D-Link DIR-868L Manual de usuario

Contents

1 Hardware

1.1 Specifications♦

•

2 Installation Instructions

2.1 Step-by-step instructions from out-of-the-box

factory firmware

♦

2.2 How to restore to factory firmware♦

•

3 Known Issues

3.1 Bad WiFi drivers♦ 3.2 OpenVPN♦ 3.3 D-Link DDNS♦

•

Hardware

Delivering Wi-Fi AC1750 dual band speeds with AC SmartBeam technology to your home network, the

DIR-868L is the perfect solution for those looking to enjoy online gaming, multiple HD video streams, and

fast file transfers ? all with less wireless interference for maximum throughput.

Specifications

CPU Broadcom

BCM4708X

RAM 256 MB

Flash 128 MB

Switch In

BCM4708X

Radio (2.4 GHz) BCM4331

Radio (5 GHz) BCM4360

Antenna Type External

(Dual Band)

Specifications found on Smallnetbuilder.net [1]•

D-Link_DIR-868L

Hardware 1

This Wiki page is for the Rev A model only! (for now)•

Installation Instructions

Step-by-step instructions from out-of-the-box factory

firmware

DD-WRT can be flashed directly on the D-Link DIR-868L by using the D-Link web interface:

Navigate to this page, select year, scroll down to the last link and select it, select dlink-dir868l-revc.

Now download the firmware file (dir868c-webflash.bin).

Open the D-Link web-interface in your web browser (address: http://192.168.0.1), Log In, and go to

Tools -> Firmware *Warning: only flash over an Ethernet-cable

Select factory-to-ddwrt.bin and click the "Upload"-button3. After flashing successfully, the router address should be changed into http://192.168.1.14. Upgrade the router (again) by using the dir-868-webflash.bin firmware5.

Note: The router doesn't support Hard Reset (aka 30/30/30 reset), use the Erasing NVRAM method

instead.

•

How to restore to factory firmware

Also works if you bricked your router.

Original post•

Download the stock firmware at

NA - DIR-868L_REVA_FIRMWARE_PATCH_1.10.FB.B04.ZIP♦ WW - DIR-868L_REVA_FIRMWARE_PATCH_1.10.B04_WW.ZIP♦

Set your computers IP manually to 192.168.0.2 with a standard subnet of 255.255.255.0. (like this on

Windows).

Unplug all cables (incl. power cable) from the router3. Insert a paper clip onto the hidden reset button located on the bottom of the device; you'll find it.4. Keep holding down the reset button as you plug in the power cable. Wait atleast 10 seconds until you

release the paper clip.

Connect your computer to the first LAN port.6. Navigate to 192.168.0.1 and upload the firmware you downloaded earlier. The router will flash it and

reboot automatically.

Now set your computer IP to automaticly detect, navigate to your gateway and login.8. Navigate to Tools - System and Restore Factory Settings.9.

D-Link_DIR-868L

Installation Instructions 2

Known Issues

Bad WiFi drivers

DD-WRT has multiple issues with WiFi firmware.

WiFi connect slow: you might experience slowness connecting your device to the AP. On Android it

always hangs at "Obtaining IP address" for ~10 seconds.

•

Link speed: the link speed on DD-WRT is not high as stock is. For example: DD-WRT has a link

speed for 5GHz of 200Mbit/s, on stock it is 433Mbit/s. Same goes for the 2.4GHz band.

•

5GHz band issue: the 5GHz band might not pop up when you search for WiFi networks on your

device, it will take ~10 seconds to show up to even be able to connect to it.

•

OpenVPN

If using the inbuilt OpenVPN-server in tunnel-mode, you may need to use the following firewall rules:

iptables -A INPUT -i vlan2 -m state --state NEW -p udp --dport 1194 -j ACCEPT

iptables -A INPUT -i tun2 -j ACCEPT

iptables -A FORWARD -i tun2 -j ACCEPT

iptables -A FORWARD -i tun2 -o vlan2 -m state --state RELATED,ESTABLISHED -j ACCEPT

iptables -A FORWARD -i vlan2 -o tun2 -m state --state RELATED,ESTABLISHED -j ACCEPT

iptables -t nat -A POSTROUTING -s 10.8.0.0/24 -o vlan2 -j MASQUERADE

Note 1: Verify that the interfaces are correct by running the ifconfig command• Note 2: You may need to adjust the above IP-address (& netmask)•

The following Additional DNSMasq Options may also be needed, to stop DHCP(-service) on the tunnel-port:

interface=tun2

no-dhcp-interface=tun2

D-Link DDNS

D-Link offers router owners a free dynamic DNS host name service. This service works (surprisingly) without

any problems on the dd-wrt firmware:

DDNS Service DynDNS.org

Username Your username (no

email-address)

Password Your Password

Hostname <hostname>.dlinkddns.com

Type Dynamic

D-Link_DIR-868L

Known Issues 3

IP Check Yes *only when needed

A working state should give verification messages, like this one:

Thu Jan 22 23:11:21 2015: INADYN: Started 'INADYN Advanced version 1.96-ADV' - dynamic DNS updater.

Thu Jan 22 23:11:21 2015: INADYN: IP read from cache file is 'x.x.x.x'. No update required.

D-Link_DIR-868L

D-Link DDNS 4
