Model 732T

Owner's Guide

Limited Lifetime

Consumer Warranty

For a period of one calendar year from the date of purchase of this auto-security

device, Directed Electronics, Inc. promises to the ORIGINAL PURCHASER to repair or

replace (with a comparable reconditioned model), free of cost, any electronic control

module which proves to be defective in workmanship or material under normal use,

SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PROFESSIONAL

AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS ORIGINALLY

INSTALLED. If warranty service is necessary you must have a clear copy of your sales

receipt containing all of the information shown on the following page.

After the first calendar year, from the date of purchase of this auto-security device,

Directed Electronics, Inc., promises to the ORIGINAL PURCHASER to repair or replace

(with a comparable reconditioned model) any electronic control module which proves

to be defective in workmanship or material under normal use FOR A CHARGE OF

$45.00, SO LONG AS THE SYSTEM WAS SOLD, INSTALLED, AND SERVICED BY A PRO-

FESSIONAL AUTO INSTALLER, AND REMAINS IN THE CAR IN WHICH THE SYSTEM WAS

ORIGINALLY INSTALLED. If warranty service is necessary you must have a clear copy

of your sales receipt containing all of the information shown on the following page.

This warranty contains the entire agreement relating to warranty and supersedes all

previous and contemporaneous representations or understandings, whether written or

oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS

CONTENTS.

This warranty is void if the product has been damaged by accident, unreasonable use,

neglect, improper service or other causes not arising out of defects in materials or

construction. This warranty is nontransferable and does not apply to any unit that

has been modified or used in a manner contrary to its intended purpose and does not

cover batteries. The unit in question must be returned to the manufacturer, postage

prepaid. This warranty does not cover labor costs for the removal, diagnosis, trou-

bleshooting or reinstallation of the unit. For service on an out-of-warranty product

a flat rate fee by model is charged. Contact your authorized dealer to obtain the ser-

vice charge for your unit.

These systems are a deterrent against possible theft. Directed Electronics, Inc. is not

offering a guarantee or insuring against the theft of the automobile or its contents

and disclaims any liability for the theft of the vehicle and/or its contents. Directed

Electronics does not authorize any person to create for it any other obligation or lia-

bility in connection with this security system.

TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD-

ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM-

MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU-

SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR-

RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF

NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR

ABROAD. NEITHER THE MANUFACTURER OR ANY ENTITIES CONNECTED THEREWITH

SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT

NOT LIMITED TO ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, TOWING,

REPAIR, REPLACEMENT, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE

ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR

THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or

consequential damages. This warranty gives you specific legal rights, and you may

also have other rights which vary from state to state.

IMPORTANT NOTE:

This product warranty is automatically void if its date code or serial number is

defaced, missing, or altered. This warranty will not be valid unless you have com-

pleted the warranty card and mailed it to Directed Electronics, Inc. within 10 days

after purchase to the address listed on the warranty registration card.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

■Date of purchase

■Your full name and address

■Authorized dealer's company name and address

■Type of system installed

■Year, make, model and color of the automobile

■Automobile license number

■Vehicle identification number

■All security options installed on automobile

■Installation receipts

Table of Contents

Limited Lifetime Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Your Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Transmitter Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Using your System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Arming While Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Disarming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

High Security Disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Disarming Without A Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Silent Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Panic Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Valet®Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Remote Valet®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Nuisance Prevention Circuitry®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Arming Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Disarming Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table of Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Code Hopping®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Programming Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Glossary Of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Security & Convenience Expansions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Quick Reference Guide (Removable) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Standard Configuration

Arm

Disarm

Panic

Auxiliary Output

Silent Mode

Trunk Release

Remote Valet

What is Included

■The control unit

■A pair of two-button transmitters

■A Stinger™DoubleGuard™shock sensor, on-board the control unit

■The Revenger™Soft-Chirp™six-tone programmable siren

■The red Status LED indicator light

■A push-button Valet switch

■Your warranty card

■FailSafe®starter-kill-ready circuitry (may require additional

parts and labor)

Important Information

Congratulations on the purchase of your state-of-the-art vehicle

security system. This system has been designed to provide years

of trouble-free operation. This guide should help you to get the

most out of your system. Please take the time to read it

thoroughly, prior to using your system.

