D-Link DIR-605L Manual

-1-

FAQ : How to Save Config file for DIR-605L

Technical Support Setup Procedure

FAQ : How to Save Config file for DIR-605L

Release date : 12/04/2012

Model Support : DIR-605L

H/W:A1

S/W:1.00

-2-

FAQ : How to Save Config file for DIR-605L

Technical Support Setup Procedure

 Save Config file DIR-605L

Note: 

** firewall (Disable Firewall) 

login **

1 : (1,2,3,4 



2 : IE(Internet explorer) 192.168.0.1 address 

Enter http://dlinkrouter

3 : (Username) : admin  Login

-3-

FAQ : How to Save Config file for DIR-605L

4 : MAINTENANCE Save and

Restore Settings 

5 : Save

-4-

FAQ : How to Save Config file for DIR-605L

6 : save 

-5-

FAQ : How to Save Config file for DIR-605L

Technical Support Setup Procedure

How to Save Config file for DIR-605L

Please note use only hard-wired network connections, to do the setting.

** Disable firewall in your PC to avoid login problem**

Step 1: Connect Your PC (Laptop) to the Router (Port 1,2,3,4 either one of them) using

Network cable.

Step 2: Launch your IE (Internet explorer) and key in 192.168.0.1 in the address column

and press enter. You may also access via http://dlinkrouter

Step 3: Enter your Username: admin and leave the password blank then click on Log In

button.

Step 4: Click on the MAINTENANCE tab along the top and then on Click on Save and

Restore Settings on the left hand side.

-6-

FAQ : How to Save Config file for DIR-605L

Step 5: Click Save button.

Step 6: Choose a directory in your computer where you will save your settings.

-7-

FAQ : How to Save Config file for DIR-605L

 

Call Center  02-6617997

: 9.00 –18.00 

Thai: Mon –Fri : Time 9.00 –18.00.

: 18.00 

English : Sat –Sun , Public Holiday and after 18.00 weekday.

Website : www.dlink.co.th

email: [email protected].sg

Facebook : http://www.facebook.com/DLinkThailandFans

-8-

FAQ : How to Save Config file for DIR-605L

Nationwide D-Link Service Centres :

Nationwide D-Link Service Centres :
