D-Link DBT-122 Manual de usuario

Version 2.0

D-Link DBT-122

Bluetooth USB Adapter

Manual

(23 June 2006)

Contents

Package Contents ................................................................ 4

System Requirements .......................................................... 4

Introduction........................................................................... 5

Installing the Bluetooth Software.......................................... 6

Using the Bluetooth Conguration Wizard.......................... 10

Introduction to the Bluetooth Software ............................... 13

Bluetooth Tray....................................................... 13

Access My Bluetooth Places ................................ 13

Icons Used for Bluetooth Devices and Services... 14

Bluetooth Software Basic Operations................................. 17

Start or Stop Bluetooth ......................................... 17

Create a Connection............................................. 17

Find Bluetooth Devices......................................... 18

Find A Service....................................................... 19

Bluetooth Connection Status ................................ 20

Send to Bluetooth ................................................. 21

Bluetooth Conguration...................................................... 22

Access the Bluetooth Conguration Panel ........... 22

Bluetooth Services versus Bluetooth Applications 22

Bluetooth Exchange Folder .................................. 22

Bluetooth Applications Overview .......................... 23

Applications > Human Interface Device (HID)...... 24

Applications > HID, Audio Gateway...................... 25

Applications > Serial Port ..................................... 26

Applications > Dial-up Networking........................ 27

Applications > Fax, Headset................................. 28

Applications > Headset......................................... 29

Applications > Headset, File Transfer................... 30

Applications > Network Access ............................ 32

Applications > PIM................................................ 33

Applications > My Headset / Audio Gateway........ 36

Applications > Printer............................................ 38

Bluetooth Services................................................ 40

Services > Notications ........................................ 41

Services > Audio Gateway Service ...................... 42

Services > Bluetooth Serial Port Service.............. 43

Services > Dial-up, Fax, File Transfer Service ..... 44

Services > Headset .............................................. 45

Services > Network Access ................................. 46

Services > PIM ..................................................... 47

Hardware Settings ................................................ 51

Advanced Settings................................................ 52

Accessibility Settings ............................................ 53

Discovery Settings................................................ 54

Security............................................................................... 56

Troubleshooting.................................................................. 58

Contacting Technical Support............................................. 62

Contents (cont’d)

Bluetooth Conguration (cont’d)

Package Contents

These items are included with your purchase:

D-Link DBT-122 USB Bluetooth Adapter

USB Extension Cable

Installation CD with Driver, Manual, Quick Installation Guide, & Bluetooth

Software

If any of the above items are missing, please contact your reseller.

System Requirements

Windows XP/Me/2000/98SE

One Available USB Port

CD-ROM Drive

•

Introduction

Introduction to Bluetooth

The term “Bluetooth” refers to a worldwide standard for the wireless

exchange of data between two devices within a Personal Area Network.

In order to exchange data, two Bluetooth devices must establish a

connection. Before a connection is established, one device must request a

connection with another, where the second device accepts (or rejects) the

connection. The originator of the request is known as the client. The device

that accepts (or rejects) the request is known as the server. Many Bluetooth

devices can act as both client and server. A client Bluetooth device runs a

software program that requests a connection to another device as part of

its normal operation. For example, the program may request a connection

to a remote computer, a printer, or a modem.

Becoming a Bluetooth client normally requires an action by the device

operator, such as an attempt to browse a remote computer, print a le,

or dial out on a modem. Every Bluetooth device that provides a service

must be prepared to respond to a connection request. Bluetooth software

is always running in the background on the server, ready to respond to

connection requests.

Introduction to the DBT-122 Bluetooth USB Adapter

The D-Link Bluetooth USB Adapter is the perfect wireless solution for quick

and easy access to Bluetooth enabled devices. It is a class 2/3 low power

device and is bundled with Bluetooth Software which allows you to connect

to several Bluetooth devices at once. The wireless transmission range of

the D-Link DBT-122 Bluetooth USB Adapter is about 10 meters (30 feet). A

PC congured as the Bluetooth server can support up to seven Bluetooth

client devices with IP addresses being automatically assigned upon a

successful connection. The Bluetooth Software also provides Internet

sharing and security access between the server and clients.

After nishing the steps outlined in this manual, you will have the ability

to share information, obtain network access, and take full advantage of a

wireless connected environment.

Installing the Bluetooth Software

Uninstalling a previous version of the Bluetooth

software:

If you are installing the Bluetooth software for the rst time, please skip this

section.

Any previous versions of the Bluetooth software must be uninstalled before installing

an upgraded version.

Please uninstall the software by completing these steps:

1) Close any open programs and insert the Driver CD into your CD-ROM Drive.

2) The Autorun screen will appear. Click on Install Bluetooth Software.

3) The Welcome screen will indicate the previous version of BTW that is

currently installed. Click on the Next button to continue.

4) Click on the Remove button from the Remove the Program screen.

5) When the les have been removed, you will be presented with a screen

informing of its completion.

a. Click on the Finish button

b. Click on the Yes button when the pop-up dialog box appears on the

screen to reboot your PC.

You have now removed the previous version of the Bluetooth software.

Installing the Bluetooth Software

Install the driver and software located on the D-Link CD that came with your

purchase BEFORE installing the DBT-122 USB Bluetooth Adapter into your

computer.

Click Install

Driver

Insert the D-Link PersonalAir DBT-122 Driver CD in the CD-ROM drive.

If this Autorun screen does not

automatically appear, click on Start >

Run, enter “D:\Autorun.exe” and click

OK. “D” represents the letter of your

CD-ROM drive.

Click Next

Installing the Bluetooth Software (cont’d)

Click Accept

Click Next

Click OK

Installing the Bluetooth Software (cont’d)

Click Install

Only Windows XP and

Windows 2000 Users will

see this screen.

Installing the Bluetooth Software (cont’d)

Click OK

When this screen appears,

connect the DBT-122 to an

available USB port on your

USB host adapter or USB hub.

Click Finish

Installing the Bluetooth Software (cont’d)

Click Yes

After you have completed the driver and software installation and reboot your

computer, a Bluetooth icon will appear on your desktop and in the bottom right hand

corner of your desktop screen (systray). The Bluetooth icon gives you access to My

Bluetooth Places, for conguring your Bluetooth settings.

Double-click the Bluetooth icon for access to

My Bluetooth Places.

Using the Bluetooth Conﬁguration Wizard

Only Windows 2000,

Windows Me, and Windows

98SE Users will see this

screen.
