Swing Gate User Manual

JKDC-100C

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

1.Product introduction

Swing barrier is generally used in simple dissuasion level access control of public

passages. It is widely used in work attendance checking systems of factories,

consumption systems of public institutions, access control of residential estates,

ticket exit systems of scenic, sports and other arenas, hand-key management

systems of construction sites and so on. The mechanical part of the barrier

contains an emergency

control device, which allows free passage in case of power fail. The turnstile has

different optional configurations for the applications of all building conditions

and for the control of all kinds of passage entrance-exits. Different

identification systems (ID card, IC card, bar-code, hand-key, fingerprint, iris, etc.)

can be configured into the barrier system. The barrier can be connected to any

kinds of controllers and various consumption devices.

2. Features and Functions:

1. SUS304# stainless steel rainproof case

2. LINIX (the best micro-motor brand in China) brush-less DC motor is used and

its surface is plated with dichromate;

3. Length of rotating arm: 500mm-900mm

4. Fault detection and alarm functions, easy to use and maintenance.

5. The running status can be programmed and controlled with the built-in

keyboard on the main board.

6. Mechanical anti-pinch function. If the gate meets resistance in the reset

process, motors will stop working automatically within the prescribed time and

reset again after the default delay (till fully reset).

7. Anti-breakthrough function. The gate is locked automatically until opening

signal received.

8. Synchronization functions(for dual gate equipment).

9. Automatic reset function. Should the user fail to pass within the prescribed

time (default time is 5 seconds), the system will cancel the authority of the

current user automatically.

10. Gate can be set as normally open or normally closed.

11. Can be used with variety of card readers: IC / ID card readers, bar codes,

fingerprints, etc. (Access controller needed)

12. Direction can be set as single-direction or bi-direction.

13. The device can be connected to management computer to realize remote

control and management.

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

14. LED direction indicator.

15. Gate autoopens when power off and autoclose when power on, complying

with fire safety requirements.

16. Alarm function, in case of illegal intrusion and reverse intrusion, etc.

17. Counter function (optional).

18. Support infrared photocell for anti-pinch and reset function.

3. Technical Specifications

4. Control Interface

1) Equipment controlling connection method:

For two-way relay and switch signal:

The COM connect to the VDD from Gate Opening interface,

The NO signal need to connect to the OPE-L(or OPE-R).

For The 12V level signal:

The negative electrode connect to the GND from Gate Opening interface.

The Positive electrode connect to OPE-L(or OPE-R)

2) Pair using must connect the synchronous wires correspondingly, e.g. GND to

GND,OPE-L to OPE-L(6 wires total, the connection must be completely

consistent).

Model

Item

JKDJ-100C

Voltage

AC 220V/110V±10%

Frequency

50/60Hz

Current

Control circuit:

DC24V

Power consumption

40W

Working temperature

-20°C~60°C

Working humidity

0~95%RH

Time of opening or

closing

2.5 seconds

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

Note: Before using, please make sure ground wire connected, prohibit

taking electricity from the main board.

Wiring Diagram

Menu Setting

I. Display and Menu Setting

1. Display refers to the three-digital LED from left to right on the main

Board.

2. Menu Setting include 3 keyswhich are INC key,SET key,DEC key. SET key

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

is used toEnter and Exit menu or function setting; INC key is used to plus

1 at a time to the parameter needs setting; DEC key is used to minus 1 at

a time to the parameter needs setting;

Ⅱ. Enter and Exit Menu Setting

1. Enter menu: Press SET key, loose the key after hearing a sound “du”,

“P00” appears, which indicates the status of menu setting. Now press INC

key Or DEC key to the parameter needs setting: Press INC key to plus 1,

and press DEC key to minus 1. There are 15 kinds of functions as below:

P00: Exit from menu setting, when P00 appears, press SET key to exit menu.

P01: The motor running direction when power on, =000 means clockwise

rotation, and =001 meansanticlockwise rotation.

