SERVICE MANUAL

IFT-22132 INFOTAG 2.13 (BW/R)

IFT-22132

Table of Content

i) Notice.................................................................................................................................................1

ii) Safety Information..............................................................................................................................2

iii) Safety Regulations.............................................................................................................................2

1. General.............................................................................................................................................................5

1.1 Model Specification............................................................................................................................5

2. Dimension........................................................................................................................................................6

3. IFT-22132 Setup Diagram & Spec Setting ....................................................................................................7

3.1Overall Layout and Label design.........................................................................................................7

3.2Exploded View.......................................................................................................................................8

3.3 Replacement of Info Tag Battery..........................................................................................................9

3.4Button Cell Specifications......................................................................................................................9

3.5 ESL Attachment (Refer to ESL Attachment Catalogue).......................................................................9

3.6 Product Handling of Info Tag...............................................................................................................10

4. Revision Records..........................................................................................................................................11

i) Notice

DIGI®

The material contained in this document is proprietary and for information only and is subject to change without

notice. Teraoka Weigh-System assumes no responsibility for any errors or damages arising from

misinterpretation of any procedure.

Screen displays, operating procedures and supporting features might vary with different software version

releases.

This document shall not be reproduced whether in part or whole without the written consent from Teraoka

Weigh-System Pte Ltd.

Teraoka Weigh-System Pte Ltd

4, Leng Kee Road

#06-01 SIS Building

Singapore 159088

ii) SafetyInformation

The operator of the equipment shall comply with the safety and warning indications and procedures outlined in

this document. Teraoka Weigh-System Pte Ltd assumes no responsibility or liability for failure to comply with

these requirements.

Repair and servicing of product, shall only be carried out by trained and qualified personnel.

Disclaimer:

Specifications are subject to change without notice. All dimensions shown are approximate. Please be aware

that Teraoka has indicated that its hardware and software used in the product may require additional updates in

the future as our product is continually under development. The need for such updates most likely applies to the

Printer software.

CAUTIONS:

FOR PLUGGABLE EQUIPMENT, THAT THE SOCKET-OUTLET SHALL BE INSTALLED NEAR THE

EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.

POUR LE MATÉRIEL RACCORDÉ PAR PRISE DE COURANT, LE SOCLE DE PRISE DE

COURANT DOIT ÊTRE

INSALLÉ À PROXIMITÉ DU MATÉRIEL ET DOIT ÊTRE AISÉMENT ACCESSIBLE.

FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE

AND RATING OF FUSE.

POUR NE PAS COMPROMETTRE LA PROTECTION CONTRE LES RISQUES D’INCENDIE,

REMPLACER PAR UN FUSIBLE DE MÊME TYPE ET DE MÊME CARACTÉRISTIQUES

NOMINALES.

DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH

THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD

USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS

IL Y A DANGER D’EXPLOSION S’IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE.

REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D’UN TYPE

RECOMMANDÉ PAR LE CONSTRUCTEUR. METTRE AU RÉBUT LES BATTERIES USAGÉES

CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT.

iii) SafetyRegulations

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

IDA Compliance Statement: (Singapore)

This equipment registered to comply with IDA (Info-Communications Development Authority of Singapore)

Standard under Dealer’s Class License.

Industry Canada statement:

This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two

conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may cause undesired operation of the

device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de

licence. L’exploitation est autorisée aux deux conditions suivantes:

1) l’appareil ne doit pas produire de brouillage;

2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d’en compromettre le fonctionnement.

IMPORTANT NOTE:

Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End users

must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance

with IC RF exposure compliance requirements, please follow operation instruction as documented in this

manual.

Cet équipement est conforme avec l'exposition aux radiations IC définies pour un environnement non contrôlé.

Les utilisateurs finaux doivent suivre les instructions de fonctionnement spécifiques pour satisfaire la conformité

aux expositions RF. Pour respecter les exigences de conformité d'exposition RF IC, s'il vous plaît suivez les

instructions d'utilisation documenté dans ce manuel.

Actual size

9mm (H) x 17mm (W)

For Taiwan 警語：

第十二條→經型式認證合格之低功率射頻電機，非經許可，公司，商號或使用者均不得擅自變

更頻率、加大功率或變更原設計之特性及功能。

第十四條→低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，

應立即停用，並改善至無干擾時方得繼續使用。

前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工

業、科學及醫療用電波輻射性電機設備之干擾

IFT-22132 Service Manual

1. General

1.1 Model Specification

Model

IFT-22132

Dimensions (in mm)

Infotag 2.13 (BW/R)

65.4 (L) X 39.0 (H) X 15.3 (W)

LCD Size

59.2mm x 29.2mm x 1.05mm

Display Window

50.4mm x 25.6mm

LCD Resolution

212 x 104 dots (Dpi: 111)

Weight

26g approx.

Power Source

DC Cell Button Battery 3.0V x 1

Operating Temperature

0 °C to + 40 °C

Humidity

85% Max. Non-condensing

IP Rating

TBA

Housing material

PC plastic casing, PC battery cover

Battery Specification

Type

CR2450 (Cell Button Battery)

Nominal Voltage

3.0V

Life Time

5 years (2 update/day)

Weight

6.6g approx.

IFT-22132 Service Manual

2. Dimension

IFT-22132

IFT-22132 Service Manual

3. IFT-22132 Setup Diagram & Spec Setting

3.1Overall Layout andLabeldesign

IFT-22132

Front View

Back View

IFT-22132 Service Manual

3.2ExplodedView

IFT-22132

Front Cover

LCD & PCBA

Back Cover

Battery Cover

Battery

Battery cover
