digicon dGate AW Manual de usuario
dGate Product Manual Version 11
dGate AW
dGate SW
dGate Product Manual - Version 11
2
Revision Date Reviser History
09 06/mar/2020 • Theo Souza;
• Vinicius Duarte;
• Nicholas Hahn;
• Cledisson Escobar;
• Jorge Grass;
• Leandro Dandolini.
• New manual layout;
• New chapter on features of dGate;
• Update of Images.
10 05/jun/2020 • Nicholas Hahn;
• Vinicius Duarte;
• Leandro Dandolini;
• Diogo Zarth.
• Jorge Grass
• New format of the manual;
• Update of information on interconnections
of ;
• Door calibration;
• Review of chapter on safety;
• Review of chapter on installation;
• Update of warranty term.
11 16/nov/2021 • Peter Elbling;
• Leandro Dandolini;
• Juliana Dietrich;
• Jorge Grass;
• Nicholas Hahn.
• New chapter on security;
• New instructions on risk;
• New document layout.
Copyright - Digicon S.A. Controle Eletrônico para Mecânica
All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, translated into any language or computer
language in any electronic, magnetic, optical, chemical, manual way or otherwise,
without the express written permission from Digicon S.A.
Code: 069.31.278
Version: 11 - English
Manual elaborated by: Digicon S.A. Controle Eletrônico para Mecânica
Department of documentation - EDS
“At the end of the product’s life cycle, dispose of it according to National Waste Policies”.
dGate Product Manual - Version 11
3
Revision Date Reviser History
09 06/mar/2020 • Theo Souza;
• Vinicius Duarte;
• Nicholas Hahn;
• Cledisson Escobar;
• Jorge Grass;
• Leandro Dandolini.
• New manual layout;
• New chapter on features of dGate;
• Update of Images.
10 05/jun/2020 • Nicholas Hahn;
• Vinicius Duarte;
• Leandro Dandolini;
• Diogo Zarth.
• Jorge Grass
• New format of the manual;
• Update of information on interconnections
of ;
• Door calibration;
• Review of chapter on safety;
• Review of chapter on installation;
• Update of warranty term.
11 16/nov/2021 • Peter Elbling;
• Leandro Dandolini;
• Juliana Dietrich;
• Jorge Grass;
• Nicholas Hahn.
• New chapter on security;
• New instructions on risk;
• New document layout.
Note: If you want to get the history of all the versions of this manual, get in contact with your representative
or with Digicon.
ATTENTION! Digicon reserves the right to modify the characteristics of its products
at any time to adapt them to latest the technological developments.
.
ATENÇÃO!: Digicon reserves the right to change the information contained in this
manual without prior notice.
dGate Product Manual - Version 11
4
Índice
1. Introduction.............................................................................................................7
2. Safety instructions ..................................................................................................8
2.1 Symbols .......................................................................................................8
2.2 Terminology .................................................................................................9
2.3 Risks .....................................................................................................9
2.3.1 Risk when unpacking the equipment:.............................................10
2.3.2 Risks when installing the equipment: .............................................10
2.3.3 Risks when using the equipment: ..................................................11
2.3.4 Risks when servicing the equipment: .............................................12
2.3.5 Risks when cleaning the equipment...............................................12
3. Characteristics of dGate.......................................................................................13
3.1 Functional description ................................................................................15
4. Unpacking, xing, and power connection.............................................................17
4.1 Opening the package.................................................................................17
4.1.2 Necessary tools:.............................................................................18
4.1.1 Package dimensions: .....................................................................18
4.1.3 Step-by-step for opening the package: ..........................................19
4.1.4 Main parts of the product................................................................22
4.2 Fixing .........................................................................................................24
4.2.1 Prior to installing the dGate, check:................................................24
4.2.2 Positioning and xing to the oor ...................................................25
4.3 Access to the dGate after xation ..............................................................29
4.4. Power connection .....................................................................................30
4.4.1 Electric panel..................................................................................30
dGate Product Manual - Version 11
5
5. Interconnections ..................................................................................................32
5.1 Basic cabling..............................................................................................34
5.3 Connection to power network ....................................................................39
5.2 Connection of control signals ....................................................................40
6. Identication of internal parts and features .........................................................43
6.1 MCP controller board .................................................................................43
6.2 Pictograms .................................................................................................44
6.3 Orientation pictogram (frontal): ..................................................................46
6.4 Anti-panic ..................................................................................................47
6.5 Features.....................................................................................................48
6.5.1. Passage control modes.................................................................48
6.5.1 Setting door speed ........................................................................49
6.5.2 Conguration of access control with doors open. ..........................50
6.5.3 Anti-crush protection system ..........................................................50
6.5.4 Passage timeout.............................................................................51
6.5.5 Detection of passage direction .......................................................52
6.5.6 Detection of user return..................................................................53
6.5.7 Detection of stationery users..........................................................53
6.5.8 Detection of gate invasion ..............................................................54
6.5.9 Detection of tailgating....................................................................55
6.5.10 Denition of asset safety zone .....................................................55
6.5.11 Accumulation of passage clearances ...........................................55
7. Optional items.......................................................................................................57
7.1 Kit Card collecting set ..............................................................................57
7.2 Digicon MCA board ....................................................................................58
dGate Product Manual - Version 11
6
8.Maintenance..........................................................................................................59
8.1 Door ...........................................................................................................59
8.1.1 Calibration routine .........................................................................60
8.2 Defects and possible causes .....................................................................61
9. Preventive maintenance.......................................................................................62
9.1 Preventive actions table:............................................................................62
10.Technical characteristics......................................................................................65
10.1 Dimensions ..............................................................................................65
10.2 Other information ....................................................................................67
11.Cleaning ..............................................................................................................68
11.1 Maintenance and preservation of stainless steel: ....................................68
11.2 Maintenance and preservation of polycarbonate (doors):........................70
12. Warranty and technical assistance.....................................................................72
Observations....................................................................................................73
dGate Product Manual - Version 11
7
1. Introduction
When we combine innovation with robustness, design, and reliability, we nd the best
solution in access control. Digicon presents a solution thought in the smallest details to
bring innovation, quality, and design to the access control market. From an intense research
process on world trends and an exhaustive engineering work, the dGate equipment was
born.
