D-Link DCS-2210 Manual de usuario

This document will guide you through the basic installation

process for your new D-Link Network Camera.

DCS-2210/DCS-2230

Quick Installation Guide

Full HD PoE/Wireless N Cube Network Camera

Quick Installation Guide

Руководство по быстрой установке

Guía de Instalación Rápida

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

Documentation also available on

CD and via the D-Link Website

D-Link DCS-2210/DCS-2230 Quick Install Guide

Installation Steps

ENGLISH

DCS-2210/DCS-2230 Quick Install Guide

This installation guide provides basic instructions for installing the DCS-2210/DCS-2230

Network Camera on your network. For additional information about how to use the

camera, please see the User’s Manual which is available on the CD include in this

package or from the D-Link support website.

Installation Steps

1. Verify the package contents against the list below.

2. Hardware Overview

3. Hardware Installation

4. Conguration with Wizard

1. Package Contents

 DCS-2210 or DCS-2230 Network Camera

 Camera Stand

 Manual and Software on CD-ROM

 CAT5 Ethernet Cable

 Power Adapter

 Quick Install Guide

If any of the above items are missing, please contact your reseller.

D-Link DCS-2210/DCS-2230 Quick Install Guide 3

Hardware Overview

ENGLISH

Status LED

Indicates the camera's

current status

PIR

Passive Infrared

sensor for

motion detect

ICR Sensor

The IR-Cut Removable sensor

judges lighting conditions and

switches from color to infrared

accordingly

Infrared LED

Used to illuminate the camera's

eld of view at night

Microphone

Records audio from the

surrounding area

WPS LED

(DCS-2230 only)

WPS status

indicator LED

Speaker

Audio output

Camera Lens

Records video of the

surrounding area

Adjustment Ring

Tighten or loosen the

adjustment ring to adjust

the camera's position

Base Holes

Can be used with cable ties to

attach camera to a surface

Reset

Press and hold this button

for 10 seconds to reset

the camera

Ethernet

RJ45 connector for Ethernet

(DCS-2210 support PoE

which can also be used to

power the camera)

WPS button(DCS-2230 only)

Press this button, then press

the WPS button on your

router to set up a wireless

connection automatically

Power Connector

Connects to the included DC

5 V power adapter

I/O Connector

I/O connectors for

external devices

2. Hardware Overview

Rear Panel

Front Panel

D-Link DCS-2210/DCS-2230 Quick Install Guide

Hardware Overview

ENGLISH

Micro SD Card slot

Local storage for storing

recorded image and video

Left Panel

D-Link DCS-2210/DCS-2230 Quick Install Guide

Hardware Installation

ENGLISH

3. Hardware Installation

Basic Connection

Connect the camera to your switch or router via Ethernet cable.

Connect the supplied power cable from the camera to a power outlet.

Connection Using a PoE Switch (DCS-2210 only)

If using a PoE switch or router, connect the network camera via Ethernet cable.

PoE will transmit both power and data over a single cable.

Note: Once power has been established, the LED will turn red. When the device has

obtained an IP address and is accessible, the LED will turn green.

D-Link DCS-2210/DCS-2230 Quick Install Guide

Conguration with Wizard

ENGLISH

4. Conguration with Wizard

Click Installation Wizard to begin the installation.

Insert the DCS-2210/DCS-2230 CD into your computer's CD-ROM drive to begin the

installation. If the Autorun function on your computer is disabled, or if the D-Link Launcher

fails to start automatically, click Start > Run. Type D:\autorun.exe, where D: represents

the drive letter of your CD-ROM drive.

After clicking Setup Wizard, the following window

will open.

Click Next to continue.

Click Yes to accept the License Agreement.

Click Finish to complete the installation.

To start the installation process, click Next.

Note: The installation may take several minutes

to nish.

D-Link DCS-2210/DCS-2230 Quick Install Guide

Conguration with Wizard

ENGLISH

Click on the D-Link Setup Wizard SE icon that was

created in your Windows Start menu.

Start > D-Link > Setup Wizard SE

Take a moment to conrm your settings and click Restart.

Select DHCP if your camera obtains an IP address

automatically when it boots up. Select static IP if the

camera will use the same IP address each time it is

started.

Click Next, to proceed to the next page.

Enter the Admin ID and password. When logging in for

the rst time, the default Admin ID is admin with the

password left blank.

Click Next, to proceed to the next page.

The Setup Wizard will appear and display the MAC

address and IP address of your camera(s). If you have

a DHCP server on your network, a valid IP Address

will be displayed. If your network does not use a

DHCP server, the network camera's default static IP

192.168.0.20 will be displayed.

Click the Wizard button to continue.

D-Link DCS-2210/DCS-2230 Quick Install Guide

Conguration with Wizard

ENGLISH

Click on the D-Link Setup Wizard SE icon that was

created in your Windows Start menu.

Start > D-Link > Setup Wizard SE

Viewing Camera via Web Browser

This section shows your camera’s live video. You

can select your video prole and view or operate

the camera. For additional information about web

conguration, please refer to the user manual included

on the CD-ROM or the D-Link website.

Enter admin as the default username and leave the

password blank. Click OK to continue.

Select the camera and click the button labeled "Link"

to access the web conguration.

The Setup Wizard will automatically open your web

browser to the IP address of the camera.

