D-Link SECURICAM Network DCS-900 Manual de usuario

Check Your Package Contents

These are the items included with your purchase:

If any of the below items are missing, please contact your reseller.

BeforeYou Begin

Youmusthaveatleastthefollowing:

• Existing10/100MbpsEthernet-BasedNetwork

•CD-ROMDrive

DCS-900

10/100 Fast Ethernet

Internet Camera

This product can be set up using

any current Web browser, i.e.,

Internet Explorer 6.0 or Netscape

Navigator 7.0

DCS-900 Internet Camera

CD-ROM with Manual and Software

Camera Stand

AC PowerAdapter

CAT5 Ethernet Cable

their respective holders. Software and specifications subject to change without notice. DCS-900.07292004

Hardware Installation

System Requirements

• JavaEnabled and Compliant WebBrowser

• CPU:Pentium III, 850MHz or above

• Memory Size: 128MB

• VGAcard resolution: 800x600 or above

• Existing10/100Mbps Ethernet-Based Network

Connect the Ethernet Cable

Connecttheincluded Ethernetcabletothenetwork

cable connector located on the back panel of the

DCS-900 and attach it to the network. Network

Connectivity is confirmed when the orange LED

Indicatoron theDCS-900 locatedbelow thePower

LED is illuminated.

Attach the External Power Supply

Attachthe external power supply totheDC power

input connector located on the rear panel of the

DCS-900andconnectittoyour localpowersupply.

Note: Power source is confirmed when the green

LEDPowerIndicatorlocatedtotherightofthelens

onthe DCS-900 is illuminated.

Attach the Swivel Stand

Locatethe stand connectoronthe bottom panelof

theDCS-900 and screw on the swivel standtothe

baseof the DCS-900.

Running the Setup Wizard

You are now ready to run the Setup Wizard, which will guide you quickly through the

installation process.

InserttheD-Link DCS-900 Driver

CDinto yourCD-ROM drive.

Click Install Software

Click Next

Click Install Wizard

Click Next

Click Finish

Running the Setup Wizard (continued)

ClickYes

You must change the Admin ID and

Password immediately to protect

your camera against unauthorized

access.By default, theAdminIDand

Password are blank. To change the

AdminIDand Password, select both

Change boxes and enter a New ID

and New Password.

Enter an IP Address and Subnet

Mask for your camera. Enter your

Gateway and DNS settings. These

settings must correspond with your

network settings for you to access

thecamera.Ifyouareunsureofwhat

thesesettingsshould be, check with

yournetwork administrator.

Running the Setup Wizard (continued)

Click Next

Click Wizard to begin

Your camera’s IPAddress will be

displayed here if it is valid.

To run the Setup Wizard, click on

Start->Programs->DCS-900Series

SetupWizard.

If you need to make any changes,

click Back to modify your settings.

Otherwise,click Restart to saveand

apply your settings.

ClickRestart

Click Link

Setup is now complete! Click Link

tolaunchyourwebbrowserandview

yourimages.

Running the Setup Wizard (continued)

TheIP Address of yourcamera must

correspondwithyournetwork settings

for you to access the camera. If you

are unsure of what these settings

should be, please check with your

networkadministrator.

By default, the Admin ID and

Password are blank. If you are

runningthis SetupWizard forthe first

time, leave both Admin ID and

Password fields blank and simply

click OK to continue.

Thisscreenappearsif the default IP

Addressofthecamera(192.168.0.20)

does not correspond with your local

area network settings. You must

assignan IPaddress foryourcamera

thatcorresponds toyournetwork’s IP

addressingscheme.

ClickYes

Click OK

Running the Setup Wizard (continued)

Viewing the Streaming Video

Tips

Click Active X or

Java toviewyour

video images.

•If you are installing several cameras, it is recommended to use one computer to

configureall of them beforeyouinstall them inyourplanned locations.To avoid IP

addressconflict, use192.168.0.20 forthe LASTcamera thatyouplanoninstalling.

•Make sure that you have the latest version of Java installed on your computer to

ensure proper operation when viewing the video in Java mode. Java can be

downloadedfor freefromSun’sweb site.(http://www.java.com)

•The Xplug Control is included with the DCS-900 and should be installed on your

computer if you want to useActive X to view your video images instead of Java.

TheXplug Control must be installed onyourcomputer if you are using the remote

monitoringsoftware.PleaserefertotheManualincludedonthisCD-ROMfordetailed

informationoninstallingtheXplugControltoyourcomputerforusewiththesoftware.

•Please refer to the Manual located on the CD-ROM for additional information

regardingall features and instructions relatedtothe DCS-900.

TheHome screen of your camera can beaccessedfromthe Setup Wizard using the Link

button. You can also use your favorite Web browser, type “http://address” in the address

box where address is the IP address that you assigned to the camera from the previous

section. Press Enter.

Notes
