Dell OptiPlex 5080 Micro Manual de usuario

OptiPlex 5080 Micro Dust Filter

Install Guide

November 2020

Rev. A00

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid

the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

trademarks may be trademarks of their respective owners.

Chapter 1: Before you begin ......................................................................................................... 4

Chapter 2: Dust Filter for OptiPlex Micro...................................................................................... 5

Chapter 3: After installing the accessory.......................................................................................6

Chapter 4: Getting help................................................................................................................. 7

Contacting Dell..................................................................................................................................................................... 7

Contents

Contents 3

Before you begin

Steps

1. Save and close all open files and exit all open applications.

2. Shut down your system: Click Start > Power > Shut down .

NOTE: If you are using a Linux operating system, see the documentation of your operating system for shut-down

instructions.

3. Disconnect your system and all attached devices from their electrical outlets.

4. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and monitor from your system.

CAUTION: To disconnect a network cable, first unplug the cable from your system and then unplug the cable

from the network device.

5. If the system unit or the adapter is being installed on the monitor:

a. Disconnect the power and all the display cables from the monitor.

b. Remove the stand from the monitor and place the monitor on a clean and soft surface.

4 Before you begin

Dust Filter for OptiPlex Micro

The dust filter for the OptiPlex 5080 Micro helps protect the system from fine dust particles. After installation, you can set a

pre-boot reminder in the BIOS to clean or replace the dust filter at customized time interval using the interval setting in the

BIOS.

Steps

1. Follow the instructions in before you begin.

2. Align the top edge of the dust filter with the top edge of the system.

3. Press the lower edge of the dust filter to close over the system.

4. Gently press down to ensure that the filter fits snugly onto the system.

5. Follow the instructions in after installing the accessory.

6. Restart the system and press F2 at the Dell splash screen to enter the BIOS Setup menu.

7. In the BIOS Setup menu, go to System Configuration > Dust Filter Maintenance and select from any of the following

intervals: 15, 30, 60, 90, 120, 150, or 180 days.

NOTE: Default setting: Disabled.

NOTE: Alerts are generated only during a system reboot and not during normal operating system operation.

NOTE: To clean the dust filter, brush or gently vacuum and then wipe down the external surfaces with a moist cloth.

Dust Filter for OptiPlex Micro 5

After installing the accessory

Steps

1. Replace all screws and ensure that no stray screws remain.

2. Connect any external devices, peripherals, or cables you removed before working on your system.

3. Connect your system and all attached devices to their electrical outlets.

4. Turn on your system.

6 After installing the accessory

Getting help

Topics:

•Contacting Dell

Contacting Dell

Prerequisites

NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing

slip, bill, or Dell product catalog.

About this task

Dell provides several online and telephone-based support and service options. Availability varies by country and product, and

some services may not be available in your area. To contact Dell for sales, technical support, or customer service issues:

Steps

1. Go to Dell.com/support.

2. Select your support category.

3. Verify your country or region in the Choose a Country/Region drop-down list at the bottom of the page.

4. Select the appropriate service or support link based on your need.

Getting help 7
