Cross Technologies 2017-1727-140 Manual de usuario

Instruction Manual

Model 2017-1727-140

Up/Downconverter

February 2018, Rev. 0

EXECUTE

MODEL 2017

CROSS TECHNOLOGIES INC.

U F=1725 G=+10.0

D F=2675 G=+25.0

MUTE

UPCONVERTERDOWNCONVERTER

REMOTEALARM POWER ALARM

UP/DOWNCONVERTER

Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc., but may be

reproduced or duplicated without the prior permission of Cross Technologies, Inc. for purposes of operating

the equipment.

When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number,

equipment serial number, and a description of the part.

CROSS TECHNOLOGIES, INC.

6170 Shiloh Road

Alpharetta, Georgia 30005

(770) 886-8005

FAX (770) 886-7964

Toll Free 888-900-5588

WEB www.crosstechnologies.com

E-MAIL [email protected]

INSTRUCTION MANUAL

MODEL 2017-1727-140 Up/Downconverter

TABLE OF CONTENTS PAGE

Warranty 2

1.0 General 3

1.1 Equipment Description 3

1.2 Technical Characteristics 4

1.3 Monitor & Control Interface 6

2.0 Installation 8

2.1 Mechanical 8

2.2 Rear I/O’s 9

2.3 Front Panel Controls, Indicators 10

2.4 Operation 11

2.5 Menu Settings 12

WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.

All Cross Technologies, Inc. products are warranted against defective materials and

workmanship for a period of one year after shipment to customer. Cross Technologies, Inc.’s

obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s option,

replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall not be

liable for any special, indirect, or consequential damages. This warranty does not cover parts

or equipment which have been subject to misuse, negligence, or accident by the customer

during use. All shipping costs for warranty repairs will be prepaid by the customer. There

are not other warranties, express or implied, except as stated herein.

CROSS TECHNOLOGIES, INC.

6170 Shiloh Rd.

Alpharetta, GA 30005

(770) 886-8005

FAX (770) 886-7964

Toll Free 888-900-5588

WEB www.crosstechnologies.com

E-MAIL [email protected]

2017-1727-140 Manual, Rev. 0 Page 2 02/14/18

MODEL 2017-1727-140 Up/Downconverter

1.0 General

1.1 Equipment Description

The 2017-1727-140 L, S-band Up/Downconverter converts 140 ± 20 MHz to 0.95-1.75 GHz GHz (Up) and 2.0-

2.7 to 140 ± 20 MHz (Down) in 1 MHz steps (100 or 125 kHz steps optional). Multi-function switches select

the frequency, gain ( upconverter -10 to +30 dB; downconverter 0 to +50 dB), and other parameters. Front panel

LEDs provide indication of DC power (green), PLL alarm (red), remote operation (yellow), and Upconverter

mute (yellow). Remote operation allows selection of frequency, gain and external 10 MHz reference (option E).

Gain settings appear on the LCD display. Connectors are BNC female for the IF, RF (SMA and N optional) and

optional external reference input and output (option E). A high stability (±0.01 ppm) option (H) is also

available. It is powered by a 100-240 ±10% VAC power supply and housed in a 1.75” X 19” X 16” 1RU

chassis.

EXECUTE

MODEL 2017

CROSS TECHNOLOGIES INC.

