranty card must be returned. If the warranty card is not

returned, you do not have a warranty. It is also necessary to keep

your receipt, which reflects that the product was installed by an

authorized dealer. Make sure that you receive the warranty card

from your dealer.

IMPORTANT! This unit and its components are water resistant, not

waterproof; so the warranty is void if the product has been damaged as

a result of prolonged water exposure or submersion.

This device complies with Part 15 of FCC rules. Operation is subject

to the following conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference re-

ceived, including interference that may cause undesired operation.

Caution: Changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to

operate this device.

FCC/ID Notice

Your Warranty

Transmitter Functions

The receiver uses a computer-based Learn Routine to learn the

transmitter buttons. This makes it possible to assign different

transmitter buttons to different receiver functions. The transmitter

initially comes programmed with Standard Configuration, but may

also be customized by an authorized dealer. The buttons indicated

in the instructions in this manual correspond to a Standard

Configuration transmitter.

Button

The arming and panic functions are controlled by . To arm the

system press this button for one second. To activate the panic

function, press and hold this button for 1.5 seconds.

Button

The disarm function and an optional auxiliary convenience or

expansion function are controlled by . To disarm the system

press this button for one second. To activate the auxiliary function,

press and hold this button for 1.5 seconds.

This auxiliary output controls _____________________________.

and Buttons

Another optional auxiliary convenience or expansion function can

be activated by pressing and simultaneously.

This auxiliary output controls _____________________________.

Standard Configuration

Using Your System

The transmitter buttons indicated in this guide correspond to the

standard transmitter configuration. Remember, this is not the only

way your transmitter may be set up.

You can activate, or arm, the system by pressing on your

transmitter for one second. When the system arms, you will hear a

short siren sound, or chirp, and see the lights flash once.

While the system is armed, the status LED will flash approximately

once per second, showing that the system is actively protecting

your vehicle. If you hear a second chirp after arming and see the

status LED flashing in groups, refer to the Diagnostics section of

this guide. This extra chirp is called Bypass Notification.

The system also can be programmed to arm itself automatically

(called passive arming). If the system is programmed for passive

arming, it will automatically arm 30 seconds after the ignition is

turned off. Whenever the system is in its 30-second passive-

arming countdown, the status LED will flash twice as fast as it

does when the system is armed. At the 30-second point, the siren

will chirp to indicate that the system is armed.

NOTE: Some faulty zones may prevent the system from passively arming.

(See Arming Diagnostics and Table of Zones sections of this guide.)

Additionally, each time a sensor is triggered during the passive arming

countdown, the 30-second countdown starts over.

Arming

When armed, your vehicle is protected in the following ways:

■Light impacts will trigger the Warn Away®signal. When

triggered, the siren will chirp and the parking lights will flash

for a few seconds.

■Heavy impacts will trigger the system. The full trigger

sequence is 30 or 60 seconds of constant siren and flashing

parking lights.

■If the tilt switch is triggered or the ignition is turned on while

the system is armed, the full trigger sequence will activate.

■The starter kill prevents the vehicle’s starter from cranking.

Multi-Level Security is a feature that is only available when using

a Standard Configuration transmitter (see Transmitter Functions

section of this guide). Multi-Level Security Arming allows you to

select which of the security system's inputs or sensors will be

active and which will be bypassed at the time that the system is

armed (see Table of Zones section of this guide). Pressing

again within five seconds of arming the security system will acti-

vate the Multi-Level Security Arming feature. Each time is

pressed again, a different security level is selected. The different

security levels can be selected as follows:

■Pressing one time: The siren chirps once. The system is

armed.

■Pressing a second time within five seconds: The siren

chirps twice followed by a long chirp. Zone Two is now bypassed.

Multi-Level Security Arming

Tabla de contenidos

Otros manuales de Alarma de coche de Directed Electronics

Directed Electronics

Directed Electronics G312R Guía de inicio rápido

Directed Electronics

Directed Electronics Avital Manual de usuario

Directed Electronics

Directed Electronics 2100 Manual de usuario

Directed Electronics

Directed Electronics Arrow 5 Manual de usuario

Directed Electronics

Directed Electronics Cyber 76XV Manual de usuario

Directed Electronics

Directed Electronics PS-7870TWE-FM Manual de usuario

Directed Electronics

Directed Electronics Clifford G5 Manual de usuario

Directed Electronics

Directed Electronics Clifford RS2.1 Manual de usuario

Directed Electronics

Directed Electronics Hornet 742T Manual de usuario

Directed Electronics

Directed Electronics AM1 Manual de usuario

Directed Electronics

Directed Electronics Viper 211HV Manual de usuario

Directed Electronics

Directed Electronics MERLIN 2000 Manual de usuario

Directed Electronics

Directed Electronics Intelliguard 850 Manual de usuario

Directed Electronics

Directed Electronics Viper 771XV Manual de usuario

Directed Electronics

Directed Electronics 2000 MAX Manual de usuario

Directed Electronics

Directed Electronics Viper 5501 Manual de usuario

Directed Electronics

Directed Electronics PS-7870TWE-FM Manual de usuario

Directed Electronics

Directed Electronics 730T Manual de usuario

Directed Electronics

Directed Electronics Responder 460 Manual de usuario

Directed Electronics

Directed Electronics 871XP Manual de usuario

Directed Electronics

Directed Electronics Auto Mate AMX 8.5 Manual de usuario

Directed Electronics

Directed Electronics 411R Series Manual de usuario

Directed Electronics

Directed Electronics Avital 3200 Manual de usuario

Directed Electronics

Directed Electronics Python 990 Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
