D-Link DCS-3110 - SECURICAM Fixed Network Camera Manual de usuario

2D-Link DCS-3110 Quick Install Guide

System Requirements

• Windows®XPorWindowsVista®

• Atleast256MBofmemory(512MBrecommended)

• InternetExplorer6.xorhigher

• VGAcardresolution:800x600orabove

• CPU:1.7GHzorabove

• AnavailableEthernetconnection

CAT5EthernetCable

Package Contents

DCS-3110

MegapixelPoENetwork

Camera

Minimum System Requirements

If any of the above items are missing, please contact your reseller.

CD-ROMwithManual

andSetupWizard PowerAdapter

Camera Stand

Note: Using a power supply with a different voltage than the one included with your

product will cause damage and void the warranty for this product.

3 D-Link DCS-3110 Quick Install Guide

HardwareOverview

Hardware Overview

Connections

Rear View

Audio Out Connector:

UsetheAudioOutconnectorfor

2-wayaudioconnection.Speakers

(notincluded)maybeconnected

tothecamerafor2-wayaudio

communication.

Reset Button

Reset is initiated

whentheresetbutton

ispressedonceand

held 30 seconds

untilthepowerLED

flashesthroughits

cycletwice.

Power Receptor

Receptor for the

supplied power

adapter.

DI/DO:

TheDCS-3110providesageneralI/Oterminalblock.TheI/O

connectorsprovidethephysicalinterfacetosendandreceive

digitalsignalstoandfromavarietyofexternaldevices.

DC12V output :

Supportforexternaldevice(likeIRlight)

RS485:

Portisdesignedforexternalpan/tilt/zoomdevices.

Ethernet Port (PoE)

ConnecttheNetworkCameratoyournetwork

usingaCAT5Ethernetcable.Thisport

supportstheNWayprotocol,allowingthe

networkcameratoautomaticallydetector

negotiate the transmission speed of the

network.

TheEthernetportcanalsobeusedtopower

thecamerabyusingaPoEswitch.

Status LED

Blinking Red:indicatespoweris

beingsuppliedtothecamera.

Solid Green: indicates that a

connectionhasbeenestablished

viaEthernetport.

Blinking Green: indicates traffic

movementinthecamera.

IftheEthernetconnectionisnot

established the Status LED will

notglow.

Mic On/Off Switch:

Select to turn the

microphoneOnorOff.

Microphone Connector: The

camerahasaninternalbuilt-in

microphone.Touseanexternal

microphone,plug it into the

microphoneconnector.

4D-Link DCS-3110 Quick Install Guide

HardwareOverview

Interfaces

Front View

ICR and Built-in Microphone

Compact Flash Card Slot

Built-inMicrophone

IR-Cut Removable (ICR)

Sensor

The IR-Cut removable

sensorwill judge the

lightconditionsandthen

switchesfrom colorto

B/Waccordingly.

CF card slot

CompactFlash(CF)isamassstoragedeviceformatusedinportable

electronicdevices.TheCFcardslotcanbeseenatthesideofthe

networkcamera.

Note: Ensure to remove the rubber strip before using it.

5D-Link DCS-3110 Quick Install Guide

HardwareInstallation

Hardware Installation

Connect the Ethernet Cable

Connect an Ethernet cable to the network cable

connectorlocatedontheNetworkCamera’sback

panelandattachittothenetwork.

Connect Using Power-Over-Ethernet

OnceyouconnectanEthernetcabletoyourPoE

switchoradapter,thePowerLEDontheDCS-3110

willturngreentoindicateaproperconnection.

Attach the External Power Supply

Attachthe external powersupply to theDC power

inputconnector located on theNetwork Camera’s

backpanel(labeledDC12V)andconnecttheother

endtoanACpoweroutlet.

Note: The LED on the network camera will turn green, when you have a proper

connection. The light might go on and off and your computer may show an

intermittent loss of connectivity, this is normal until you have congured

your Network Camera.

6D-Link DCS-3110 Quick Install Guide

HardwareInstallation

Thepackagecomeswithacamerastandwithaswivelballscrewheadthat

canbe attached tothe Network Camerabottom socket cavity.Attach the

camerastandtotheNetworkCameraandstationitforyourapplication.There

areholeslocatedinthebaseofthecamerastandallowingthecameratobe

mountedtotheceiling,oranywallsecurely.

7D-Link DCS-3110 Quick Install Guide

SoftwareInstallation

TurnonthecomputerandinserttheD-LinkDCS-3110CDintotheCD-ROM

drive. The following step-by-stepinstructions displayed are shown when

usingWindowsVista®operatingsystem.Thestepsandscreensaresimilar

whenusingotherWindows®operatingsystems.

Software Installation

Click Nexttocontinue.

Click I Agree to accept the License

Agreement.

Click Next

Click I Agree

Click Installation Wizard

8D-Link DCS-3110 Quick Install Guide

SoftwareInstallation

Click Finish to complete the

installation.

Tostart the installationclick

Install.

Note: The installation may take

several minutes to complete.

Click Install

Click Finish

9 D-Link DCS-3110 Quick Install Guide

Conguration

Conguring Your Camera with

the Installation Wizard

ClickontheD-Link Installation WizardiconthatwascreatedinyourWindows

Startmenu.

TheInstallation Wizard willappear andshow the MACaddress of your

DCS-3110andanIPAddress(whichmayormaynotbecorrectdepending

onwhatyouhaveyourDCS-3110connectedto).IfyouhaveaDHCPserver

onyournetwork,therewillbeavalidIPAddressdisplayedhere.

Note: A DHCP server is a device that supplies the same IP address.

Click Manual Setup

EntertheadminIDandpassword.

Note: The default Admin ID is admin with

the password left blank.

Click Next

10D-Link DCS-3110 Quick Install Guide

Conguration

Anewwindowwillpopuptoaskifyou

wanttosetupaPPPoEforthedevice.

Click Nofor quick setup. For further

informationrefer to the usermanual

fordetails.

Checkthe Get IP by DHCP Server

automaticallyboxtoobtainanewIP

addressevery time thecamerastarts

up.ClickNexttocontinue.

Select UPnP Port Forwardingifyour

routersupportsthisfunction.Ifnot,

chooseManual to manuallyenter

yourport numbers. Click Next to

continue.

Click Next
