Digitus DN-95323-1 Manual de usuario

Fast Ethernet PoE af/at 8-port

Switch + 2 uplinks

User Manual

DN-95323-1 Rev. 2

Package Contents

Check the following contents of

your package:



PoE Switch x1



User Manual x1



Power Cord x1



Accessories

(Rubber Feet*4, 19” bracket*2)

If any part is lost and damaged, please contact your local

agent immediately.

Introduction

The DIGITUS® 8-port Fast Ethernet Switch with 8 Power over

Ethernet ports provides your network a noticeable

improvement in performance and efficiency. Thanks to PoE+

(30W) support, you only need one cable (network cable) for

power and data transfer. This enables you to expend your

network even where no power lines or outlets are available.

The switch doesn't need a configuration so a fast and seamless

integration you’re your network is guaranteed. With the

integrated DIP switch, you can activate the VLAN mode (Virtual

Local Area Network). By the port separation an optimal and

time-saving identification of the connected devices (e.g.

IP-Network cameras) is possible without using a web interface.

Multicast and broadcast requests are also prevented via the

port-based VLAN function. The Extensive mode can be used to

extend the range by up to 250 m at 10 Mbps.

Hardware Description

Front Panel

The Front Panel Consists of Ethernet Ports. The LED indicators

are also located on the panel.

DIP Switch

The DIP switch located on the left panel.

Default: The factory default mode, normal communication

between port 1~10.

VLAN: Port 1-8 are isolated to stop broadcast Storm and

increase forwarding rate of frame but can

communicate via uplink port 9 and 10 CCTV Up to

250m PoE distance allows you to expand you

network via Ethernet cable to where there is no

power Line or outlet. Network speed will be

reduced to 10Mbps

Note: After change the mode, in order to make the

corresponding configuration take effect you need to manually

restart

LED indicator

LED Color Function

PWR Green

Off: No Power supply

Light: Indicates the switch has power

LNK/

ACT Green

Off: No device is connected to the

corresponding port

Light: Indicates the link through that

port is successfully Established at

10/100Mbps

Blink: Indicates that the Switch is

actively sending or receiving data over

that port

PoE Orange

Off: No PoE powered device (PD)

connected

Light: There is a PoE PD connected to

be port

Blink: Indicates port abnormal PoE

function

Rear Panel

The rear panel of the PoE Switch indicates an AC inlet power

socket, which accepts input power from 100 to

240V AC, 50/60HZ.

Power socket

Connect the female connector of the power cord here, and the

male connector to the AC (Alternating Current) power outlet.

Please make sure the voltage of the power supply meets the

requirement of the input voltage

Grounding column

The switch already comes with lightning protection mechanism.

You can also ground the switch through the PE (Protecting

Earth) cable of AC cord or with Ground Cable.

Installation of the Switch

This part describes how to install your Ethernet Switch and

make connections to it. Please follow the following instructions

to avoid incorrect installation causing device damage and

security threat.

Before cleaning the switch, unplug the power plug of the

switch first. Do not clean the switch with wet cloth or

liquid

Do not place the switch near water or any damp area

Prevent water or moisture from entering the switch

chassis

Do not place the switch on an unstable case or desk.

The switch might be damaged severely in case of a fall

Ensure proper ventilation of the equipment room and

keep the ventilation vents of the switch free of

obstruction

Make sure that the operating voltage is the same one

labeled on the switch

Do not open the chassis while the switch is operating or

when electrical hazards are present to avoid electrical

shocks.

Desktop Installation

Install the Switch on a desktop, please attach these cushioning

rubber feet provided on the bottom at each corner of the

Switch in case of external vibration. Allow adequate space for

ventilation between the device and the objects around it.

Wall-mounted installation

Fix the two screws on the wall as shown in the figure below

Place the switch smoothly on the screws to fix it to the wall

Turn on the switch

Please connect the AC power cord into the rear of the switch

and to an electrical outlet (preferably one that is grounded).

When the switch is power on, the LED indicators flash

momentarily for one second, which represents a resetting of

the system. The Power LED indicator turns on green.

Note: Please confirm the voltage is correct before power

on, otherwise the switch will be damaged.

(The power input is: 100V-240Vac, 50/60Hz.)

Specifications

Model

8*FE (PoE)+2FE Uplink PoE Switch

Standard

IEEE802.3, IEEE802.3u, IEEE802.3az,

IEEE802.3x, IEEE802.3af, IEEE802.3at

Network Media

10BASE-T:

UTP category 3,4,5 cable (≤100m)

100BASE-TX:

UTP category 5 cable (≤100m)

MAC Address Table

1K, Auto-learning, Auto-aging

Transfer mode

Store-and-Forward

Frame Forward Rate

10Base-T: 14881pps/Port

100Base-TX: 148810pps/Port

Switching Capacity

Dimensions (L*W*H)

220 *150*44mm

Fan

Fanless

Power Input

AC: 100~240V, 50/60Hz

PoE Port

Port 1~8

PoE Power on RJ45

Mode A 1/2(+), 3/6(-)

PoE Power Output

Voltage: 55V DC

Power: 30W(Max)

PoE Power Budget

120W

Temperature

Operating Temperature:

0°C ~ 40 °C (32 °F ~104°F)

Storage Temperature:

-40 °C ~ 70 °C (-40 °F ~158°F)

Humidity

Operating Humidity:

10% ~ 90% non-condensing

Storage Humidity:

5% ~ 90% non-condensing

This is a Class A product. In home environment, this product may cause radio

interference. In this case, the user may be required to take appropriate

measures.

Hereby Assmann Electronic GmbH, declares that the Declaration of

Conformity is part of the shipping content. If the Declaration of Conformity is

missing, you can request it by post under the below mentioned manufacturer

address.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany
