Digitus DA-70885 Manual de usuario

USB-C™ Docking Station 10-in-1

with Keyboard

Manual

DA-70885

Product Introduction

The multifunctional DIGITUS® docking station has everything you

need to create a fully equipped workplace. The integrated keyboard

enables you to utilize your notebook or MacBook® even more

conveniently, namely in conjunction with the docking station. Via the

HDMI® and VGA port, you can extend your desktop by 2 additional

monitors or connect projectors / TV devices. In combination with

your existing screen, this allows you to clone your desktop or extend

it to a maximum of 3 displays (Windows: 3 extended / macOS®: 2

extended + 1 cloned). Additionally, the docking station is equipped

with two USB-C™ ports, one of which features Power Delivery (PD).

This allows you to charge your connected notebook / tablet while in

use. Three additional USB 3.0 ports provide you with plenty of space

to connect additional mobile devices, which can be charged while in

use. Of course, other USB peripheral devices, e.g. a mouse or USB

stick can also be connected using the USB 3.0 port (downward

compatible with USB 2.0). Two card readers for SD/TF cards and

MicroSD cards are also integrated, as is a gigabit Ethernet port. This

allows you to connect your notebook to the local network or Internet

via the docking station using a network cable. The Desktop-Multi-

Tool features are rounded off with a stereo audio jack. This allows

you to use a microphone, speaker, or headset. With the

multifunctional DIGITUS® docking station and integrated keyboard,

you can expand your notebook’s, MacBook®’s or PC’s capabilities.

Note: Not all USB-C™ ports support all functions of the USB-C™

standard.

Make sure that your notebook’s USB-C™ port supports

the DisplayPort™ Alternate Mode (DP Alt Mode) as well as

Power Delivery.

Structure Diagram

Status Indicator:

Lock, Caps, Scroll, Power

HDMI®

Audio

VGA

USB 3.0

USB Type-C™

SD / Micro SD Memory Cards

USB Type-C™ with Power

Delivery (PD) Function

RJ45 Ethernet

Features

1) 10 additional interfaces for your notebook, MacBook® or PC

2) Supports resolutions up to UHD 4K / 30 Hz (HDMI®) or

dual display with Full HD 1080p / 60 Hz (HDMI® + VGA)

3) Extended screen or duplicated screen display possible

(extension / clone

4) Supports Power Delivery 3.0 (100 W max.) to quickly charge your

notebook

5) Plug and Play - no driver installation required

6) Working with up to 3 monitors possible (incl. notebook display)

7) Keyboard layout: QWERTZ (compact, 78 keys)

8) High-quality aluminum housing

9) 1 x USB-C™ connection: USB 3.1 (Gen 2) 10 Gbps SuperSpeed+

10) 1 x USB-C™ connection with Power Delivery 3.0

(charging adapter 100 W max.)

11) 1 x HDMI® connection: UHD 4K / 30 Hz (1080p / 60Hz when used

simultaneously with the VGA connection)

12) 1 x VGA connection: Full HD 1080p / 60 Hz, 1080i, 720p

13) 3 x USB 3.0: SuperSpeed 5 USB, downward compatible

with USB 2.0

14) 1 x Gigabit Ethernet connection: RJ45, 10/100/1000 Mbps

15) 1 x SD- / MicroSD card reader: Supports cards up to 2 TB

16) 1 x audio connection: 3.5 mm jack socket, stereo output and

microphone input

Operating System Support:

Mac OS x. 10.x and future releases

Windows 7/8/10 32 and 64 bit and future release

Note: 1. Keyboard only support Mac os or windows system

2. Press FN+F11 simultaneously lock or unlock the keyboard

Additional Information

Operating Temperature

0°C to +45°C

Operating Humidity

10% to 90 % RH (no condensation)

Storage Temperature

-10°C to +70°C

Storage Humidity

10% to 90 % RH (no condensation)

USB-C PD Charging Port

MAX 100W (20V/3A)

Connection Diagram / Application Example

Headphones

Router

USB Stick

HDMI® Display

HDD / SSD (External Storage)

VGA Display

Mouse

Notebook / PC

SD / Micro SD Memory Cards

Power Supply

Note: 1. For video output, USB-C™ source devices must support

video output

2. Suggest charge for power supply to keep it work stable.

Display setting for Win 10

Rigth click desktop > display settings

Graphics settings for Win 10

1. Clone mode

Right click desktop > graphics seting > display

2. Extended Desktop

Right click desktop > graphic settings > display

Resolution setting for MAC

Apple Logo > System Preferences > Displays

Sound setting for MAC

Apple Logo > System Preferences > Sound