U F=1725 G=+10.0

D F=2675 G=+25.0

MUTE

UPCONVERTERDOWNCONVERTER

REMOTEALARM POWER ALARM

UP/DOWNCONVERTER

FRONT PANEL

AC UPCONVERTER

RF OUT

GND

DOWNCONVERTER

J4 J5J3J18J2

RF IN 10 MHZ REF 10 MHZ IF IN

EXT REF

IF OUT OUTPUT INPUT

J10

AND

MONITOR

CONTROL

J20

REAR PANEL

Figure 1.1 Model 2017-1727-140 Front and Rear Panels

PLL,ATT, CONTROL

M&C

CONTROLLER

140 ± 20

MHz

OUT

2.0

2.7

GHz

0.2 GHz LP

2017-1727-140 Up/Downconverter Block Diagram

EXT**

10 M

PLLS

140 ± 20

MHz

IN 2.4 GHz BP

0.95

1.75

GHz

OUT

1.75

GHz BP

0.2GHz LP

S Downconverter

L Upconverter

2.7 GHz LP

2.54

GHz

3.75 - 4.45

GHz 1.89

GHz

3.35-

4.15

GHz

1.75 GHz LP

**OPTIONAL**

Figure 1.2 Model 2017-1727-140 Up/Downconverter Block Diagram

2017-1727-140 Manual, Rev. 0 Page 3 02/14/18

1.2 Technical Characteristics

TABLE 1.0 2017-1727-140 Up/Downconverter Specifications*

--------UPCONVERTER--------

Input Characteristics

Impedance/Return Loss 50 Ω/14 dB

Frequency 140 ± 20 MHZ

Noise Figure, Maximum 20 dB @ max. gain

Input Level Range -40 to -10 dBm

Output Characteristics

Impedance/Return Loss 50 Ω/14 dB

Frequency (GHz) 0.95 to 1.75 GHz

Output Level Range -20 to 0 dBm

1 dB comp. maximum gain +5 dBm

Mute @ 0 dBm out >60 dB

Channel Characteristics

Gain, max. at Fc +30 ±3 dB

Gain range, 1 ±1 dB steps +30 dB to -10 dB

Image Rejection N/A

Spurious, Inband, sig. rel. <-50 dBC 0 dBm

Spurious, Inband, sig. ind. <-50 dBC Gmax.

Spurious, Out of Band <-50 dBC Gmax

Intermod - 2 Carriers <-50 dBC Gmax

Frequency Resp. Band ±2 dB

Frequency Resp. 36,40 MHz ± 0.5 dB, ±1.0 dB

Frequency Sense Non-inverting

--------UP AND DOWNCONVERTER--------

Synthesizer Characteristics

Frequency Accuracy ± 1.0 ppm internal reference (±0.01 ppm, option -H)

Frequency Step 1 MHz, others optional

10 MHz In/Out Level 3 dBm ± 3 dB, 75 ohms (Option E)

-110-95-80-70-70

1MHz100kHz10kHz1kHz100 Hz

dBC/Hz

Phase Noise

Fre

Controls, Indicators

Gain Selection Direct readout LCD; pushbutton switches or remote selection

Power Green LED

Alarm; Remote Red LED, Yellow LED

Remote RS232C, 9600 baud; (RS485, option Q, Ethernet, optional)

Other

RF/IF Connector BNC (female) 50ΩRF, 75ΩIF

10 MHz Connectors BNC (female), 75Ωconnector works with 50 or 75 ohms

Alarm/Remote Connector DB9 (female) - NO or NC contact closure on Alarm

Size 19 inch, 1RU standard chassis 1.75”high X 16.0”deep

Power 100-240 ±10% VAC, 47-63 Hz, 45 watts maximum

Continued on next page...

2017-1727-140 Manual, Rev. 0 Page 4 02/14/18

--------DOWNCONVERTER--------

Input Characteristics (L)

Impedance/Return Loss 50 Ω/14 dB

Frequency 2.0 to 2.7 GHz

Noise Figure (max) 15 dB @ max gain

Input Level -70 to -20 dBm

Output Characteristics (L)

Impedance/Return Loss 50 Ω/14 dB

Frequency 140 ± 20 MHz

Output level/max linear -30 to -10 dBm

Output 1 dB compression -5 dBm

Mute @ 0 dBm Out N/A

Channel Characteristics

Gain, max. at Fc +50 ±3 dB

Gain range, 1 ±1 dB steps +50 to 0 dB

Image Rejection > 50 dB, min.

Spurious, Inband, sig. rel. <-50 dBC 0 dBm

Spurious, Inband, sig. ind. <-50 dBC Gmax.

Spurious, Out of Band <-50 dBC Gmax

Intermod - 2 Carriers <-50 dBC Gmax

Frequency Resp. Band ±2 dB

Frequency Resp. 40 MHz ±0.5 dB, ± 1.0 dB

Frequency Sense Inverting/Non-inverting

TABLE 1.0 2017-1727-140 Up/Downconverter Specifications... Continued from page 4

Available Options:

E External 10 MHz Reference input & output

H High Stability (±0.01ppm) Internal Reference

W78 RF/RF Monitor Ports (Front)

W31 External Temp 0C to +50C

X or X1 125 kHz or 100 kHz step size

Remote & M&C Interfaces:

