D-Link DFE-528TX Manual de usuario

Contents of Package:Contents of Package:

DFE-528TX 10/100 Fast Ethernet Adapter

Quick Install Guide

CD-ROM, which includes driver software

If any of the above items are missing, please contact your reseller.

Requirements:Requirements:

•PowerPC-based Macintosh computer with free PCI slot

•Operating System 8.0 or higher

•A .SIT and .ZIP-compatible utility such as Aladdin Systems Stuffit or

Stuffit Expander. Aladdin currently provides a free download of Stuffit

Expander at their website at www.aladdinsys.com

Installation Procedure:Installation Procedure:

1.1. Install the DFE-528TX

2.2. Install the Drivers

3.3. Configure the Network Services

Installing the DFEInstalling the DFE--528TX into the528TX into the

computer’s PCI slotcomputer’s PCI slot

Note: Make sure that Aladdin Systems “Stuffit” or “Stuffit Expander” has been

installed on your computer before you continue with the installation.

•Turn OFF the computer

•Insert the DFE-528TX into an available PCI slot

Installing the DFEInstalling the DFE--528TX Drivers528TX Drivers

•Turn ON the computer

•Insert the CD-ROM into the Macintosh’s CD-ROM drive

Double click on the CD-ROM icon on the desktop

Double-click on the “Macintosh”folder.

-2-

Copy the folder “DFE-528TX Driver for Mac OS” to the desktop.

Double-click on the folder “DFE-528TX Driver for Mac OS”

Double-click on the “Installer” icon.

Click “Install” to continue.

-3-

Click “OK” to restart the computer.

After the computer restarts, the driver is installed.

Checking InstallationChecking Installation

of the DFEof the DFE--528TX Drivers528TX Drivers

Go to the Apple Menu>Controls Panel>Extensions Manager

Scroll down to find DFE-528. Make sure that the box to the left is checked.

Before the adapter can be used, you will need to configure network services as

shown in Step 4.-4-

Configuring Network ServicesConfiguring Network Services

1. Open the Apple menu.

2. Go to Control Panels>AppleTalk control panel.

3. Select Ethernet D-Link Port from the Connect via: list box.

4. Do not choose DFE-528 Ethernet. If you do not see it, go back to the

beginning of this guide and install the drivers again.

5. When the installation is successful, and you have completed this step, choose

“Quit” from the “File” menu.

6. Click “Save” when prompted to save the new settings.

7. Open the Apple menu again.

8. Go to Control Panels>TCP/IP control panel.

9. Select Ethernet D-Link Port from the Connect via: list box.

10. From the Configure: list box, choose “Using DHCP Server” if you are

automatically assigned a “Dynamic IP address.” If you are not automatically

assigned an IP address, choose “Manual” for a “Static IP address.”

11. Choose “Quit” from the “File” menu.

12. Click “Save” when prompted to save the new settings.

Restart your computer one more time.

Your adapter is now ready to network with other computers.

-5-

CONTACTING TECHNICAL SUPPORTCONTACTING TECHNICAL SUPPORT

You can find the most recent software and user documentation on the D-Link

website.

D-Link provides free technical support for customers within

the United States for the duration of the warranty period on

this product.

U.S. customers can contact D-Link technical support

through our web site.

Web:

http://www.dlink.com

-6-

Notes

-7-

Building Networks for People

Printed in Taiwan

Rev.1.0
