Digitus DN-18604 Manual de usuario

Smart Full HD PTZ Outdoor Camera

with Auto Tracking, Dual LED,

WiFi + Voice Control

Quick Installation Guide

DN-18604

1. Introduction

The weatherproof WiFi outdoor camera from

DIGITUS® can be rotated 355° and panned 90° and is

equipped with auto-tracking, this enables automatic

tracking of movements within the field of view.

Thanks to the wide-angle lens of 85° with razor-sharp

Full HD resolution, you won't miss a single detail. The

integrated dual LEDs ensure the best possible night

vision up to 50 m - with switched-on white light LEDs

also in color. They ensure optimal illumination and a

clear view even in absolute darkness. Thanks to

WLAN operation, you are 100% flexible as far as the

installation location is concerned. All you have to do

is position the camera within the range of your

wireless network and supply it with power;

alternatively, a network connection can also be

established via cable using the RJ45 port. Via Amazon

Alexa and Google Assistant, the camera image can be

displayed on corresponding Amazon and Google

displays via voice command. The camera is also able

to detect and track movements in the image area and

send a corresponding push notification to your

smartphone. The available MicroSD card slot can be

equipped with memory cards of up to 128 GB, so that

recordings can be stored for a longer period of time

and retrieved at any time. The two-way audio

transmission allows you to communicate with people

in front of the camera.

The camera's live image and all settings can be

conveniently accessed and adjusted via app -

regardless of your current location (assuming cellular

reception). The camera is designed for a variety of

uses, for example, for monitoring the house, garden,

garage or carport. Thanks to the included bracket, the

camera can be individually aligned and mounted. Go

for security and flexibility with the voice-controlled

Full HD PTZ outdoor camera from DIGITUS®.

2. Main features

•Full HD video resolution 1080p with a wide angle

of 85°.

•Auto tracking function (tracking movements)

•Rotates 355° (PAN) / tilts 90° (TILT)

•Dual-LED illumination for optimal night vision up to

50m in color

•Voice control via Amazon Alexa & Google Assistant

possible

•Motion detection with push notification via app

•Supports two-way audio transmission

•Recording to MicroSD card / cloud possible

(manual/motion/schedule)

•Free Smart Life (Tuya) app available for iOS and

Android

•Suitable for wall installation, weatherproof, IP65

3. Package Content

•1 x Smart full HD PTZ outdoor camera with auto-

tracking, dual-LED, WiFi + voice control

•1 x Power adapter

•1 x Mounting material

•1 x Quick Start Guide

IMPORTANT:If any part is missing or damaged,

please contact your local dealer or reseller for

assistance.

4. Technical data

•Video Resolution: 1920 x 1080p@25 BpS (Full HD)

•Video compression: H.264

•Optics: FOV: 90° viewing angle / 4 mm lens

•Light sensitivity: 0.1 lux / Aperture: F1.2

•Sensor: 1/2.7" CMOS - 2 megapixel

•Supports motion detection with auto-tracking

(tracking motion)

•Rotates 355° (PAN) / Tilts 90° (TILT)

•Night vision range: up to 50m with dual LED for

optimal illumination

•Day / night switching: IR-CUT

•Video frame rate: Mainstream 1080p@25bps,

720p@25bps

•Infrared LEDs: 4 pcs / White light LEDs: 4 pcs for

optimized night vision in color

•Built-in speaker and microphone

•Two-way audio communication / compression:

G.711

•Connection types: Wireless LAN / LAN RJ45

•wireless LAN: 2.4 GHz (IEEE 802.11b/g/n) - dual

antenna

•LAN: RJ45 10/100M

•Recording modes: Manual / Motion / Schedule

•With MicroSD card slot

•MicroSD card storage capacity: up to 128 GB

•Supports cloud storage

•Network protocols: TCP/IP, UDP, DDNS, P2P, RTSP,

Private Cloud, ONVIF

•System requirements: iOS 7 / Android 4 or higher

•Security: user authentication, software encryption

•Power supply camera: 12 V DC, 2 A via 5.5 mm DC

jack

•Power consumption: 20 W max.

