Cypress Semiconductor PSoC 3 FirstTouch Manual de usuario

CY8CKIT-003

PSoC®3 FirstTouch™ Starter Kit Guide

Spec. # 001-49613 Rev. *B

Cypress Semiconductor

198 Champion Court

San Jose, CA 95134-1709

Phone (USA): 800.858.1810

Phone (Intnl): 408.943.2600

http://www.cypress.com

Downloaded from Elcodis.com electronic components distributor

2 CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B

Copyrights

Semiconductor Corporation assumes no responsibility for the use of any circuitry other than circuitry embodied in a Cypress

product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted nor

intended to be used for medical, life support, life saving, critical control or safety applications, unless pursuant to an express

written agreement with Cypress. Furthermore, Cypress does not authorize its products for use as critical components in life-

support systems where a malfunction or failure may reasonably be expected to result in significant injury to the user. The

inclusion of Cypress products in life-support systems application implies that the manufacturer assumes all risk of such use

and in doing so indemnifies Cypress against all charges.

Any Source Code (software and/or firmware) is owned by Cypress Semiconductor Corporation (Cypress) and is protected by

and subject to worldwide patent protection (United States and foreign), United States copyright laws and international treaty

provisions. Cypress hereby grants to licensee a personal, non-exclusive, non-transferable license to copy, use, modify, create

derivative works of, and compile the Cypress Source Code and derivative works for the sole purpose of creating custom soft-

ware and or firmware in support of licensee product to be used only in conjunction with a Cypress integrated circuit as speci-

fied in the applicable agreement. Any reproduction, modification, translation, compilation, or representation of this Source

Code except as specified above is prohibited without the express written permission of Cypress.

Disclaimer: CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS MATE-

RIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE. Cypress reserves the right to make changes without further notice to the materials described

herein. Cypress does not assume any liability arising out of the application or use of any product or circuit described herein.

Cypress does not authorize its products for use as critical components in life-support systems where a malfunction or failure

may reasonably be expected to result in significant injury to the user. The inclusion of Cypress’ product in a life-support sys-

tems application implies that the manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all

charges.

Use may be limited by and subject to the applicable Cypress software license agreement.

PSoC Designer™, and Programmable System-on-Chip™ are trademarks and PSoC® is a registered trademark of Cypress

Semiconductor Corp. All other trademarks or registered trademarks referenced herein are property of the respective corpora-

tions.

Flash Code Protection

Cypress products meet the specifications contained in their particular Cypress PSoC Data Sheets. Cypress believes that its

family of PSoC products is one of the most secure families of its kind on the market today, regardless of how they are used.

There may be methods, unknown to Cypress, that can breach the code protection features. Any of these methods, to our

knowledge, would be dishonest and possibly illegal. Neither Cypress nor any other semiconductor manufacturer can guaran-

tee the security of their code. Code protection does not mean that we are guaranteeing the product as "unbreakable."

Cypress is willing to work with the customer who is concerned about the integrity of their code. Code protection is constantly

evolving. We at Cypress are committed to continuously improving the code protection features of our products.

Downloaded from Elcodis.com electronic components distributor

CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B 3

Contents

1. Introduction 5

1.1 Welcome......................................................................................................................5

1.2 Kit Contents .................................................................................................................5

1.3 Document Revision History ........................................................................................6

1.4 Documentation Conventions .......................................................................................6

2. Getting Started 7

2.1 Hardware .....................................................................................................................7

3. Installation 9

3.1 Install Hardware...........................................................................................................9

3.1.1 Hardware Jumpers...........................................................................................9

3.2 Install Software ..........................................................................................................10

4. Example Projects 13

4.1 PSoC Rocks ..............................................................................................................13

4.1.1 Open the PSoC Rocks Project.......................................................................13

4.1.2 Modify the PSoC Rocks Project .....................................................................13

4.1.3 Build, Program, and Run the PSoC Rocks Project ........................................14

4.1.4 Schematic Design PSoC Creator...................................................................15

4.1.5 How the PSoC Rocks Project Works .............................................................16

4.1.6 PCB Schematic ..............................................................................................18

4.2 Bubble Level Emulator...............................................................................................19

4.2.1 How the Bubble Level Emulator Project Works .............................................20

4.2.2 PCB Schematic ..............................................................................................21

4.3 ThermistorTemperatureSense ...................................................................................22

4.3.1 How the ThermistorTemperatureSense Project Works ..................................22

4.3.1.1 Temperature Sensing Design Principle ...........................................23

4.3.2 PCB Schematic ..............................................................................................24

4.4 CapSense Slider........................................................................................................25

