Dell Dimension 4600C Manual de usuario

CAUTION:

Before you set up and operate your Dell™ computer, read and

follow the safety instructions in your Owner's Manual.

www.dell.com |support.dell.com Continued

09Y560A03

Set Up Your Computer First

Options for connecting the monitor - VGA→VGA

If your monitor has a VGA connector and the optional video

card is not present, connect your monitor to the integrated

video connector.

VGA→DVI

If your monitor has a VGA connector and the optional video card

is present, connect your monitor to the optional video card

connector using the DVI adapter (included).

DVI→DVI

If your monitor has a DVI connector, connect your monitor to the

optional video card connector.

If you have a modem, connect a telephone cable to either of the modem

connectors (not all modems have two connectors).

Connect a keyboard and a mouse.

Connect the computer and monitor to electrical outlets.

See your

Owner’s Manual

for instructions on attaching the stand.

The screw is attached to the bottom of the stand.

If you have a network device, connect a network cable to the

network connector.

PS/2

USB

optional video card

integrated video

VGA adapter DVI

9Y560am3.qxd 9/18/2003 4:13 PM Page 1

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly

forbidden.

Dell and the DELL logo are trademarks of Dell Inc.; Microsoft and Windows are registered

trademarks of Microsoft Corporation. Dell disclaims proprietary interest in the marks and names

of others.

August 2003

See your

Owner's Manual

for additional setup instructions,

including how to connect a printer.

To access support and educational tools, double-click the

DDeellllSSoolluuttiioonnCCeenntteerricon on the Microsoft® Windows®desktop.

You can also access Dell through ssuuppppoorrtt..ddeellll..ccoomm.

For additional information about your computer, click the

SSttaarrttbutton and click HHeellppaannddSSuuppppoorrtt:

• To access the

Tell Me How

help file, click UUsseerraannddssyysstteemm

gguuiiddeess, click UUsseerr''ssgguuiiddeess, and then click TTeellllMMeeHHooww.

• For help with the Windows operating system, click

MMiiccrroossooffttWWiinnddoowwssXXPPTTiippss.

Open the door for:

1. IEEE 1394 option

Connect devices such as digital cameras to the IEEE 1394 connector.

2. CD or DVD drive

Play CD or DVD discs in this drive.

3. PC Card option

Connect certain types of PC Cards in this slot.

4. Front USB 2.0 connectors (2)

Connect accessories, such as game controllers and digital cameras, to these USB connectors.

5. Headphone connector

Plug headphones into this connector. Doing so disables sound from your speakers.

Printed in the U.S.A.

Set Up Other Devices Last

Help and Support

6Turn on the computer and monitor.

Connect other devices according to their documentation.

9Y560am3.qxd 9/18/2003 4:14 PM Page 2