Your warranty card must be returned. If it is not returned you do

not have a warranty. It is also necessary to keep your receipt,

which reflects that the product was installed by an authorized

dealer. Make sure you receive the warranty card from your dealer.

Your Warranty

The system requires no specific maintenance. Your remote is pow-

ered by a miniature 12V battery, type GP23A, that will last approx-

imately one year under normal use. When the battery weakens,

operating range will be reduced and the LED on the remote will dim.

Transmitter Functions

The receiver uses a computer-based Learn Routine to learn the trans-

mitter buttons. This makes it possible to assign any transmitter

button to any receiver function. The transmitter initially comes pro-

grammed with Standard Configuration, but may also be customized

by an authorized dealer. The buttons in all of the instructions in

this manual correspond to a Standard Configuration transmitter.

Button

The arm/disarm and Panic Functions are usually controlled by Button I.

Button

The Silent Mode, trunk release and Remote Valet functions are usu-

ally controlled by Button II. (Silent Mode and Remote Valet work by

pressing Button II for less than one second. Trunk release requires

you to press Button II for 1.5 Seconds.)

Standard Configuration

System Maintenance

and Button

An optional auxiliary convenience or expansion function that you

have added to your system can usually be controlled by pressing

and simultaneously. These button assignments can be

changed if needed, such as for two-car operation from one remote.

The auxiliary output controls _____________________________.

Using Your System

You can turn on, or arm, the system by pressing of your trans-

mitter for one second. When the system arms, you will hear a short

siren sound, or chirp, and see the parking lights flash once. If the

vehicle’s power door locks are controlled by the system, the doors

will lock. While the system is armed, the Status LED will flash

about twice a second, showing that the system is actively pro-

tecting your vehicle. If you hear a second chirp after arming and

see the Status LED flashes in groups, see Diagnostics section. This

extra chirp is called Bypass Notification. The system also can be

programmed to arm itself automatically (called passive arming). If

the system is programmed for passive arming, it will automatically

arm 30 seconds after the ignition is turned off and the system

"sees" you leave the vehicle by opening and closing a door.

Whenever the system is in its 30 second passive-arming count-

Arming

down, the Status LED will flash twice as fast as it does when the

system is armed.

NOTE: If any protected entry point (such as a door or a switch-protect-

ed trunk or hood) is open, the system will not passively arm (unless

forced passive arming is programmed on. See Programming Options sec-

tion). Additionally, each time a sensor is triggered during the arming

countdown, the 30-second countdown starts over.

When armed, your vehicle is protected in the following ways:

■Light impacts will trigger the Warn Away®signal. When trig-

gered, the siren will chirp and the parking lights will flash for

a few seconds.

■Heavy impacts will trigger the system. The trigger sequence

is 30 seconds of constant siren and flashing parking lights.

■If a door is opened, the system will immediately start chirp-

ing the siren and flashing the parking lights. Three seconds

later, the siren output changes to a continuous blast. This

progressive response gives you time to disarm the system

with your transmitter if you inadvertently open the door

while the system is armed, while still providing instant

response (even if the door is immediately closed).

■Turning on the ignition key will trip the same two-stage

response as opening a door.

■The optional starter kill prevents the starter from cranking.

Your system can be armed while driving the vehicle! Simply press

on your transmitter while the vehicle is running. The system

will chirp once and then once more to indicate that the ignition

Arming While Driving

is on. The system will not respond to any input except the door

triggers and the starter kill relay (if installed) will not be activated.

The system will disarm automatically when the ignition is turned

off. The siren will chirp twice and the LED will stop flashing.

