Digitus DN-651160 Manual de usuario

Industrial 8 + 4-port L3

managed Gigabit Ethernet

(PoE) Switch

Quick Installation Guide

DN-651160, DN-651161

Table Content

1. Overview ..................................................... 3

2. Features....................................................... 3

3. Specification ................................................ 4

3.1 standard...................................................... 4

3.2 Interface...................................................... 5

3.3 Work environment...................................... 5

3.4 Switch ......................................................... 5

3.5 Power supply .............................................. 5

3.6 Mechanical characteristic........................... 6

3.7 Industrial standard...................................... 6

4. Package........................................................ 6

5. Switch Panel................................................. 7

6. LED Indicator................................................ 8

7. Installation Caution ...................................... 9

7.1 Installation precautions .............................. 9

7.2 Din rail installation.................................... 10

7.3 grounding.................................................. 10

7.4 Power Connection .................................... 10

8. Management system Login ..........................11

1. Overview

This is a L3 managed industrial PoE Ethernet switch

with 8 Port 10/100/1000Mbps RJ45 (PoE) +4 Port

1000/2500/10000Mbps SFP, support one console port.

The Ethernet switch adopts Layer 2 protocol required

by the industrial site to ensure the stability of the

communication network. This series of switches adopt

low power consumption and fanless design to ensure

no noise interference, while supporting -40~80°C

working temperature and good EMC electromagnetic

compatibility performance to ensure stable work in

harsh industrial environments, and to build fast for

industrial applications such as factory automation,

intelligent transportation, and video surveillance.

Stable network terminal access network provides a safe

and reliable solution.

2. Features

Data control: support 802.3X full-duplex flow

control, support network storm suppression

Redundant network: support STP/RSTP/MSTP,

support ERPS (self-healing time <20ms)

Multicast management: support IGMP Snooping

V1/V2/V3

Redundancy backup: supports the virtual route

redundancy protocol VRRP

VLAN: Support IEEE 802.1Q VLAN, effectively isolate

the broadcast domain

Link aggregation: support link static/dynamic

aggregation, providing perfect bandwidth utilization

QOS: Support COS\DSCP, 4 queues, support

WRR\SP scheduling mode

Security management: support ACL access control

list, support 802.1X

Management function: support WEB, CLI, SNMP

management methods

Monitoring and maintenance: support port

mirroring, interface status monitoring, log

management

Supports static routes. IPV6

Supports NTP clients. Support PTP（1588v2）

IP40 protection grade

3. Specification

3.1 standard

IEEE802.3i 10Base-T,IEEE802.3u 100Base-TX,

IEEE802.3ab 1000Base-T,IEEE802.3z 1000Base-X,IEEE

802.3ae 10GBase-X,IEEE802.3x Flow

Control,IEEE802.1d-Spanning Tree

Protocol,IEEE802.1w-Rapid Spanning Tree

Protocol,IEEE802.1q-VLAN , IEEE 802.3ad, IEEE802.1p-

Class of Service,IEEE802.1X-Port Based Network Access

Control,IEEE802.3af,IEEE802.3at etc.

3.2 Interface

DN-651160: 8 Port Gigabit RJ45 + 4port 10G SFP

DN-651161: 8 Port Gigabit RJ45 (PoE) +4 Port 10G SFP

3.3 Work environment

Working temperature: -40～80 °C

storage temperature: -40～85 °C

relative humidity: 5%～95% (no condensation)

3.4 Switch

Bandwidth (switch capacity): 1.2Tbps

Packet Buffer Memory: 32Mbit

Packet Forwarding Rate: 406Mpps

MAC Address Table: 32K

3.5 Power supply

Input voltage: DC12-48V (DN-651160)

Input voltage: DC48-57V (DN-651161)

(Two-way power redundancy backup)

Access terminal:

Block terminal, Support dual power redundancy

Support built-in over current 4.0A protection

Support reverse connection protection

Max Power consumption: 18W

3.6 Mechanical characteristic

IP40 aluminum housing

DIN rail installation

Natural colling, no fan

Weight: 0.8Kgs

Measurement: 175.6 x 135 x 45.5 mm

3.7 Industrial standard

FCC CFR47 Part 15, EN55032, Class A

IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air)

IEC61000-4-3 (RS): 10V/m (80~1000MHz)

IEC61000-4-4 (EFT): Power Port: ±2kV; Data Port: ±1kV

IEC61000-4-5 (Surge): Power Port: ±2kV/CM, ±1kV/DM;

Data Port: ±4kV/CM, ±2kV/DM

IEC61000-4-6 (CS): 3V (10 kHz-150 kHz);

10V (150 kHz-80MHz)

IEC61000-4-16 (Common mode conduction): 30V

(cont.), 300V (1s)

Frequency range：150kHz-80MHz

Impact: IEC 60068-2-27

Free Fall: IEC 60068-2-32

Vibration: IEC 60068-2-6

4. Package

Industrial switch 1pcs

User manual 1pcs

Block terminal 1pcs

5. Switch Panel

Side panel: P1 and P2 are the number of connecting

terminals, P+1 and P-1 are respectively to the positive

and negative poles to be connected; Earthing screw

used for earthing equipment.

Front panel: the yellow light on RJ45 port is the link

light. It is on, when the connection is established and

the transmission data is flashing. The green light on

RJ45 port is the POE light, which is only on when the

switch port supplies power to the downlink PD. Green

LED on is for system operation. The power indicator

“POW” shows whether the current device is received

power in normal.

There are also green LED for optical link status.

Switch size (mm) 175.6* 135*45.5

6. LED Indicator

LED Indicator

Status

Definition

Power

Red LED on

Power work in

normal

Red LED off

No power or

power in trouble

RJ45 LED

Yellow LED on

Ethernet work in

normal

Yellow LED

flashing

Link

communication

in normal

Green LED on

PoE feeding to PD

device in normal

Green LED off

No PoE work

RUN

Green LED

slowing

flashing

System run in

normal

Optical LED

Green LED on

Optical work in

normal

7. Installation Caution

7.1 Installation precautions

In order to avoid damage to equipment and personal

injury caused by improper use, please follow the

following precautions:

In order to avoid damage caused by falling of the

equipment, please put the equipment in a stable

environment.

When supplying power to the equipment, pay

attention to confirm the range of power supply

voltage, as well as the positive and negative poles

of the power supply, so as not to damage the

equipment by wrong operation.

In order to reduce the risk of electric shock, ensure

that the equipment is well grounded in the working

environment.

No matter when, please do not arbitrarily remove

the equipment shell.

When placing the switch, please avoid the area with

dust and strong electromagnetic interference

7.2 Din rail installation

The first step is to check the grounding

and stability of the guide rail: the guide

rail slot of the switch is clamped into

the guide rail; the second step: from

the center to both sides of the guide

rail positioning screws in order. Step 3:

Use screws to fix the mounting rail card

slot on the fixed guide groove at both

ends of the guide rail to ensure that the

guide rail and the switch are fixed on

the guide rail vertically and stably.

7.3 grounding

Fix the grounding wire to the

grounding screw above the switch,

and ensure good reliable

connection of the grounding

system.

7.4 Power Connection

Insert the power cord into the specified position of the

6-core terminal, and insert the terminal into the

standard power supply inlet (P+1 and P-1 input

corresponding to the first power supply P1, and P+2

and P-2 input corresponding to the second power

supply P2).
