Digitus DS-43110 Manual de usuario

8-PORT HDMI

VIDEO SPLITTER

User Manual

DS-43110

２

Table of Contents

1.0 Introduction ....................................................................................2

2.0 Specifications.................................................................................2

3.0 Package Contents..........................................................................3

4.0 Panel Descriptions.........................................................................4

5.0 Connection and Operation............................................................4

３

HDMI 8Ports Splitter Amplifier by Cat5 x1

Dear Customer

Thank you for purchasing this product. For optimum performance and safety, please read these

instructions carefully before connecting, operating or adjusting this product. Please keep this manual

for future reference.

1.0 Introduction

This HDMI Splitter is an HDMI splitter with eight RJ45 outputs. It distributes the input of the HDMI

signal into the eight identical outputs simultaneously. Eight HDMI Extender Receivers by Cat5 x1

receive the distributed signal from the splitter and transmit to displays individually.

Each receiver works with the splitter as a full functional module. Only by the most inexpensive UTP

cable with cross stand inside the full functional module extend the HDTV display up to 50 meters for

1080p.

This HDMI Splitter offers solutions for HDTV retail and show site, HDTV, STB, DVD and Projector

factory, noise, space and security concerns, data center control, information distribution, conference

room presentation, school and corporate training environments.

1.1 Features

This HDMI Splitter has many features that enable it to perform in a superior manner.

Among those features you will find:

Easy to Use: Install in seconds, no need of setting.

One pair as a full functional module,

One piece of CAT-5e/6 cable can substitute HDMI cable to achieve long distance transmission.

Follow the standard of IEEE-568B.

Transmission distance can be up to 50 meters for 1080p using

UTP cable with cross stand inside.

Supports highest video resolution 1080p.

Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.

Supports 8bit per channel (24bit all channel) deep color.

Supports uncompressed audio such as LPCM

４

2.0 SPECIFICATIONS

Signal Inputs/Output

Input DDC Signal 5 volts p-p (TTL)

Maximum Single Link Range 1920X1080p

Output Video HDMI

Operating Frequency

Video Amplifier Bandwidth 1.65Gpbs/165MHz

Vertical Frequency Range 50/60Hz

Resolutions(HDTV)

Interlaced(50&60Hz) 480i,576i,1080i

Progressive(50&60Hz) 480p,576p,720p,1080p

Mechanical

Size of HDMI 8Ports Splitter Amplifier (L-W-H) 441×202×45mm

Weight of HDMI 8Ports Splitter Amplifier (Net) 2218g

Size of Receiver (L-W-H) 100×65×25.5MM

Weight of Receiver (Net) 385G

Warranty

Limited Warranty 1 Year Parts and Labor

Environmental

Operating Temperature 0°C to +70°C

Operating Humidity 10% to 85 % RH (no condensation)

Storage Temperature -10°C to +80°C

Storage Humidity 5% to 90 % RH (no condensation)

Power Requirement

Power Supply for HDMI 8Ports Splitter Amplifier 5V DC@4A，15W

Power Supply for Receiver 5V DC@2A，5W

Regulatory Approvals

Converter Unit FCC,CE,UL

Power Supply UL,CE,FCC

Accessories Adapter

AC Power Adapter US standard, UK standard and so on

User Manual English Version

Note: Specifications are subject to change without notice.

3.0 Package Contents

Before attempting to use this unit, please check the packaging and make sure the following items

are contained in the shipping carton:

Packaging of Main Unit

1) HDMI 8Ports Splitter Amplifier

2) User’s Manual.

Packaging of Accessories

3) Eight Receivers

4) Nine pieces of 5V DC Power Supply.

（one 5V@4A，eight 5V@2A）

4.0 Panel Descriptions

5.0 ConnectION and OperatION

1) Connect the single HDMI source (such as HD-DVD, PS3, STB ) to the main HDMI input

using a piece of HDMI cable.

2) Connect each piece of CAT-5e/6 cable to both of the output of the HDMI 8-Ports Splitter

Amplifier and input of the Receiver.

3) Connect outputs of Receivers to displays ( such as HD-LCD, HD-DLP)

4) Plug the 5V@ 4A power supply into the HDMI 8Ports Splitter Amplifier and the

5V@2A power suppliers to each Receiver individually.

Attention: Insert / Extract cable gently.

６

5.1 CONNECTION DIAGRAM
