CYP CDPS-44SM Manual de usuario
CDPS-44SM
HDMI 4x4 Seamless Matrix Switcher
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and is be-
lieved to be accurate. Cypress Technology assumes no responsibility
for any infringements of patents or other rights of third parties which
may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no com-
mitment to update or to keep current the information contained in
this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, tran-
scribed, stored in a retrieval system, or any of its part translated into
any language or computer le, in any form or by any means—elec-
tronic, mechanical, magnetic, optical, chemical, manual, or other-
wise—without express written permission and consent from Cypress
Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version 1.0 January 2012
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 21/09/26 Preliminary Release
RDV2 17/04/13
RDV3 04/06/13 Matrix mode 1080i@50/60 IN4
Disabled
CONTENTS
1. Introduction........................................... 1
2. Applications.......................................... 1
3. Package Contents ............................... 1
4. System Requirements........................... 1
5. Features................................................. 2
6. Operation Controls and Functions...... 3
6.1 Front Panel ....................................... 3
6.2 Rear Panel........................................ 5
6.3 Remote Control............................... 6
6.3.1 Remote Control Dip Switch......... 7
6.4 RS-232 Protocols .............................. 7
6.5 RS-232 & Telnet Commands........... 8
6.6 RS-232 & Telnet control................. 10
6.7 Telnet Setting ................................. 11
6.8 OSD MENU...................................... 11
7. Connection Diagram ......................... 15
8. Specications ..................................... 16
9. Timing .................................................. 17
9.1 Input Support Timing ..................... 17
9.2 Output Support Timing ................. 18
1
1. INTRODUCTION
The 4 by 4 HDMI Seamless Matrix Switcher allows the signal from 4 dif-
ferent input sources to be freely selected and arranged on 4 displays
(TV or monitor), providing three output modes (Matrix, Dual and TV
Wall) for various applications. Matrix mode routes the source signals
to output displays as regular matrix does, Dual mode allows 2 sets of
2 selected sources to show on designate output displays with POP
method and TV Wall mode extends a selected source to display on
all 4 output displays as one. The device supports video timings up to
WUXGA@60RB and 1080p@60Hz, audio format up to 7.1CH LPCM at
192kHz sampling rate based on input source EDID. For all the opera-
tion/control can be done through IR, remote control, Telnet, RS-232 or
front panel buttons.
2. APPLICATIONS
• Broadcasting room and control
• Surveillance room and control
• Public advertisement and control
• Digital Presentation
• Conference call or meeting room presentation
3. PACKAGE CONTENTS
• 1 x 4 by 4 Seamless Matrix Switcher
• 1 x Remote Control (CR-125)
• Software CD Driver (Optional)
• 1 x 12V/3A DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipments such as DVD/Blu-ray players or any video
signal and PC/Notebook devices and output HD TV/monitor.
2
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Deep color support 8/10/12 bit source
• Seamless switching
• Supports three different modes: Matrix mode/ Dual mode/ TV Wall
mode
■ Matrix mode: Can routes and output any 4 source to any 4 dis-
plays with seamless switching
Note: Under output timing 1080i@50/60 input 4 will be disabled,
OSD will show “IN 4 Disabled”
■ Dual mode: Can display POP (Picture Of Picture) image com-
bined by 2 sources to be presented on the HDMI output ports
(Dual A and Dual B)
■TV Wall mode: Can output any source to 4 displays (2 by 2
Video wall) as a full image with adjustable Bezel Correction for 4
displays
• Supports OSD, RS232, Telnet, Remote control and on-panel controls
• Input resolutions support VGA~WUXGA and 480i~1080p
• Output resolutions support 480p~1080p
• Supports different input resolution and output resolution selectable
from OSD menu. The factory default value for the output resolution
is 720p@60Hz/ 2CH LPCM
• Audio supports LPCM 2CH, 6CH, 8CH/AC3/DTS/Dolby Digital Plus/
Dolby TruHD & DTS-HD
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
-
+
1
INPUT 234SAVERECALL
A
OUTPUT BCD
4X4 SEAMLESS MATRIX CDPS-44SM
LOCK
MATRIX/
DUAL/WALL
XGA
720P
MENU
1 2 3 4 5 8 9
6 7
1IR Window:
Accept IR signal from the device’s remote control included in the
package.