P02: The longest operation time of barrier.Its measurement is 0.1sec, when we

set itto 60, the time is 6 seconds. If the barrier hasn't closed in 6 sec, it will

automatically stop.(System default is 60)

P03: The passing time, measurement is second. Number 10 means 10 seconds. If

the pedestrian hasn't passed through the gate in pre-set time, the passing

right will be canceled.( System default is 10)

P04: Working mode(System default is 000)

=000 bi-direction swiping card

=001 swipe card enter but free for exit

=002 free for entrybut swipe card exit

=003 free for entry and exit

=004swipe card for entry only (single direction)

=005 swipe card for exit only (single direction)

P05: The speed of barrier gate opening for entry, system default is 10.

P06: The speed of barrier gate closing after entry, system default is 10.

P07: The speed of barrier gate opening for exit, system default is 10

P08: The speed of barrier gate closing after exit, system default is 10.

P09: Pedestrian who pass through the channel in the pre-set time will be

regarded as one person, system default is 10.

P10: Counter clear for entry , when it displays P10, press SET Key, then it

displays O-L, press INC Key to clear the counter.

P11: Counter clear for exit, when it displays P11, press SET Key, then it displays

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

O-L, press INC Key to clear the counter.

P12: Memory function setup (system default is 000)

=000: with memory for entry and exit

=001: with memory for exit only

=002: with memory for entry only

=003: without memory for entry and exit

P13: Equipment communication address, namely set a identification number for

all the mechanism. Number range from 1-255. (System default is 001)

P14: Equipment types

=000: Swing barrier

=001: Flap barrier

P15: System reset, when it displays P15, press SET Key, then it will display P-2,

press INC Key to reset system.

5. Decorative Facing Cover:

For standard bridge-type swing barrier, two decorative facing covers are

installed at each side of the housing. The covers are made by 10mm thick PVC

materials.

On the standard decorative cover; the words “Please put in your card here”are

printed using silk-screen printing method. The background of the decorative

cover is white, and other words can also be printed as may be required by

customers. The system integrator can install different user interfaces according

to the users requirements, such as IC card reader, magnetic card reader,

fingerprint scanner, status indicating light, exit button equipment, etc.

6. Operating Instructions

The Swing Barrier has two different operating modes:

1) Always Free Passing (Barrier Free Passage)

2) Electric Driving Entry Control (Intelligent Passage through Identification by

means of IC, ID, Bar-code, etc.)

Each of the above two operating modes has an emergency design: when there is

a power failure, the two wings of the Flap Barrier will automatically open to

ensure free passage through it.

The two-way operating modes are specifically defined by the above code and

have something to do with the operation selected.

7. Work to be carried out by the Customer

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

Single-Phase 5A 220V power supply, grounded to the connecting line of the

control equipment. (Connect the controllers’ dry contact (or level) control signal

to PASS1 or PASS2)

1) Civil Engineering Works:

Use GB (Chinese Standard) 405# Portland cement concrete to build foundation

with thickness from 10CM to 15CM. The installation can be carried out five to

seven days after the concrete foundation is built.

2) Fixation

The swing barrier base plate can be opened. There are four 12mm holes inside

the base. Use four 8mm*10mm expansionbolts to fix the base.

Unit: mm

9. Service Commitments

1) Prepurchase Service:

A) Offer users counselor and consultant service related to the turnstile.

B) On the basis of comprehensive consideration of the specific layout,

environment and power supply conditions, propose reasonable design schemes

to customers, striving for best price value.

2) Sales Service:

A) Assemble and adjust the equipment system to reach the best conditions.

B) Offer free training to users to help them establish the ideas of properly using

the equipment and offering service.

Help users to establish a management system for the turnstile system.

3) Aftersales Service:

A) Supply various consumable materials.

B) Periodically carry out inspection by telephone calls and provide advice and

maintenance.

