INSTALLATION and SERVICE INSTRUCTIONS

D 90 G

Professional

COOKER

USE and CARE INSTRUCTIONS

distributed by Industries Ltd

PPAA

AARR

RREE

EEXX

Dear Customer,

Thank you for having purchased and given your

preference to our product.

The safety precautions and recommendations reported

below are for your own safety and that of others. They

will also provide a means by which to make full use of

the features offered by your appliance.

Please keep this booklet in a safe place. It may be

useful in future, either to yourself or to others in the

event that doubts should arise relating to its operation.

This appliance must be used only for the task it has

explicitly been designed for, that is for cooking

foodstuffs. Any other form of usage is to be considered

as inappropriate and therefore dangerous.

The manufacturer declines all responsibility in the

event of damage caused by improper, incorrect or

illogical use of the appliance or be faulty installation.

PRODUCT LABEL

FIRST TIME USE THE OVEN

It is advised to follow these instructions:

■Clean the interior of the oven with cloth soaked in water and detergent (neutral)

then dry carefully.

■Fit the wire racks as described at chapter “Use and care”.

■Insert shelves and tray.

■Switch on the empty oven on max to eliminate grease tracks from the heating

elements.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR

USE OF ELECTRICAL APPLIANCES

Use of any electrical appliance implies the necessity to follow a series of fundamental

rules. In particular:

■Never touch the appliance with wet hands or feet;

■do not operate the appliance barefooted;

■do not allow children or other incapable people to use the appliance

without supervision.

The manufacturer cannot be held responsible for any damages caused by improper,

incorrect or illogical use of the appliance.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS

After having unpacked the appliance, check to ensure that it is not damaged.

In case of doubt, do not use it and consult your supplier or a professionally qualified techni-

cian.

Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not

be left around within easy reach of children, as these may cause serious injuries.

■Do not attempt to modify the technical characteristics of the appliance as this

may become dangerous to use.

■Do not carry out cleaning or maintenance operations on the appliance without

having previously disconnected it from the electric power supply.

■After use, ensure that the knobs are in off position.

■Do not allow children or other incapable people to use the appliance without

supervision.

■During and after use of the cooker, certain parts will become very hot. Do not

touch hot parts.

■Keep children away from the cooker when it is in use.

■Some appliances are supplied with a protective film on steel and aluminium parts.

This film must be removed before using the appliance.

■Fire risk! Do not store flammable material in the oven, and in the accessory

drawer.

■Make sure that electrical cables connecting other appliances in the proximity of

the cooker cannot come into contact with the hob or become entrapped in the

oven door.

■Do not line the oven walls with aluminium foil. Do not place baking trays or the

drip tray on the base of the oven chamber.

■The manufacturer declines all liability for injury to persons or damage to property

caused by incorrect or improper use of the appliance.

■IMPORTANT NOTE: This appliance shall not be used as a space

heater, expecially if installed in marine craft or caravans.

INSTALLATION

CAUTION:

■

This appliance must be installed in accordance with these installation

instructions, local gas fitting regulations, municipal building codes,

water supply regulations, electrical wiring regulations, AS5601 / AG 601

- Gas Installations and ony other relevant statutory regulations.

■

This appliance shall be only be serviced by authorized personnel.

■

This appliance is to be installed only by an authorised person.

■

Incorrect installation, for which the manufacturer accepts no

responsibility, may cause personal injury of damage.

■

Always disconnect the cooker from mains power supply before carrying

out any maintenance operations or repairs.

■

In the room where the cooker is installed, there must be enough air to

allow the gas to burn correctly, according to the current local

regulations.

ELECTRICAL REQUIREMENTS

■The appliance must be connected to the mains checking that the voltage

corresponds to the value given in the rating plate and that the electrical

cable sections can withstand the load specified on the plate.

■The plug must be connected to an earthed socket in compliance with safety

standards.

■If the appliance is supplied without plug, fit a standard plug which is

suitable for the power consumed by the appliance.

■The appliance must be connected directly to the mains placing an omnipolar

switch with minimum opening between the contacts of 3 mm between the

appliance and the mains.

■The power supply cable must not touch the hot parts and must be

positioned so that it does not exceed 50°C above ambient.

■Once the appliance has been installed, the switch or socket must always be

accessible.

■

If the power supply cable is damaged it must be substituted by a suitable

cable according to current electrical regulations.

N.B. The connection of the appliance to earth is mandatory.

If the installation requires alterations to the domestic electrical system call a qualified

electrician.

He should also check that the socket cable section is suitable for the power drawn by

the appliance.

Replacing the power cord must be done by a qualified electrician in

accordance with the instructions supplied by the manufacturer and in

compliance with established electrical regulations.

CLEARANCES

Installation clearances and protection of combustible surfaces shall comply with

the requirements of AS5601 / AG 601 - Gas installation.

Installation shall comply with the Dimension in Fig 1 bearing in mind that

Overhead Clearances

In no case shall the clearances between the highest part of the cooker be less

than 600mm or for an ovehead exhaust fan 750mm. AII other downward facing

combustible surfaces less than 600mm above the cooker surface shall be protected

for the full width of the cooking surface in accondance with the standards noted

above. In no case shall the clearance be less than 450mm

Side Clearances

Where the dimensions from the periphery of the nearest burner to any vertical

combustible surface is less than 200mm the surface shall be protected in

accordance with the standards to a height of not less than 150mm above the

cooking surface for the full width or depth of the cooking surface

Protection of combustible surfaces.

The standards above specify that where required protection shall ensure that the

surface temperature of the combustible surface does not exceed 50°C above room

temperature.

Figure 1

450 mm

300 mm

650 mm

500 mm

Figure 2

ANTI-TILT BRACKET

Fixing the anti-tilt bracket:

■After you have located where the cooker is to be positioned mark, on the wall, the

place where the 2 screws of the anti-tilt bracket have to be fitted. Please follow the

indications given in the drawing below.

■Make two holes of diameter 8mm diameter on the wall and insert the plastic plugs.

■Attach the anti-tilt bracket loosely by means of 2 screws.

■Move the cooker to the wall and adjust the height of the anti-tilt bracket so that it can

engage in one slot of the cooker back.

■Attach the anti-tilt bracket tight.

■Push the cooker against the wall so that the anti-tilt bracket is fully inserted in one slot

of the cooker back.

ASSEMBLING THE BACKGUARD

1. Insert the side supports S and D into the backguard B (see fig. 3)

2. Insert the backguard group into the support guides in the cooker

3. The backguard can be removed for cleaning or fixed with a screw through the

hole C.

Identification

label

When you open the

bottom oven door the

indentification label is

at the bottom right

hand side.

Figure 3

USE and CARE

CAUTION:

■This appliance must be used only for the task it has explicitly been designed for,

that is for cooking foodstuffs. Any other form of usage is to be considered as

inappropriate and therefore dangerous.

■Do NOT place combustible materials or products on this appliance at any time.

■Do NOT spray aerosols in the vicinity of this appliance while it is in use.

USING THE OVEN FOR THE FIRST TIME

■Clean the inside of the oven with a cloth soaked in water and neutral detergent

and dry thoroughly.

■Slide in the catalytic liners and wire racks on the oven wall as in Fig. 4. Position

the shelf and tray as per Fig. 5.

■To eliminate traces of grease in manifacture it is necessary to pre-heat the oven

at the maximum temperature, for 60 minutes in the position, for 30 minutes

in the position and for another 15 minutes in the position.

Figure 4 Figure 5