2Power
ON/OFF: Press this button to power on the device or set it to
standby mode.
Factory default: Press Power then connect power supply to
reset the system to Factory default setting.
3MENU:
Press this button to bring up the OSD menu on screen.
Press “MENU” with “-“button to switch output timing to 720P@60Hz
instantly.
Press “MENU” with “+” button to switch output timing to XGA
(1024x768@60Hz) instantly.
4-/+ Buttons:
Press these buttons to scroll down/up the OSD selections then press
“MENU” button to conrm.
5CHANNEL INPUT 1~4 and CHANNEL OUTPUT A~D:
Matrix mode:
i. Press “Matrix/Dual/Wall” button to switch to Matrix mode and
LED will illuminate constantly.
ii. Press an output from A~D and then press corresponding input
from 1~4. For example: press output A then press input 1,
output A will display input 1’s image. Each output setting must
be made individually.
4
Dual mode: To combine 2 sources to be presented on each
HDMI output ports (Dual A and Dual B).
i. Press “Matrix/Dual/Wall” button to switch to Dual mode and
LED unilluminate.
ii. Press output A/B and then press corresponding input 1/2. For
example: press output A then press input 1, output A will
display input 1’s image on the left side, then press output B
and then press input 2, output A will display input 2’s image
on the right side. Both output A and B will have identically
image.
iii. Dual A group are output A and B, Dual B group are output C
and D. Each group will output the same image
simultaneously.
iv. Press button A or B for 3 seconds, to switch Dual A channel’s
audio between output A or B.
v. Press button C or D for 3 seconds, to switch Dual B channel’s
audio between output C or D.
TV Wall mode:
i. Press “Matrix/Dual/Wall” button to switch to TV Wall mode
and LED will blink constantly.
ii. Press input 1~4 to select a source to 4 displays (2 by 2 Video
wall). The audio will be on output A only.
6MATRIX/DUAL/WALL:
Press to switch between Matrix mode, Dual mode and TV Wall
mode. When in Matrix mode the LED will illuminate constantly,
when in DUAL mode the LED will unilluminate and when in TV Wall
mode the LED will blink constantly.
7LOCK:
Press once to lock the keypad and remote control, press 3 second
again to release the lock function.
8SAVE:
To save the customized input and output corresponding settings.
Press “Matrix/Dual/Wall” button to select mode status.
Press each output channel A~D and then press corresponding
input channel 1~4.
Press “SAVE”, the input 1~4 LEDs will all illuminate at the same
5
time, then press input 1/2/3 or 4 to save to the system memory.
For example: Select Matrix mode, press output A then press
input 4, then press “SAVE”. This will corresponding to remote
control FAV.1~FAV.4.
9RECALL:
When in the mode status “Matrix, Dual or Wall”, press “RECALL”
and the input channel 1~4 LED will illuminate at the same time,
and select input channel 1/2/3 or 4 to recall the customized
screen settings and this will corresponding to remote control
FAV.1~FAV.4.
6.2 Rear Panel
4321 DCBACONTROL
RS232 DC 12V
USB
SERVICE
ONLY
HDMI IN HDMI OUT
1 2 3 4 5 6
1HDMI IN 1~4:
Connect with HDMI source equipments such as DVD/Blue-ray play-
ers and or PC/Notebook devices.
2HDMI OUT 1~4:
Connect with HDMI TV/Monitor/Recorder for output image display
or saving.
3Control:
Connect to an active network for telnet control (Please refer to 6.5
telnet Commands).
4USB SERVICE ONLY:
This slot is reserved for factory use only.
5RS-232:
Connect from PC/Notebook with D-Sub 15pin cables for RS-232
command sending and controling over the device.
6DC 12V:
Plug the 12V DC power supply into the unit and connect the
adaptor to an AC outlet.
