Datamax PRINTPAD MC70 Manual de usuario

PRINTPAD MC70

110219-003

User Guide

TABLE OF CONTENTS

PrintPad MC70 Printer Views......................... 1

Open View.................................................... 1

Closed View.................................................. 1

Using Batteries: General Guidelines.............. 2

Installing and/or Replacing Batteries .............. 2

Charging the Batteries and Handheld Comput-

er ..................................................................... 4

Determining Battery Condition...................... 6

Using a Handheld Computer (HHC)............... 7

Compatible Handheld Computers ................... 7

Loading Paper................................................. 8

Printing a Self-Test......................................... 9

Configuring the Printer ................................ 10

Using the Printer Data Cables...................... 10

Using Bluetooth............................................ 11

Bluetooth Parameters.................................. 11

PrintPad MC70 LEDs and Indicators............ 12

Power LEDs................................................ 12

Audio Indicators.......................................... 13

Radio LED .................................................. 14

Power LED.................................................. 14

CardReader Audio Indicators........................ 14

Using DEX/UCS Capabilities......................... 15

Using a CardReader...................................... 16

General Guidelines...................................... 16

CardReader Indicators................................. 16

Using External Charging............................... 17

Overview.................................................... 17

Media Supplies.............................................. 21

PRINTPAD MC70 USER'S GUIDE

PrintPad MC70 Printer Views

Open View

Closed View

Roller

Battery/

battery

cavity

Battery clip

Paper/paper

cavity

Data port

Self-test

button

Charge LED

Battery

Status LED

Radio LED

Power LED

Battery

Status

Radio LED

Power LED

Handheld cavity

Latch

Paper opening

Hand strap

LEDs

DC power port

DEX/UCS port

CardReader slot

PRINTPAD MC70 USER'S GUIDE

Using Batteries: General Guidelines

The printer ships with two batteries installed, but

they are not operational. Before operating the

printer, remove the two red, battery isolator

labels either by gently pulling the labels out, or

by lifting the batteries up.

If you are storing your printer for a long period

of time or shipping it, reinstall the battery

isolator labels.

Both batteries must be installed for your printer

to operate properly.

Installing and/or Replacing Batteries

1. Open the printer by unsnapping the latch on the

front of the case (Figure 1).

2. Lift the battery cover up by pushing the retainer clip

inward with your finger (Figure 2).

3. Lift up the outside end of the battery to remove it.

Figure 1 Figure 2

PRINTPAD MC70 USER'S GUIDE

4. Insert the new batteries. Verify the battery contacts

are facing down and are facing the outside edge of

the printer (Figure 3).

5. Close the battery cover by snapping it into place.

Figure 3

Contacts

PRINTPAD MC70 USER'S GUIDE

Charging the Batteries and Handheld

Computer

If the battery is low when the printer “wakes up,” the

printer sounds three short beeps.

1. Remove the red battery isolator labels, if necessary.

2. Plug the power supply connector into the printer's

external DC port. The DC port is located on the side

of the printer's case (Figure 4).

3. Plug the adapter in an appropriate power source.

The Charge LED flashes red when charging and flashes

green when fully charged. The Charge LED is visible

when the printer's lid is open or closed. A complete

charge takes approximately 7-9 hours. For more

information on the Charge LEDs, see

PrintPad MC70

LEDs and Indicators on page 12

Caution: To obtain full battery capacity, a new battery

must cycle through two to three charges. To restart a

charge, unplug the power cord. Wait 30 seconds, then

replug the power cord.

Note: The MC70 Handheld Computer will charge while

power is plugged into the DC power port.

Figure 4

DC power port

DEX/UCS port

PRINTPAD MC70 USER'S GUIDE

Caution: Do not plug DC power into the internal and

external power ports at the same time.

Caution: Do not plug in either DC plug to power if

using external charge contacts and they are powered.

PRINTPAD MC70 USER'S GUIDE

Determining Battery Condition

You can determine the relative battery status by

printing a self-test. For more information, see

Printing a

Self-Test on page 9

. On the printout, “Battery Volt”

varies between 6.8 and 8.4 volts.

Caution: There is a risk of explosion if the battery is

replaced by an incorrect type. Dispose of used

batteries according to the instructions.

Caution: The operating temperature of this portable

printer is 50° C. However, the operating temperature

when used with a Datamax-O’Neil power supply for

charging the portable printer is limited to 40° C. Please

charge the printer in a suitable location that meets this

temperature requirement.

Caution: (For US/Canada) Please only use the

Datamax-O’Neill part number 220240-100 power

supply with this product.

PRINTPAD MC70 USER'S GUIDE

Using a Handheld Computer (HHC)

1. Insert the handheld into the cavity by slightly

rotating it into the side channels.

2. Press down until the handheld is fully seated (Figure

5).

Compatible Handheld Computers

Note: The PrintPad MC70 is intended for use with UL

Listed Accessory Handheld Computer Symbol

Technologies MC70 series.

Model 1x Battery 2x Battery

MC7004 yes yes

MC7090 yes yes

MC7094 yes yes

Figure 5