4.4.1 How the CapSense Slider Project Works.......................................................25

4.4.2 PCB Schematic ..............................................................................................27

4.5 Proximity Sensor........................................................................................................28

4.5.1 How the Proximity Sensor Project Works ......................................................29

4.5.2 PCB Schematic ..............................................................................................30

5. Technical Reference 31

5.1 PSoC 3 FirstTouch Starter Kit Schematic..................................................................32

5.1.1 Hardware Jumpers.........................................................................................33

5.1.2 Board Layout..................................................................................................34

5.1.3 Bill of Material (BOM) ....................................................................................36

5.2 PSoC 3 Pin Assignment on PSoC 3 FirstTouch Starter Kit Board ............................39

Downloaded from Elcodis.com electronic components distributor

4 CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B

Contents

Downloaded from Elcodis.com electronic components distributor

CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B 5

1. Introduction

1.1 Welcome

Thank you for purchasing the CY8CKIT-003 PSoC® 3 FirstTouch™ Starter Kit.

The PSoC 3 FirstTouch Starter Kit is designed to introduce you to the PSoC programmable system-

on-chip design methodology and Cypress's new PSoC 3 architecture. This full-featured starter kit

ships with an array of sensors, I/O's, projects and software to quickly get you up to speed with PSoC

Creator and our powerful design methodology so you can easily evaluate PSoC and see what

values the solution can provide you.

This kit, in addition to our new PSoC 3 architecture, features the following:

■PSoC Creator development software with an integrated, free-edition Keil C51 Compiler

■USB-based Serial Wire Debugging protocol programmer and debug interface

■Accelerometer analog sensor

■Thermistor analog sensor

■Proximity analog sensor

■CapSense®analog touch-sensing interface

■28-pin general purpose I/O pins

■12-pin wireless module header

In this guide you will find instructions on how to easily evaluate the PSoC 3 architecture and PSoC

Creator design methodology through five included example projects. Experience the development

software for yourself and discover how we truly have changed the way you change the world!

If you have questions about or need help with this kit, visit our online technical support center at

http://www.cypress.com/go/support for support options, or contact your local Cypress sales

representative or authorized distributor.

1.2 Kit Contents

PSoC 3 FirstTouch Starter Kit contains:

■Evaluation Board

■Quick Start Guide

■Kit CD

■Retractable USB A to Mini B cable

■Proximity wire (for use as proximity detection antenna)

■9V battery

Downloaded from Elcodis.com electronic components distributor

6 CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B

Introduction

1.3 Document Revision History

1.4 Documentation Conventions

Table 1-1. Revision History

Revision PDF

Creation Date

Origin of

Change Description of Change

** 02/19/09 KKU/VED New kit user guide.

*A 06/19/09 KKU/

AESA Updated Guide to the latest FTK Board Revision

*B 07/28/09 KKU Updated Guide to the latest FTK Board Revision

Table 1-2. Document Conventions for Guides

Convention Usage

Courier New Displays file locations, user entered text, and source code:

C:\ ...cd\icc\

Italics Displays file names and reference documentation:

Read about the sourcefile.hex file in the PSoC Designer User Guide.

[Bracketed, Bold]Displays keyboard commands in procedures:

[Enter] or [Ctrl] [C]

File > Open Represents menu paths:

File > Open > New Project

Bold Displays commands, menu paths, and icon names in procedures:

Click the File icon and then click Open.

Times New Roman Displays an equation:

2 + 2 = 4

Text in gray boxes Describes Cautions or unique functionality of the product.

Downloaded from Elcodis.com electronic components distributor

CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B 7

2. Getting Started

2.1 Hardware

The PSoC 3 FirstTouch Starter Kit contains these components and sensors.

Figure 2-1. PSoC 3 FirstTouch Starter Kit

The components indicated in Figure 2-1 are:

1. PSoC 3 100-pin TQFP (Cypress CY8C3866AXI-040 TQFP100)

2. Proximity Sensor Connector (Samtec Inc, BCS-101-L-S-HE)

3. Three Axis Accelerometer (Kionix, KXSC7-2050)

4. Five Segment CapSense Slider

5. Bank of Eight LEDs (Also Referred as LED Display in this user guide)

6. Thermistor (Murata, NCP21XV103J03RA)

7. Wireless Expansion Connector

8. General Purpose Expansion Connector (22 GPIO, 2 VDD, 2 GND, 2 SIO)

9. USB Programming and Debugging Interface (Cypress CY7C68013A-56LFXC)

10. USB Connector

11. 9V DC Battery Holder

12. Jumper J1 Vddio Power Source Select

13. Jumper J4 Voltage Regulator Source Select

14. Voltage Regulator (Zetex Inc, ZLDO330)

15. General Purpose Push Button Switch

15. General Purpose 1. CY8C3866AXI

2. Proximity Sensor Connector

3. Accelerometer

4. CapSense Slider

14. Voltage

11. 9V Battery

10. USB Mini B 9. CY7C68013A

8. 28-Pin External

7. 12-Pin Wireless

6. Thermistor

5. Eight Red LED Outputs

Header

FX2LP High Speed USB

PSoC 3 Device

Port I/O (on reverse)

