D-Link DKVM-2K Manual de usuario

2-Port KVM Switch

with Built-in Cables

DKVM-2KDKVM-2K

DKVM-2K

This product works with allThis product works with all

This product works with all

Windows Operating SystemsWindows Operating Systems

Windows Operating Systems

Check Your Package Contents

These are the items included with your purchase:

Before You Begin

You must have at least the following:

•PS/2 Keyboard

•PS/2 Mouse

•VGA or Higher Monitor

• DKVM-2K KVM Switch with Built-In

Cables

• Quick Installation Guide

their respective holders. Software and specifications subject to change without notice. DKVM-2K.07242003

If any of the above items are missing, please contact your reseller.

Installing the DKVM-2K

Attach your computer’s 6-pin PS/2

male keyboard connector to the

DKVM-2K keyboard port.

Attach your monitor’s HDDB 15 VGA

connector to the console port of the

DKVM-2K.

Attach your computer’s 6-pin PS/2

male mouse connector to the

DKVM-2K mouse port.

Make sure that all your computers are turned OFF before

installing the DKVM-2K to avoid mouse and keyboard errors

when booting up your computers.

Installing the DKVM-2K

Attach the DKVM-2K‘s built-in

monitor cable to the VGA port

located on the back of your

computer case.

Attach the DKVM-2K’s built-in

mouse cable to the PS/2 mouse

port located on the back of your

computer case.

Attach the DKVM-2K’s built-in

keyboard cable to the PS/2

keyboard port located on the

back of your computer case.

Type A

Power ON all your attached computers after you have

completed the DKVM-2K installation.

The following steps below apply to both the computers that you are using with your

DKVM-2K.

Switchingwith the DKVM-2K

The DKVM-2K features a Select Button located on the front panel and keyboard Hot

Keys to switch quickly and easily between both your computers.

Select

Button

You can also use your keyboard to switch between your computers. Press the Scroll

Lock key twice to enter Hot Key switching mode. A beep confirms that the Hot Key mode

is activated.

Hot Key Menu

Scroll Lock + Scroll Lock + 1 : Switches to PC 1

Scroll Lock + Scroll Lock + 2 : Switches to PC 2

Scroll Lock + Scroll Lock + S : Activates Auto Scan Mode. Each

computer will be scanned every 10

seconds.

Scroll Lock + Scroll Lock + ESC : Exits Auto Scan Mode and Hot

Key Mode.

Troubleshooting Tips

Keyboard

If your keyboard is not functional, not detected, or there is a keyboard error on boot-up,

check the following:

• Make sure that the keyboard is properly connected to the

computer and to the DKVM-2K. Check that the keyboard is plugged into the

correct PS/2 keyboard port and not the PS/2 mouse port.

• Verify that the keyboard works when plugged into the computer directly. You

will have to shut down your computer first to do this.

• Read your motherboard documentation and make sure that the PS/2

keyboard’s IRQ is enabled. This can be set for most computers in the

BIOS setup.

• Try using a different keyboard.

Mouse

If your mouse is not functional, not detected, or there is a mouse error on boot-up, check

the following:

• Make sure that the mouse is properly connected to the

computer and to the DKVM-2K. Check that mouse is plugged into the

correct PS/2 mouse port and not the PS/2 keyboard port.

• Verify that the mouse works when plugged into the computer directly. You

will have to shut down your computer first to do this.

• Read your motherboard documentation and make sure that the PS/2

mouse’s IRQ is enabled. This can be set for most computers in the

BIOS setup.

• Try using a different mouse.

• If mouse movement is random when switching between computers, try shutting

down your computer and rebooting.

• Verify that your computers do not have more than one mouse driver installed

(check your config.sys and autoexec.bat files for Windows) and that you are

using the latest mouse driver.

• If a special mouse is used such as a cordless or scrolling mouse, make sure

you use generic PS/2 mouse drivers. A non-standard PS/2 mouse may have

extensions on the PS/2 protocol that are not supported by the DKVM-2K.

• Do not move the mouse or press any mouse buttons when switching from one

PC to another.

• Try resetting the mouse by unplugging it from the DKVM-2K for about 3 seconds

and reconnecting.

Video

If the image on your monitor is not clear, check the following:

• Verify that all video monitor cables are inserted properly.

• Try lowering the resolution and refresh rate of your monitor.

• Try using a shorter video cable.

Technical Support

You can find software updates and user documentation on the D-Link website.

D-Link provides free technical support for customers within the United States and

within Canada for the duration of the warranty period on this product.

U.S. and Canadian customers can contact D-Link Technical Support through our

website, or by phone.

Tech Support for customers within the United States:

D-Link Technical Support over the Telephone:

(877) 453-5465

24 hours a day, seven days a week.

D-Link Technical Support over the Internet:

http://support.dlink.com

email:[email protected]

Tech Support for customers within Canada:

D-Link Technical Support over the Telephone:

(800) 361-5265

Monday to Friday 8:30am to 9:00pm EST

D-Link Technical Support over the Internet:

http://support.dlink.ca

email:[email protected]