To turn off, or disarm the system, press again. You will hear

two chirps, and the parking lights will flash twice. If power locks

are controlled by the system, the doors will unlock. If the siren

chirps either four or five times when disarming, see Diagnostics

section. This is called Tamper Alert.

Your system includes a High Security Disarm feature. During the

triggered sequence, using the transmitter to disarm it will only

stop the triggered sequence (the siren will stop and the parking

lights will stop flashing), however, the system will remain armed

and the doors will stay locked. This is extremely useful if you must

stop the system from sounding, but are unable to check the vehicle

visually. The trigger will stop, but the vehicle will remain protected.

To disarm with the transmitter during a trigger, press on your

transmitter. The siren will stop sounding. Next press once

more and the system will chirp four or five times (reporting the

trigger) and disarm.

High Security Disarm

Disarming

Tabla de contenidos

Otros manuales de Alarma de coche de Directed Electronics

Directed Electronics

Directed Electronics Automate 640M Manual de usuario

Directed Electronics

Directed Electronics 3901T Manual de usuario

Directed Electronics

Directed Electronics Car Alarm Manual de usuario

Directed Electronics

Directed Electronics Avital Manual de usuario

Directed Electronics

Directed Electronics Avital 3200 Manual de usuario

Directed Electronics

Directed Electronics G436S 5220XS Manual de usuario

Directed Electronics

Directed Electronics 425 Series Manual de usuario

Directed Electronics

Directed Electronics Viper 350HV Manual de usuario

Directed Electronics

Directed Electronics Viper 550HF Manual de usuario

Directed Electronics

Directed Electronics 1000 Manual de usuario

Directed Electronics

Directed Electronics PYTHON 480XP Manual de usuario

Directed Electronics

Directed Electronics Vehicle Security System 3901V Manual de usuario

Directed Electronics

Directed Electronics 100 ESP Manual de usuario

Directed Electronics

Directed Electronics 429 Series Manual de usuario

Directed Electronics

Directed Electronics 671XV Manual de usuario

Directed Electronics

Directed Electronics Viper 5904 Manual de usuario

Directed Electronics

Directed Electronics 411R Series Manual de usuario

Directed Electronics

Directed Electronics Intelliguard 750 Manual de usuario

Directed Electronics

Directed Electronics Python 571XP Manual de usuario

Directed Electronics

Directed Electronics K10 Manual de usuario

Directed Electronics

Directed Electronics 554R Manual de usuario

Directed Electronics

Directed Electronics AutoCommand 20095 Manual de usuario

Directed Electronics

Directed Electronics Viper 220MAX Manual de usuario

Directed Electronics

Directed Electronics 690XV Manual de usuario

Manuales populares de Alarma de coche de otras marcas

Clifford

Clifford 3606X Manual de usuario

Ultra Start

Ultra Start 2500M SERIES Manual de usuario

Ultra Start

Ultra Start 650 Series Manual de usuario

Audiovox

Audiovox Prestige Platinum+ APS-511C Manual de usuario

Sparkrite

Sparkrite SRA8 Manual de usuario

Viper

Viper 4708V Manual de usuario

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manual

Falcon

Falcon Predator XL3 Guía del usuario

Audiovox

Audiovox Auto Security XR91 Instrucciones de funcionamiento

Clifford

Clifford Sabre II Manual de usuario

CrimeStopper

CrimeStopper CS-8717 Guía de inicio rápido

Ultra Start

Ultra Start 450 SERIES Manual de usuario

Scytek electronic

Scytek electronic Vectra X3 Manual de usuario

Excalibur

Excalibur AL-1860-EDPB Manual de usuario

Clifford

Clifford CYBER 2 Manual de usuario

Gemini

Gemini 7057 Manual de usuario

FlashLogic

FlashLogic FLRSBA PRESTIGE Manual de usuario

Magicar

Magicar FAI-440 Manual de usuario
