Digi XLR PRO Manual de usuario

XLR PRO®

Radio Frequency (RF) Module

User Guide

PRELIMINARY DRAFT

Disclaimers

Information in this document is subject to change without notice and does not represent a commitment on

the part of Digi International. Digi provides this document “as is,” without warranty of any kind, expressed or

implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular

purpose. Digi may make improvements and/or changes in this manual or in the product(s) and/or the

program(s) described in this manual at any time.

Trademarks and Copyright

Digi, Digi International, the Digi logo, and XLR PRO are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the property of

their respective owners.

Customer Support

If you need assistance, contact technical support:

• Telephone (8:00 am - 5:00 pm—U.S. Mountain Time):

(866) 765-9885 toll-free U.S.A. & Canada

(801) 765-9885 Worldwide

• Fax:

952-912-4952

• Online:

www.digi.com/support/eservice/

• Email:

[email protected]

XLR PRO Radio Frequency Module User Guide

Part Number 90001407

Revision Date Description

P1 April 2014 Preliminary draft.

PRELIMINARY DRAFT

XLR PRO Radio Frequency Module User Guide 3

Contents

About the XLR PRO Radio Frequency (RF) Module

XLR PRO RF Module Technical Specifications 5

XLR PRO RF Module Receiver Sensitivity 6

XLR PRO RF Module Pin Signals 6

XLR PRO RF Module Data Rates 9

XLR PRO Certifications

FCC (United States) Certification 11

FCC Labeling Requirements 11

FCC Notices 12

FCC Limited Modular Approval 12

FCC-Approved Antennas 12

IC (Industry Canada) Certification 13

IC Labeling Requirements 13

XLR PRO Approved Antennas

Omni-Directional Antennas 15

Yagi Antennas 16

PRELIMINARY DRAFT

4 XLR PRO Radio Frequency Module User Guide

PRELIMINARY DRAFT

XLR PRO Radio Frequency Module User Guide 5

About the XLR PRO Radio Frequency

(RF) Module

The XLR PRO Application Name is a high performance, industrial grade long-range RF

solution using Chirp Spread Spectrum (CSS) technology to maximize range and

significantly increase immunity to interference.

XLR PRO Application Name Technical Specifications

Specification Description

Transmit Power (Software Selectable) 30 dBm (highest power level)

Receiver Sensitivity Up to -120 dBm (see XLR PRO RF Module

Receiver Sensitivity on page 6)

Throughput Data Rate (Software

Selectable)

TBD

RF Data Rate 9 kbps to 3.1 Mbps

Networking and Security

Transmission Chirp Spread Spectrum (CSS)

Modulation Quadrature Phase Shift Keying (QPSK)

Supported Network Topologies Point-to-point, Point-to-multipoint, Broadcast

repeater

Interface Serial CMOS UART and I/O lines

Encryption 128bit AES

Power Requirements

Supply Voltage 3.8 to 5.5VDC

Note Operation below 4.5V may reduce radio

transmit power performance and LNA

sensitivity.

PRELIMINARY DRAFT

6 XLR PRO Radio Frequency Module User Guide

XLR PRO RF Module Receiver Sensitivity

XLR PRO Application Name Pin Signals

Receive Current 295 mA at 5 V

Transmit Current 1.5 A at 5 V

Shutdown Mode Power Down 3 μA

Environmental

Operating Temperature -40 C to 70 C

Certifications

FCC ID MCQ-XLRP (pending)

IC 1846A-XLRP (pending)

Hazardous Locations C1D2 (pending)

Specification Description

Data Rate

Receiver Sensitivity (25°C)

(dBm)

9 kbps -120

28 kbps -119

65 kbps -116

140 kbps -113

290 kbps -109

590 kbps -106

1.1 Mbps -104

2.3 Mbps -100

3.1 Mbps -98

Pin # Name Description

1 Reserved Do not connect

2 Reserved Do not connect

3 Reserved Do not connect

PRELIMINARY DRAFT

XLR PRO Radio Frequency Module User Guide 7

XLR PRO Application Name Pin Signals

4 Reserved Do not connect

5 GND Ground

6 VDD-5V Power Supply

7 Reserved Do not connect

8 Reserved Do not connect

9 Reserved Do not connect

10 Reserved Do not connect

11 VDD-5V Power Supply

12 GND Ground

13 3.3V_OUT Regulated Output Voltage from VDD_5V.

Controlled by nSHUTDOWN.

14 3.3V_IN Voltage Supply for the Primary Processor

and the I/O Voltages

15 3.3V_ADJUST Voltage Control of 3.3V_OUT

16 nRESET Module Reset

17 Reserved Do not connect

18 DIO0/AD0/CommBtn GPIO/Analog Input/Commissioning Button

19 Reserved Do not connect

20 DIO1/AD1 GPIO/Analog Input

21 Reserved Do not connect

22 DIO2/AD2 GPIO/Analog Input

23 Reserved Do not connect

24 DIO1/AD1 GPIO/Analog Input

25 Reserved Do not connect

26 DIO4 GPIO

27 Reserved Do not connect

28 DIO5/ASSOC GPIO/Associate Indicator

29 DIO19/SPI_nATTN GPIO/SPI Attention

Pin # Name Description

PRELIMINARY DRAFT

8 XLR PRO Radio Frequency Module User Guide

30 DIO8/nDTR/SLP_RQ GPIO/Pin Sleep Control Line

31 DIO17/SPI_nSSEL GPIO/SPI Slave Select

32 DIO9/ON_nSLEEP GPIO/Module Status Indicator

33 DIO16/SPI_SI GPIO/SPI Slave In

34 VREF Used internally used for programmable

secondary processor. For compatibility with

other XLR modules, we recommend

connecting this pin to the voltage reference if

Analog Sampling is desired. Otherwise,

connect to GND.

35 DIO15/SPI_SO GPIO/SPI Slave Out

36 DIO10/PWM0/RSSI/DAC0 GPIO/RX Signal Strength Indicator

37 DIO18/SPI_CLK GPIO/SPI Clock

38 DIO11/PWM1/DAC1 GPIO/Pulse Witdh Modulator

39 DIO7/nCTS GPIO/Clear-to-Send Flow Control

40 DIO12/CD/PWM2/ADTRG GPIO/Pulse Width Modulator

41 DIO6/nRTS GPIO/Request-to-Send Flow Control

42 GND Ground

43 DIO13/DOUT UART Data out

44 Reserved Do not connect

45 DIO14/DIN/nConfig UART Data in

46 nSHUTDOWN Module Shutdown

47 GND Ground

48 VDD_5V Power Supply

49 Reserved Do not connect

50 Reserved Do not connect

51 Reserved Do not connect

52 Reserved Do not connect

Pin # Name Description

PRELIMINARY DRAFT

XLR PRO Radio Frequency Module User Guide 9

XLR PRO Application Name Data Rates

RF Baud Rate

Setting

Raw Data Rate

9605 Mhz BW (Kbps)

0x00 9.380

0x01 12.50

0x02 28.14

0x03 37.52

0x04 65.66

0x05 87.55

0x06 140.7

0x07 187.6

0x08 290.8

0x09 387.7

0x0A 590.9

0x0B 787.8

0x0C 1191

0x0D 1588

0x0E 2392

0x0F 3189

PRELIMINARY DRAFT

10 XLR PRO Radio Frequency Module User Guide

PRELIMINARY DRAFT
