D-Link DFB-A5 Manual de usuario

USB 2.0 & Firewire

Combo PCI Adapter

DFB-A5DFB-A5

DFB-A5

This product can be used with theThis product can be used with the

This product can be used with the

following operating systems:following operating systems:

following operating systems:

Windows XP, Me, 2000, 98SEWindows XP, Me, 2000, 98SE

Windows XP, Me, 2000, 98SE

Macintosh OS v10.1Macintosh OS v10.1

Macintosh OS v10.1

Check Your Package Contents

Thesearetheitemsincludedwithyourpurchase:

If any of the below items are missing, please contact your reseller.

Before You Begin

Youmusthaveatleastthefollowing:

•WindowsXP/Me/2000/98SE orMacintoshOS v10.1

•Pentium Class CPU or Higher

•OneAvailablePCISlot

•CD-ROMDrive

• DFB-A5 USB 2.0 & Firewire Combo

PCI Adapter

• CD-ROM (containing Drivers,

Installation Guide and Warranty)

Run theDriver CD before you install theDFB-A5.

The Driver CD contains an installation program that

significantly simplifies the installation process.

Windows Users

Click Install Drivers

If the Autorun screen does not automatically start, click on Start > Run, enter

“D:\Autorun.exe” and click OK. “D” represents the letter of your CD-ROM drive.

Replace it if your CD-ROM drive is a different letter.

Only Windows XP users will

see this screen.

Click Continue Anyway

Insert the D-Link CD-ROM

Into Your Computer

Mac users please proceed to

the next page.

Turn on your computer and

insert the D-Link DFB-A5Driver

CD in the CD-ROM drive.

Select No and

Shut Down

your computer.

Installing The DFB-A5 Combo PCI

Adapter Into Your Computer

Remove the outer cover of your computer.

Refertoyourcomputermanualasneeded.

Remove the backplate. (The small piece

of metal that covers the opening for the

PCI card).

Make sure that your computer is turned OFFMake sure that your computer is turned OFF

Make sure that your computer is turned OFF

before you install the DFB-A5.before you install the DFB-A5.

before you install the DFB-A5.

Locate an available PCI slot and

insert theDFB-A5 carefully into the

PCI slot.

Secure theDFB-A5 with the screw from

the backplate. Replace your computer's

cover and plug in the power cord.

Turn OnTurn On

Turn On your computer.

PCI Slot

Windows XP Users

Completing The Driver Installation

Follow these steps to complete installation under Windows XP for each device that

Windows prompts you to install.

Click Next

Click Continue Anyway

Click Finish

Windows 2000 & Me Users

TheDFB-A5 driver installation will proceed automatically for Windows

2000 & Me users while Windows is starting.

Click Next

Click Continue Anyway

Click Finish

Windows 98SE Users

Click Next

Select only

CD-ROM

drive

Windows 98SE Users

Click Finish

When prompted, Restart Your

Computer to complete the installation.

Windows 98SE may prompt

you for the Windows 98SE

Setup disk. If prompted,

insert the Windows 98SE

Setup disk and select OK.

Click Next

Macintosh OS X 10.1 Users

Double-click DFB-A5 when it

appears on the desktop

Double-click

USB2EHCI_V1033 when

it appears on the desktop

Insert the DFB-A5 Driver CD

into the CD-ROM drive.

Drag-&-drop

USB2EHCI_V1033_1130.img

to the desktop

Double-click

USB2EHCI-

V1033_1130.

IMG from the

desktop

Double-click

USB2EHCI_V1033.pkg

Macintosh OS X 10.1 Users

Enter your Name

& Password

Click the Lock

Click Continue

Click OK

Macintosh OS X 10.1 Users

Click Continue

Select a

Destination

Volume

Click Install

Click Continue

Installation