Learn more about our gates by accessing our website, using the QRCode below:
dGate Product Manual - Version 11
8
2. Safety instructions
2.1 Symbols
You will nd the symbols below in the Product Manual. They indicate important Attention
and Caution notices regarding the safety, installation, operation, and maintenance of
the equipment.
ATTENTION!: Describes something important that should be the knowledge
of qualied technical professional and the user.
CAUTION – RISK OF HARM/INJURY!: Describes situations of risk that can
lead to harm and/or injuries.
CAUTION – RISK OF DEATH!: ! Describes high-risk situations that can lead
to death. These cases are related to interaction with the inside of the equipment
and it is advised that you use a qualied technical professional.
Read and keep this manual: Read and keep this Product Manual for future reference.
Read carefully all the instructions of safety, unpacking, installation, operation, and
maintenance prior to operating this equipment.
Follow the instructions and the attention and caution warnings: Follow all the
instructions for installation, operation/use, and maintenance. Pay attention to all the
warnings of attention, caution, and precautions in the operating instructions as well as
those that axed to this equipment. Attention and caution warnings are essential to
protect the user and the qualied technical professional, as well as the longevity of use
of the equipment.
dGate Product Manual - Version 11
9
2.2 Terminology
The terms dened below are used in this document. The denitions are based on what
is found in the safety rules:
Qualied Technical Professional: The term qualied technical professional applies
to persons trained and qualied by Digicon who are permitted to install, replace, or
service your equipment. It is recommended that the qualied technical professional
use their experience, technical skills, and good practice to prevent possible injury
to themselves and others, due to risks that exist in areas of restricted access. This
posture must be taken to mitigate risks and to increase the useful life of the equipment.
ATTENTION! Installation and/or maintenance provided by unqualied
technician can nullify the warranty term of the equipment.
User: The term user applies to persons who are not qualied technical professionals
and who use the equipment.
2.3 Risks
The following safety information and warnings are available to protect you against
injury and prevent damage to the equipment.
Children and people in need of assistance may be unable to assess the risks associated
with the use of equipment and may injure themselves or put themselves in situations
that involve risk of life.
Special attention must also be given to animals that are close to the equipment.
Below, we will mention risks that must be addressed in dierent situations:
dGate Product Manual - Version 11
10
2.3.1 Risk when unpacking the equipment:
ATTENTION!:
• Always use the proper tools
• Always wear the necessary PPE (gloves, shoes, and safety goggles)
CAUTION - RISK OF HARM/INJURY!:
• Be careful when handling the packaging of equipment; it is made of wood and
can splinter;
• The package is heavy; take care that it does not tip over, as it can cause
injuries and also damage to the equipment;
• In the construction of the packaging there are ne blades of steel, which can
cause cuts and injuries;
• Take care to remove the lid of the container, as it may fall causing injury and
damage to equipment;
• To remove the screws that secure the equipment to the base of the package,
the side glass doors must be removed. Handle them with care, leaving them
in a safe place;
• Beware of hands and feet when removing the equipment from the base of the
packaging and placing it in the place of installation.
2.3.2 Risks when installing the equipment:
ATTENTION!:
• All the stages of installation should be performed by a qualied technical
professional who should use the appropriate tools and PPE;
• Prior to connecting the electric power, make a detailed inspection of the
installation.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Torniquete de digicon
digicon
digicon dflow Manual de usuario
digicon
digicon Turnstile Duo Manual de usuario
digicon
digicon CATRAX Plus Manual de usuario
digicon
digicon dGate UW900 Manual de usuario
digicon
digicon Catrax clip Manual de usuario
digicon
digicon catrax master Manual de usuario
digicon
digicon dflow Manual de usuario
digicon
digicon CATRAX Plus Manual de usuario