•Power supply input voltage: 100 - 240 V, 50/60 Hz ,

0.7 A via Euro plug type-C (CEE 7/16)

•Power supply output voltage: 12 V DC, 2 A, 24 W

via 5.5 mm hollow plug

•Operating temperature: -10°C ~ +50°C

•Operating humidity: 10% ~ 90%

•Protection class: IP65

•Dimensions: L 110 x W 170 x H 200 mm

•Weight: 490 g

•Color: White

5. Safety instructions

Please read these instructions carefully before first

use and retain them for future reference. The safety

precautions contained herein will reduce the risk of

fire, electric shock and injury when followed

correctly.

This product is designed for residential use.

This product is IP 65 rated, so there is protection

against heavy seas and dust tightness.

6. Safety instructions for devices with a

power supply unit in closed rooms

•Do not open the device under any circumstances.

It does not contain any parts requiring

maintenance. In the event of a fault, have the

device checked and repaired by a specialist.

•For safety and approval reasons, the device must

not be converted or modified.

•In case of problems, please contact our

customer service.

•Only use the device with the enclosed original

power supply unit.

•The device may only be connected to easily accessible

sockets. In case of danger, pull out the mains plug.

•Always lay cables to the device in such a way that

they do not pose a danger to persons or animals.

•Use the device only within the specified

temperature range of: 0 ~ 40°C.

•When not in use, store the product in a clean and dry

place with temperatures between 0°C and 40°C.

•Do not allow the device to come into contact

with liquids

•This device is not intended for outdoor use. Ensure

that the device is used only in dry, dust-free,

apartment-like environments.

•During thunderstorms, there is a risk of

overvoltage due to the risk of lightning strikes.

Disconnect all connections of the device during

thunderstorms.

•The device is not a toy! Keep the equipment out of

the reach of children. Packaging material lying around

such as plastic bags, foils or cushioning elements such

as Styrofoam can be dangerous for children.

•Dust, moisture and vapors as well as sharp cleaning

agents or solvents may damage the product.

•Disconnect the product from the power source

before cleaning. Use a lint-free cloth for cleaning.

•We accept no liability for damage to property or

personal injury caused by improper handling of the

device or by failure to observe the hazard warnings.

We accept no liability for consequential damage! In

such cases, all warranty claims are void.

7. Note on Video Surveillance

Observe all applicable laws regarding camera

surveillance. The cameras are intended for private

use at home. Inform your family members, relatives

and household helpers in your household about the

video surveillance. Ensure that public areas and your

neighbors' property cannot be seen.

8. Notes when using the APP

Read and accept the privacy policy of the platform

within the app. Choose a password with a high level

of security for your account to protect it from

unauthorized access.

The password should contain at least 8 characters;

we recommend using upper and lower case and

alphanumeric characters / special characters.

9. Explanation about Amazon, Google,

Apple, etc.

Amazon, Alexa and all related logos are trademarks of

Amazon.com, Inc. or its affiliates.

Android, Google, Google Home and Google play are

registered trademarks of Google Inc.

AVM Fritz!Box is a registered trademark of AVM

Computersysteme Vertriebs GmbH.

Telekom Speedport is a registered trademark of

Deutsche Telekom AG.

App Store is a service mark of Apple Inc. registered in

the U.S. and other countries. IOS is a trademark or

registered trademark of Cisco in the U.S. and other

countries and is used under license.

Google Play and the Google Play logo are trademarks

of Google Inc. All other trademarks not listed herein

are the property of their respective owners.

The trademarks or trade names mentioned in this

manual are used to describe the operating steps and

do not imply that they are freely available. In any

case, they are the property of the respective rights

holders.

10. Commissioning guide:

Hardware overview:

Smart Full HD PTZ Outdoor

Camera with Auto Tracking,

Dual LED, WiFi + Voice Control

RJ45 waterproof

connector cap

Power supply

Mounting kit
