D-Link DCS-4705E Manual de usuario

This document will guide you through the

basic installation process for your new

D-Link Network Camera.

DCS-4705E

Documentation also available on

CD and via the D-Link Website

Quick Installation Guide

Vigilance 5 Megapixel H.265 Outdoor Bullet Camera

Quick Installation Guide

Installationsanleitung

Guide d’installation

Guía de instalación

Guida di Installazione

Краткое руководство по установке

КОРОТКИЙ ПОСІБНИК ЗІ ВСТАНОВЛЕННЯ

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

D-Link DCS-4705E Quick Installation Guide 1

ENGLISH

Quick Installation Guide

This installation guide provides basic instructions for installing the Network

Camera on your network. For additional information about how to use the

camera, please see the User Manual which is available on the CD included in

this package or from the D-Link support website.

Package Contents

DCS-4705E Vigilance 5 Megapixel H.265 Outdoor Bullet Camera

Cable Waterproong Connector

Rubber Power Connector Plug

Mounting Kit

Manual and Software on CD-ROM

Quick Installation Guide

If any of the above items are missing, please contact your reseller.

Safety Notice:

Installation and servicing should be done by certied technicians so as to

conform to all local codes and prevent voiding your warranty.

2D-Link DCS-4705E Quick Installation Guide

ENGLISH

Hardware Overview

Camera Lens

IR LEDs

Provide illumination for

low-light environments

Adjustment Ring

Loosen to adjust camera

angle and tighten to lock

camera angle

Reset Button

Press and hold for 10

seconds to reset camera

back to the factory default

settings

Grounding Screw

Can be attached to a

grounding wire if desired

Power Connector

Connects to an optional 12 V / 1.5 A power

adapter (not included)

Ethernet Jack

RJ-45 connector for Ethernet, can

also be used to power the camera

using Power over Ethernet (PoE)

D-Link DCS-4705E Quick Installation Guide 3

ENGLISH

Conguring the Camera

Insert the DCS-4705E CD into your computer's CD-ROM drive to begin

the installation. If the Autorun function on your computer is disabled, or if

the D-Link Launcher fails to start automatically, click Start > Run. Type D:\

autorun.exe, where D: represents the drive letter of your CD-ROM drive.

Click on the D-Link Setup Wizard SE icon that

was created in your Windows Start menu (Start >

D-Link > Setup Wizard SE).

The Setup Wizard will appear and display the MAC

address and IP address of your camera(s). If you

have a DHCP server on your network, a valid IP

Address will be displayed. If your network does not

use a DHCP server, the network camera's default

static IP 192.168.0.20 will be displayed.

Select your camera, then click the Wizard button to

continue.

Click Setup Wizard and follow the instructions to

install the Setup Wizard.

Enter the Admin ID and password. When logging in

for the rst time, the default Admin ID is admin with

the password left blank.

Click the checkboxes if you wish to change the

admin ID and password for the camera, and enter

the new ID and password you wish to use.

Click Next to continue.

Select DHCP if your camera obtains an IP address

automatically from a DHCP server such as a router.

Select Static IP if you want to manually enter the IP

settings for the camera.

Click Next to continue.

4D-Link DCS-4705E Quick Installation Guide

ENGLISH

Take a moment to conrm your settings and click

Restart.

Viewing Your Camera via Web Browser

Click on the D-Link Setup Wizard SE icon that

was created in your Windows Start menu (Start >

D-Link > Setup Wizard SE).

Select the camera and click Link to access the web

conguration.

The Setup Wizard will automatically open your web

browser to the IP address of the camera.

This section displays your camera’s live video. You

can select your video prole and view or operate

the camera. For additional information about web

conguration, please refer to the user manual

included on the CD-ROM or the D-Link website.

Enter admin as the default username and leave the

password blank. Click OK to continue.

D-Link DCS-4705E Quick Installation Guide 5

ENGLISH

Mounting Instructions

It is highly recommended that you congure and test your camera before

mounting it.

If you need to waterproof your installation, please continue to the next page.

Place the mounting sticker where you want to

position the camera. Make sure the camera base

will be positioned so that the cable channel is on

the bottom.

Use a 6 mm drill bit to make the required holes

approximately 25 mm deep, then insert the wall

anchors into the holes.

If you are running the camera cables through

the wall, drill a hole in the center and pull the

cables through the hole.

Connect the power and Ethernet cables, or just the

Ethernet cable if you are using a PoE connection.

Use the screws provided to mount the camera to

the wall.

If you are running the camera cables out the

side of the camera, guide the camera cables

through the cable channel on the base.

To adjust the camera's angle, turn the adjustment

ring counterclockwise to loosen it, then move the

camera to the desired position and angle. When

you are nished, turn the adjustment ring clockwise

to tighten it.

6D-Link DCS-4705E Quick Installation Guide

ENGLISH

To waterproof your camera installation, follow the instructions below. Round

Ethernet cable, a crimping tool, and RJ-45 plugs are required for this

procedure.

Waterproong Your Installation

Place the washer around the base of the Ethernet

connector as shown.

Connect the RJ-45 plug into the Ethernet

connector, then screw the waterproof connector

to the Ethernet connector by turning it about a

half-turn clockwise.

Thread bare Ethernet cable through the waterproof

connector as shown, then crimp an RJ-45 plug onto

the cable.

D-Link DCS-4705E Quick Installation Guide 7

ENGLISH

If you are using PoE to power your camera, use

the included rubber power connector plug to the

power connector.

If you are using a power adapter(not included)

to power your camera, wind waterproof tape

around the connection in an overlapping manner to

cover it.

Additional Information

Additional help and product information is available online at

http://www.dlink.com.

Warranty Information

Please visit http://warranty.dlink.com/ for warranty information for your region.

Screw the back part of the waterproof connector

clockwise until there is a tight seal around the

Ethernet cable.

8D-Link DCS-4705E Quick Installation Guide

DEUTSCH

Installationsanleitung

Diese Installationsanleitung bietet Ihnen grundlegende Anleitungen zur

Installation der Netzwerkkamera in Ihrem Netzwerk. Zusätzliche Informationen

zur Verwendung der Kamera nden Sie im Benutzerhandbuch, das Ihnen auf

der CD, die diesem Paket beiliegt, oder über die D-Link Support-Website zur

Verfügung steht.

Packungsinhalt

DCS-4705E Vigilance 5 Megapixel H.265 Outdoor Bullet Camera

Wasserdichter Anschlussstecker

Netzanschlussstecker aus Hartgummi

Montageset

CD-ROM mit Software und Handbuch

Installationsanleitung

Sollte einer der oben aufgeführten Artikel fehlen, wenden Sie sich bitte an

Ihren Fachhändler.

Sicherheitshinweis:

Installation und Wartungsarbeiten sollten nur von zertizierten Technikern

vorgenommen werden, zu jeder Zeit allen örtlich geltenden Richtlinien und

Anforderungen entsprechen sowie verhindern, dass Ihr Garantieanspruch

erlischt.