D-Link DCS-2210/DCS-2230 Quick Install Guide

Technical Support

ENGLISH

Technical Support

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: +91-22-27626600

Toll Free 1800-22-8998

Web: www.dlink.co.in

E-Mail: [email protected]

Singapore, Thailand, Indonesia,

Malaysia, Philippines, Vietnam:

Singapore - www.dlink.com.sg

Thailand - www.dlink.co.th

Indonesia - www.dlink.co.id

Malaysia - www.dlink.com.my

Philippines - www.dlink.com.ph

Vietnam - www.dlink.com.vn

Korea:

Tel : +82-2-2028-1810

Monday to Friday 9:00am to 6:00pm

Web : http://d-link.co.kr

E-mail : [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

South Africa and Sub Sahara

Region:

Tel: +27 12 661 2025

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South

Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

Saudi Arabia (KSA):

Tel: +966 01 217 0008

Fax: +966 01 217 0009

Saturday to Wednesday 9.30AM to 6.30PM

Thursdays 9.30AM to 2.00 PM

E-mail: [email protected]

D-Link Middle East - Dubai, U.A.E.

Plot No. S31102,

Jebel Ali Free Zone South,

P.O.Box 18224, Dubai, U.A.E.

Tel: +971-4-8809022

Fax: +971-4-8809066 / 8809069

Technical Support: +971-4-8809033

General Inquiries: [email protected]

Tech Support: [email protected]

Egypt

1, Makram Ebeid Street - City Lights Building

Nasrcity - Cairo, Egypt

Floor 6, ofce C2

Tel.: +2 02 26718375 - +2 02 26717280

Technical Support: +2 02 26738470

General Inquiries: [email protected]

Tech Support: [email protected]

Kingdom of Saudi Arabia

Ofce # 84 ,

Al Khaleej Building ( Mujamathu Al-Khaleej)

Opp. King Fahd Road, Olaya

Riyadh - Saudi Arabia

Tel: +966 1 217 0008

Technical Support:

+966 1 2170009 / +966 2 6522951

General Inquiries: [email protected]

Tech Support: [email protected]

Pakistan

Islamabad Ofce:

61-A, Jinnah Avenue, Blue Area,

Suite # 11, EBC, Saudi Pak Tower,

Islamabad - Pakistan

Tel.: +92-51-2800397, 2800398

Fax: +92-51-2800399

Karachi Ofce:

D-147/1, KDA Scheme # 1,

Opposite Mudassir Park, Karsaz Road,

Karachi – Pakistan

Phone: +92-21-34548158, 34326649

Fax: +92-21-4375727

Technical Support: +92-21-34548310, 34305069

General Inquiries: [email protected]

Tech Support: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

D-Link DCS-2210/DCS-2230 Quick Install Guide

Technical Support

ENGLISH

Iran

Unit 5, 5th Floor, No. 20, 17th Alley , Bokharest

St. , Argentine Sq. ,

Tehran IRAN

Postal Code : 1513833817

Tel: +98-21-88880918,19

+98-21-88706653,54

General Inquiries: [email protected]

Tech Support: [email protected]

Morocco

M.I.T.C

Route de Nouaceur angle RS et CT 1029

Bureau N 312 ET 337

Casablanca , Maroc

Phone : +212 663 72 73 24

Email: [email protected]

Lebanon RMA center

Dbayeh/Lebanon

PO Box:901589

Tel: +961 4 54 49 71 Ext:14

Fax: +961 4 54 49 71 Ext:12

Email: [email protected]

Bahrain

Technical Support: +973 1 3332904

Kuwait:

Technical Support: + 965 22453939 / +965

22453949

Türkiye Merkez İrtibat Ofisi

Ayazağa Maslak yolu

Erdebil Cevahir İş Merkezi No: 5/A Ayazağa /

Maslak İstanbul

Tel: +90 212 2895659

Ücretsiz Müşteri Destek Hattı: 0 800 211 00 65

Web:www.dlink.com.tr

Teknik Destek: [email protected]

Technical Support

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Otros manuales para DCS-2210

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Cámara de seguridad de D-Link

D-Link

D-Link SECURICAM DCS-7110 Manual de usuario

D-Link

D-Link SECURICAM DCS-910 Manual de usuario

D-Link

D-Link DCS-936L Manual de usuario

D-Link

D-Link DCS-2310L Manual de usuario

D-Link

D-Link DCS-933L Cloud Camera 1150 Manual

D-Link

D-Link DCS-8300LHV2 Manual de usuario

D-Link

D-Link DCS-1100 Manual de usuario

D-Link

D-Link SECURICAM DCS-7110 Manual de usuario

D-Link

D-Link DCS-2670L Manual de usuario

D-Link

D-Link SECURICAM DCS-6110 Manual de usuario

D-Link

D-Link DCS-6100LH Manual de usuario

D-Link

D-Link DCS-2330L Manual de usuario

D-Link

D-Link BEYOND FIBER MSME SECURITY KIT Manual de usuario

D-Link

D-Link DCS-942L Manual de usuario

D-Link

D-Link DCS-7413 Manual de usuario

D-Link

D-Link DCS-6500LH Manual de usuario

D-Link

D-Link DCS-7000L Manual de usuario

D-Link

D-Link DCS-5222L Manual de usuario

D-Link

D-Link DCS-931L Cloud Camera 1050 Manual de usuario

D-Link

D-Link SECURICAM DCS-910 Manual de usuario

D-Link

D-Link DCS-2310L Manual de usuario

D-Link

D-Link DCS-7413 Manual de usuario

D-Link

D-Link DCS-960L Manual de usuario

D-Link

D-Link DCS-4603 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