Header

Regulator

Switch

13. Jumper J4

12. Jumper J1

Downloaded from Elcodis.com electronic components distributor

8 CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B

Getting Started

Downloaded from Elcodis.com electronic components distributor

CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B 9

3. Installation

3.1 Install Hardware

This section shows you how to use the PSoC 3 FirstTouch Starter Kit.

Note: This kit comes with a factory programmed demonstration to display "PSoC Rocks!" message

on the LED display when the board is waved.

1. Unpack the PSoC 3 FirstTouch Starter Kit.

2. Connect a 9V DC battery to the battery connector on the kit board.

3. Hold the board and battery exposing the LEDs. Then continuously wave the board from side to

side in the plane of the PCB (shown in Figure 3-1).

4. As you wave the board, the rasterized image of the message "PSoC Rocks!" appears as shown

in the following figure.

5. Keep waving. The message changes every few seconds.

Figure 3-1. Rasterized Image of "PSoC Rocks!"

3.1.1 Hardware Jumpers

There are two jumpers for power configuration. All examples are run with the default setup of 3.3V

operation. This requires J1-2 to connect to J1-3 and J4-2 to connect to J4-3. For all other configura-

tions see section 5.1.1 Hardware Jumpers on page 33.

Downloaded from Elcodis.com electronic components distributor

10 CY8CKIT-003 PSoC 3 FirstTouch Starter Kit Guide, Spec. # 001-49613 Rev. *B

Installation

3.2 Install Software

When installing the PSoC 3 FirstTouch Starter Kit, the installer checks if the prerequisites, PSoC

Creator, PSoC Programmer, Windows Installer, Windows.NET, Acrobat Reader, and Keil C51

Compiler, are installed in your PC. If these applications are not installed, then the installer prompts

you to install them.

1. Insert the Kit CD into the your PC. The CD is designed to automatically open an installation

dialog (see Figure 3-3). If this does not automatically open, do manually open this by running the

cyautorun.exe utility on the kit cd.

Figure 3-2. Auto Run File View

2. The kit cd's installation dialog prompts you to open this file or begin installing the development

environment software. Click the Install PSoC 3 FirstTouch Starter Kit menu item to begin this

installation.

Figure 3-3. Installation Dialog.

3. As specified, this installation process first determines if you have all prerequisite software. Follow

the on-screen dialogs to complete all required installations. After following these steps, you must

have the following software installed:

a. PSoC Creator 1.0

b. PSoC Programmer 3.10

c. Keil C51 Compiler (Cypress edition)

Downloaded from Elcodis.com electronic components distributor

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de computadora de Cypress Semiconductor

Cypress Semiconductor

Cypress Semiconductor CY7C2563KV18 Guía rápida

Cypress Semiconductor

Cypress Semiconductor CY62148E Manual de usuario

Cypress Semiconductor

Cypress Semiconductor FM4-216-ETHERNET Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY7C1511V18 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY8CNP102B Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY62167EV30 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor PSoC CapSense CY8CKIT-031 Manual

Cypress Semiconductor

Cypress Semiconductor CY7C1012DV33 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor SL811HS Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY7C1146V18 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY7C0241AV Manual de usuario

Cypress Semiconductor

Cypress Semiconductor MoBL CY62157EV30 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor Perform CY7C1511KV18 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY7C1292DV18 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor NoBL CY7C1355C Manual de usuario

Cypress Semiconductor

Cypress Semiconductor STK22C48 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor MoBL CY62157E Manual de usuario

Cypress Semiconductor

Cypress Semiconductor Perform CY62147EV30 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY7C1546V18 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor Z9973 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor PSoC FirstTouch CY3261A-RGB Manual de usuario

Cypress Semiconductor

Cypress Semiconductor Perform STK16C88-3 Manual de usuario

Cypress Semiconductor

Cypress Semiconductor FM0+ S6E1C Series Manual de usuario

Cypress Semiconductor

Cypress Semiconductor CY7C1215H Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
