D-Link DPN-144DG Manual de usuario

Quick Installation Guide

DPN-144DG

GPON ONT Dual Band Wireless AC1200

VoIP Gateway wit 1 GPON Port, 4

10/100/1000Base-T Ports, 2 FXS Ports,

and 1 USB Port

DPN-144DG Quick Installation Guide

BEFORE YOU BEGIN

Delivery Package

•GPON ONT VoIP gateway DPN-144DG

•Power adapter DC 12V/2.5A

•“Quick Installation Guide” ( rochure).

If any of the items are missing, please contact your reseller.

The “User Manual” and “Quick Installation Guide” documents are availa le

on D-Link we site (see www.dlink.ru).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

DPN-144DG Quick Installation Guide

Default Settings

IP address o device 192.168.0.1

Username (login) admin

Password admin

Name o wireless network

(SSID)

2.4GHz DPN-144DG

5GHz DPN-144DG-5G

Network key (PSK)

see WPS PIN on the

arcode la el on the

ottom panel of the

device

Gateway DPN-144DG with default settings cannot connect to the

Internet. To get started, please set your own password for access to the

we - ased interface; then, if needed, configure other settings

recommended y your ISP.

DPN-144DG Quick Installation Guide

System Requirements and Equipment

•A computer with any operating system that supports a we rowser.

•A we rowser to access the we - ased interface of the gateway:

◦Apple Safari 8 and later

◦Google Chrome 48 and later

◦Microsoft Internet Explorer 10 and later

◦Microsoft Edge 20.10240 and later

◦Mozilla Firefox 44 and later

◦Opera 35 and later.

•A NIC (Ethernet or Wi-Fi adapter) to connect to the gateway.

•An 802.11a, , g, n, or ac Wi-Fi adapter to create a wireless network.

•An analog phone.

•A USB modem (when it is necessary to connect to the Internet via mo ile

operators' networks)1.

Your USB modem should e equipped with an active identification

card (SIM or R-UIM) of your operator.

Some operators require su scri ers to activate their USB modems prior

to using them. Please, refer to connection guidelines provided y your

operator when concluding the agreement or placed on its we site.

For some models of LTE USB modems, it is required to disa le the PIN

code check on the SIM card prior to connecting the USB modem to the

gateway.

1 Contact your operator to get information on the service coverage and fees.

DPN-144DG Quick Installation Guide

CONNECTING TO PC

!Invisi le laser radiation may e emitted from the end of the fi er and/or

from DPN-144DG . Take all necessary precautions to avoid unnecessary

exposure to this radiation.

PC with Ethernet Adapter

1. Connect an Ethernet ca le etween any of LAN ports located on the ack

panel of the gateway and the Ethernet port of your PC.

2. To connect via USB modem: connect your USB modem to the USB port2

located on the ack panel of the gateway.

!In some cases you will need to re oot the gateway after connection of

the USB modem.

3. To connect the device to a fiber optic line: connect the fi er optic ca le

to the PON port on the ack panel of the gateway. Make sure that center

conductor of the ca le is inserted directly into the center of the PON

connector. Secure the ca le y carefully pushing the fi er connector onto

the PON connector until tight. Be careful not to over-tighten the

connector or you may damage either the ca le or the device.

4. To connect the device to an Ethernet line: in the we - ased interface of

the gateway, select the gateway's LAN port that will e used as the WAN

port and create an Ethernet WAN connection. Then connect an Ethernet

ca le etween an availa le Ethernet port of the gateway and the Ethernet

line.

!Please connect the gateway to the ISP's Ethernet line only after setting

the WAN port and creating the Internet connection.

5. Connect a phone ca le etween an FXS port of the gateway and the

phone.

6. Connect the power cord to the power connector port on the ack panel of

the gateway, then plug the power adapter into an electrical outlet or power

strip.

2 It is recommended to use a USB extension ca le to connect a USB modem to the

gateway.

DPN-144DG Quick Installation Guide

7. Turn on the gateway y pressing the POWER ON/OFF utton on its

ack panel.

8. Wait for several minutes. When the device receives all needed settings,

the PON LED will stop linking and will light solid green. When the

Internet connection is esta lished, the nternet LED will light solid

green.

Then make sure that your PC is configured to o tain an IP address

automatically (as DHCP client).

DPN-144DG Quick Installation Guide

Obtaining P Address Automatically

(OS Windows 7)

1. Click the Start utton and proceed to the Control Panel window.

2. Select the Network and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected from the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the Network and Internet

section.)

3. In the menu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Local Area Connection

icon and select the Properties line in the menu displayed.

5. In the Local Area Connection Properties window, on the

Networking ta , select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties utton.

DPN-144DG Quick Installation Guide

6. Make sure that the Obtain an IP address automatically and Obtain

DNS server address automatically choices of the radio uttons are

selected. Click the OK utton.

7. Click the OK utton in the connection properties window.

DPN-144DG Quick Installation Guide

PC with Wi-Fi Adapter

1. To connect via USB modem: connect your USB modem to the USB port3

located on the ack panel of the gateway.

!In some cases you will need to re oot the gateway after connection of the

USB modem.

2. To connect the device to a fiber optic line: connect the fi er optic ca le

to the PON port on the ack panel of the gateway. Make sure that center

conductor of the ca le is inserted directly into the center of the PON

connector. Secure the ca le y carefully pushing the fi er connector onto

the PON connector until tight. Be careful not to over-tighten the

connector or you may damage either the ca le or the device.

3. To connect the device to an Ethernet line: in the we - ased interface of

the gateway, select the gateway's LAN port that will e used as the WAN

port and create an Ethernet WAN connection. Then connect an Ethernet

ca le etween an availa le Ethernet port of the gateway and the Ethernet

line.

!Please connect the gateway to the ISP's Ethernet line only after setting

the WAN port and creating the Internet connection.

4. Connect the power cord to the power connector port on the ack panel of

the gateway, then plug the power adapter into an electrical outlet or power

strip.

5. Turn on the gateway y pressing the POWER ON/OFF utton on its

ack panel.

6. Make sure that the Wi-Fi adapter of your PC is on. As a rule, modern

note ooks with uilt-in wireless NICs are equipped with a utton or

switch that turns on/off the wireless adapter (refer to your PC documents).

If your PC is equipped with a plugga le wireless NIC, install the software

provided with your Wi-Fi adapter.

Then make sure that your Wi-Fi adapter is configured to o tain an IP address

automatically (as DHCP client).

3 It is recommended to use a USB extension ca le to connect a USB modem to the

gateway.

DPN-144DG Quick Installation Guide

Obtaining P Address Automatically and

Connecting to Wireless Network (OS Windows 7)

1. Click the Start utton and proceed to the Control Panel window.

2. Select the Network and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected from the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the Network and Internet

section.)

3. In the menu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Wireless Network

Connection icon. Make sure that your Wi-Fi adapter is on, then select

the Properties line in the menu displayed.

5. In the Wireless Network Connection Properties window, on the

Networking ta , select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties utton.
