D-Link DCS-5029 Manual de usuario

DCS-5029L

Quick Install Guide

HD Pan & Tilt Day/Night Network Camera

Cloud Camera

ENGLISHENGLISH

If any of the above items are missing, please contact your reseller.

Minimum Requirements

DCS-5029L HD Pan & Tilt Day/Night Network Camera

Power Adapter

Package Contents

Mounting Kit

• Wired 10/100 Fast Ethernet or Wireless 802.11g/n network

(Wireless N network recommended for optimum performance)

Ethernet Cable

Audio In/Out Cable

Quick Install Guide

Computer with:

Web Browser

• 1.3GHz processor or above and at least 128MB RAM

• Windows® 8, 7, Vista®, or Mac OS® X 10.6 or higher

• Internet Explorer® 7, Firefox, Safari 4, or Chrome

• Installed and enabled Java and ActiveX® controls

• A router (D-Link Cloud Router is recommended)

• An Internet connection

• An e-mail account (required to create a mydlink account)

Network Device and Service

Product Overview

Camera Lens

Microphone

Light Sensor

Power LED

PIR Sensor

WPS Status LED

Power Receptor

Ethernet Port

Reset Button

WPS Button

Front

Back

IR LEDs*

Speaker

DIDO Port

Audio In/Out

Antenna

microSD

Card Slot

*Note: If you see a white haze when viewing in night vision mode, the IR lights on the

camera may be reecting o a nearby surface. Try repositioning the camera in order to

avoid glare from the IR LEDs.

ENGLISHENGLISH

The Zero Conguration Setup will only work with a registered

Cloud Router and an active mydlink account. Your Cloud Router

will automatically assign your network settings (both wired and

wireless) to your camera, and add it to your mydlink account. If you

do not have a D-Link Cloud Router, skip to the Easy Setup section

on the next page.

Zero Conguration Setup

If using an Ethernet connection:

Connect the included Ethernet

cable to the Ethernet port located

on the back of the DCS-5029L and

connect it to your router.

Attach the power supply to the

power receptor located on the back

of the DCS-5029L and connect it to

a wall outlet or power strip. Power

is conrmed when the Power LED

is lit.

From any PC, open a web browser,

go to http://www.mydlink.com

and log into your account. Once

mydlink detects your camera, a

notice will appear that there is a

new device detected. Click on your

camera from the New Devices

list and then click Yes to add your

camera.

Your setup is complete!

DCS-5029L

If using a wireless connection:

Press and hold the WPS button

on the side of the camera for ve

seconds. The blue WPS status LED

will start to blink. Then, press the

WPS button on your Cloud Router

within two minutes.

Easy Setup (All Other Routers)

Download the Setup Wizard from http://www.mydlink.com/support.

If you do not have a D-Link Cloud Router, you can use any Windows

or Mac computer to go through the Setup Wizard, which will

guide you through the installation process, from connecting your

hardware to conguring your camera.

Windows Users - Extract (“unzip”) the les to a folder on your

computer and then double-click the autorun.exe le.

Mac Users - Download the Mac OS Setup Wizard. Open the

SetupWizard le and launch the application.

After about 20-30 seconds, the Setup Wizard will open, which

will guide you step-by-step through the installation process

from connecting your hardware to conguring your camera and

registering it with your mydlink account.

ENGLISHENGLISH

• Windows does not have Java installed by default.

Download it from http://www.java.com.

• In Mac OS X 10.7.x, Java applets are disabled by

default. Click the Finder > Applications > Utilities

> Java Preferences and check the Enable applet

plug-in and Web Start applications option.

• The ActiveX® controls in IE will install automatically

if needed. We suggest that you make sure that

you have enabled the related options in Tools >

Internet Options > Security > Custom Level.

mydlink Lite App (Free)

Search for “mydlink lite” to download and install the app on your smartphone or

tablet when connected to the Internet. You can also nd the app by scanning the

QR code below with a QR code scan app.

mydlink+ App (Paid - Tablet Only)

Search for the word “mydlink+” to download and install the app on your tablet

when connected to the Internet. You can also nd the app by scanning the QR code

below with a QR code scan app.

Start mydlink

mydlink Requirements: for mydlink and mydlink app requirements refer to: www.mydlink.com

Open a web browser on any computer connected to the Internet.

Enter http://www.mydlink.com in the address bar and press Enter.

Mount the Camera

Please refer to the steps below to assist you with mounting the camera.

We suggest that you congure the camera before mounting.

1. Place the arm mount where you want to position

the camera and use a pencil to mark the holes.

Make sure you allow adequate space for the

necessary cables to be routed. The camera can

be mounted to either side of the camera shoe.

2. Depending on the material of the wall or ceiling,

use a 6mm drill bit to drill two holes where you

marked. If the wall is made out of concrete, after

drilling the holes, insert the plastic anchors, and

then insert the screws.

3. The power and Ethernet cables can be concealed

behind the mounting bracket.When you run the

cables through the channel, secure them with

the built-in guides. Leave enough cable length

protruding from the top to connect the cables to

the camera.

4. Fasten the arm mount to the wall using the

screws provided. Lightly pull on the arm mount

to make sure it is fastened securely.

5. Align the camera base mounting guides with

the camera shoe and thumbscrew on the arm

mount. Tighten the thumbscrew to lock the

camera in place.

Do not overtighten the screws as this may crack the bracket.

ENGLISHENGLISH

Technical Support

This guide is only for the rst time conguration. Please refer to the user manual to

learn more or visit http://www.mydlink.com for more information. Also feel free to

http://support.dlink.com

USA

Version 1.0_130x183

June 4, 2014

RMN0101382

D-Link Corporation or its subsidiaries. All other third party marks mentioned herein may be trademarks

of their respective owners. Maximum wireless signal rate derived from IEEE Standard 802.11g and

802.11n specications. Actual data throughput will vary. Network conditions and environmental factors,

including volume of network trac, building materials and construction, and network overhead, lower

actual data throughput rate. Environmental conditions will adversely aect wireless signal range. Product

specications, size and shape are subject to change without notice, and actual product appearance may

dier from that depicted on the packaging. This publication may not be reproduced, in whole or in part,

without prior express written permission from D-Link Systems, Inc.