C) The warranty period of the turnstile is one year after installation. Lifetime

maintenance will be provided after the one year warranty period expires. Once

there is any failure arising during the operation of the equipment, please dial our

service phone number for technical advice; If the problem cannot be solved

through telephone call, our company shall, when considered as necessary under

the circumstances, send technical personnel to the site to carry out maintenance

and repair. (The traveling cost shall be borne by the user)

Aftersales Service Hot-line: +86-755-28408621

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

Product Warranty Card

Warranty No.:

Product Description:

Product Model:

Manufacturing Date:

Product Serial No.:

Warranty Period: Refer to the

Following Service

Commitments:

Purchase Date:

To be

Filled in

by the

Custome

Name of

Customer:

Company Name:

Tel:

Post Code:

Email:

Fax:

Address of Customer:

Seal

Seller

Name of Agency or Distributor:

Tel:

Address

Dear Customer:

Thanks a lot for your selection of our company’s products. Our company not only

provides quality products, but also offers superior aftersales service support. If

any question arises in the operation, please call the service support hot-line of

our company. Our engineer will be glad to answer your questions. Thanks again

for your trust in and support to our company and our product.

Our company offers one year warranty for the sold products:

Rules of Warranty

A) The one year warranty covers any failure due to manufacturing factors

provided the product is used under normal conditions (except as stipulated

otherwise by the warranty card). The warranty does not cover housing,

accessory and consuming parts. In case a failure of any of the above products

takes place, our company shall provide service under warranty to the products

with failure and the service shall be free of charge.

B) To receive service under warranty: The customers shall notify the customer

service agency of our company before the warranty expires and shall present

金科达诚安检设备有限公司

J K D C S E C U R I T Y C O L I M I T E D

Add: Jinkedacheng Science Park,N0.59 Xinhe Road,Shangmugu,Pinghu Town,

Longgang District,Shenzhen City,GuangDong Province,China

Web: http://www.securityjkdc.com Tel: +86 755-28408621

valid warranty card when requesting service under warranty.

C) The following circumstances are not covered by the warranty:

a) Any damage or failure incurred by disasters/accidents (such as: fire,

earthquake, etc);

b) Any failure arising from improper operation not satisfying requirements, or

from use under unaccepted working environment and conditions;

c) Any failure arising from the repair, or replacement /adding of parts of the

products by any person not authorized by our company;

d) Any damage (such as finish damage) arising from improper transportation

after delivery.

D) Our company denies any other commitments of any form not recognized by

our company. Our company is only responsible for repairing or replacing as per

related stipulations the product with failure certified here-under.

Otros manuales de Torniquete de JKDC SECURITY

JKDC SECURITY

JKDC SECURITY JKDJ-120C Manual de usuario

Manuales populares de Torniquete de otras marcas

Oxgard

Oxgard CUBE C-10 Manual de usuario

LBA GROUP

LBA GROUP LBAT10 Manual de usuario

Magnetic

Magnetic mTripod Manual de usuario

Kaba

Kaba Argus HSG-E02 Manual de usuario

Automatic Systems

Automatic Systems TR491 Manual de usuario

Turnstiles

Turnstiles HZ-SWGS01 Manual de usuario

DSI

DSI DST-80 Manual de usuario

OZAK

OZAK VP-125 Manual

Automatic Systems

Automatic Systems SMARTLANE SL 90X Manual de usuario

Alvarado

Alvarado MT Instrucciones de instalación y funcionamiento

Alvarado

Alvarado SU5000 Manual de usuario

Magnetic Autocontrol

Magnetic Autocontrol MPT 33 Manual de usuario

Oxgard

Oxgard Praktika T-04K Guía de inicio rápido

digicon

digicon CATRAX Plus Manual de usuario

Oxgard

Oxgard CUBE C-04-s Manual de usuario

BOON EDAM

BOON EDAM Turnlock 100 Guía

Wano

Wano Tripod BO-DSN10 Manual de usuario

Timewatch

Timewatch TWLD-TS2700 Manual de usuario
