Dell P2016 Manual de usuario

Model: P2016

Regulatory model: P2016t/P2016b

Dell P2016 Monitor

User’s Guide

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other jurisdictions.

All other marks and names mentioned herein may be trademarks of their respective companies.

2015 – 06 Rev. A00

Contents

About Your Monitor ..................................... 5

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Monitor Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

LCD Monitor Quality and Pixel Policy. . . . . . . . . . . . . . . . . . . . . . 18

Setting Up the Monitor.................................. 19

Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Connecting Your Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Organizing Your Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Attaching the Cable Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Removing the Monitor Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Wall Mounting (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Operating the Monitor .................................. 25

Turning on the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Using the Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 25

Using the On-Screen Display (OSD) Menu . . . . . . . . . . . . . . . . . . . 27

Using the Tilt, Swivel, and Vertical Extension . . . . . . . . . . . . . . . . . 40

Contents | 3

4| Contents

Troubleshooting .......................................43

Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Product Specific Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Universal Serial Bus (USB) Specific Problems . . . . . . . . . . . . . . . . . 47

Appendix ..............................................48

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

FCC Notices (U.S. only) and Other Regulatory Information . . . . . . . . 48

Contacting Dell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Setting Up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

About Your Monitor | 5

About Your Monitor

Package Contents

Your monitor ships with the components shown below. Make sure that you have

received all the components and contact Dell if something is missing.

NOTE: Some items may be optional and may not ship with your monitor.

Somefeatures or media may not be available in certain countries.

NOTE: To set up with any other stand, please refer to the respective stand setup

guide for setup instructions.

Monitor

Stand

Cable cover

Power cable (varies by country)

6| About Your Monitor

DisplayPort cable

USB upstream cable (enables the

USB ports on the monitor)

•Drivers and documentation media

•Quick Setup Guide

•Safety and Regulatory Information

Product Features

The Dell P2016 flat panel display has an active matrix, thin-film transistor (TFT), liquid

crystal display (LCD), and LED backlight. The monitor features include:

• 49.40 cm (19.45 inch) active area display (Measured diagonally) 1440 x 900

resolution, plus full-screen support for lower resolutions.

• Tilt, swivel, vertical extension and rotate adjustment capabilities.

• Removable pedestal and Video Electronics Standards Association (VESA™) 100 mm

mounting holes for flexible mounting solutions.

• Plug and play capability if supported by your system.

• On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

• Software and documentation media includes an information file (INF), Image

color Matching File (ICM), Dell Display Manager software application and product

documentation. Dell Display Manager included (comes in the CD attached with the

monitor).

• Security lock slot.

• Stand lock.

• Asset Management Capability.

• Energy Star Compliant.

• EPEAT Gold Compliant.

• RoHS compliant.

• BFR/PVC-free (excluding external cables).

• Arsenic-Free glass and Mercury Free for Panel only.

• Energy Gauge shows the energy level being consumed by the monitor in real time.

• TCO Certified Displays.

• Analog backlight dimming control for flicker free display.

About Your Monitor | 7

Identifying Parts and Controls

Front view

Label Description

1Function buttons (For more information, see Operating the Monitor)

2Power on/off button (with LED indicator)

8| About Your Monitor

Back View

Label Description Use

1VESA mounting holes

(100mmx100mm - behind

attached VESA cover)

Wall mount monitor using

VESA-compatible wall mount kit

(100mmx100mm).

2Regulatory label Lists the regulatory approvals.

3Stand-release button Release stand from monitor.

4Security-lock slot Secures monitor with security lock

(sold separately).

5Barcode serial number label Refer to this label if you need to contact

Dell for technical support.

NOTE: Service tag printing (EMEA region

only).

6Dell Soundbar mounting slots Attaches the optional Dell Soundbar.

NOTE: Please remove the plastic strip

covering the mounting slots before

affixing the Dell Soundbar.

7Cable-management slot Use to organize cables by placing them

through the slot.

About Your Monitor | 9

Bottom View

Label Description Use

1Stand lock Lock the stand to the monitor using a M3 x 6 mm

screw (screw not included).

2AC power connector To connect the monitor power cable.

3DP connector Connect your computer with DP cable.

4VGA port Connect your computer with VGA cable (optional).

5USB upstream port Connect the USB cable to your computer and the

monitor to enable the USB ports on the monitor.

6USB downstream ports (2) Connect USB devices.

NOTE: You must connect the USB upstream cable

to the monitor and your computer to be able to use

these ports.

10 | About Your Monitor

Monitor Specifications

Flat Panel Specifications

Screen type Active matrix - TFT LCD

Panel type In-plane switching type

Viewable image:

Diagonal 49.40 cm (19.45 inches)

Active Area:

Horizontal 418.61 mm (16.48 inches)

Vertical 262.35 mm (10.33 inches)

Area 109821.81 mm2(170.22inch2)

Pixel pitch 0.2915 mm x 0.2915 mm

Viewing angle:

Horizontal 178° (typical)

Vertical 178° (typical)

Luminance output 250 cd/m² (typical)

Contrast ratio 1000:1 (typical)

Dynamic contrast ratio 2,000,000:1

Faceplate coating AG type, hard-coating 3H

Backlight LED

Response time 6ms Typ. g-to-g with OD (Fast mode)

Color depth 16.7 million colors

Color gamut (typical) 72%* (CIE1931)

*Color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.

Resolution Specifications

Horizontal scan range 30 kHz to 83 kHz (automatic)

Vertical scan range 56 Hz to 76 Hz (automatic)

Maximum preset resolution 1440x900 at 60 Hz

Video display capabilities

(DP playback)

480i, 576i, 480p, 576p, 720p,