Q RS485 Remote Interface

W8 Ethernet with Web Browser

W18 Ethernet with Web Browser & SNMP

W28 Ethernet with TCP/IP, Telnet®

Connectors/Impeedance Interfaces:

-D 50Ω, BNC (RF), 50ΩBNC (IF)

-N 50Ω, N-Type (RF), 75ΩBNC (IF)

-M 50Ω, N-Type (RF), 50ΩBNC (IF)

-S 50Ω, SMA (RF), 50ΩBNC (IF)

-SS 50Ω, SMA (RF), 50ΩSMA (IF)

Contact Cross for other available options

*+10˚C to +40˚C; Specifications subject to change without notice

2017-1727-140 Manual, Rev. 0 Page 5 02/14/18

1.3 Monitor and Control Interface

A) Remote serial interface

Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit.

(RS-232C, RS-422, or RS-485 - option -Q)

Connector: Rear panel, DB-9 male

J10 Pinouts

(RS-232C/422/485)

Pinouts (RS-232C/422/485)

Pin Function

1 Rx-

2 Rx+ (RS-232C)

3 Tx+ (RS-232C)

4Tx-

5GND

6 Alarm Relay: Common

7 Alarm Relay: Normally Open

8 Not Used

9 Alarm Relay: Normally Closed

B) Status Requests

Table 1.1 lists the status requests for the 2017-1727-140 and briefly describes them.

Table 1.1 2017-1727-140 Sttatus

2017-1727-140 Status Reqquests

Table 1.1 2017-1727-140 Status Requests

Command Syntax* Description

Command Status {aaS1} Returns {aaS1bbbbccccdddeeffLMNOP} where:

• bbbb = Tx frequency (bbbbbbb - 7 characters,opt X, X1)

• cccc = Rx frequency (ccccccc - 7 characters,opt X, X1)

• ddd = Tx gain (-10 to 30)

• ee = Rx gain (00 to 50)

• ff = Tx input level (10 to 40 => -10 to -40 dBm)

• L = 0 - non-inverted Receiver; L = 1 - inverted

• M = 0 - Receiver synth alarm

• N = 0 - Transmitter synth alarm

• O = 0 - Summary alarm

• P = 0 - Transmit signal disabled (muted)

External 10MHz (option -E) {aaS2} Returns {aaS2b} where:

• b = 1 - External 10MHz selected

* PLEASE NOTE: The Address (aa) should only be used when RS-485 is selected (option -Q ONLY)

2017-1727-140 Manual, Rev. 0 Page 6 02/14/18

C) Commands

Table 1.2 lists the commands for the 2017-1727-140 and briefly describes them. After a command is sent the

2017-1727-140 sends a return “>” indicating the command has been received and executed.

General Command Format - The general command format is {aaCND...}, where:

{ = start byte

aa = address (RS-485 only option -Q)

C = 1 character, either C (command) or S (status)

N = 1-digit command or status number, 1 through 9

D = 1 character or more of data (depends on command)

} = stop byte

Table 1.2 2017-1727-140 Commmands

Commands

Table 1.2 2017-1727-140 Commands

Command Syntax* Description

Set Transmitter Frequency {aaC1xxxx} where:

• xxxx = 4 characters (7 characters, option X, X1)

• Range: 9500 to 1750 MHz,

(9500000 to 1750000, option X, X1)

Set Transmitter Input Level {aaCIxx} where:

• xx = 2 characters

• Range: 10 to 40 (-10 to -40 dBm)

Set Receiver Frequency {aaC2xxxx} where:

• xxxx = 4 characters (7 characters, option X, X1)

• Range: 2000 to 2700 MHz

(2000000 to 2700000, option X, X1)

Set Transmit Gain {aaC3xxxx} where:

• xxxx = 2 or 3 characters

• Range: +30 to-10 (+30 to-10 dB, in 1 dB steps)

Set Receiver Gain {aaC4xxx} where:

• xx = 2 characters

• Range: 50 to 00 (50 dB to 0 dB, in 1 dB steps)

Enable Tx {aaCAx} where x =:

• 0 to disable Tx signal

• 1 to enable Tx signal

External 10MHz (option -E) {aaCEx} where x =:

• 0 to disable External 10MHz ref signal

• 1 to enable External 10MHz ref signal

Downconverter Spectrum {aaC7x} where x =:

• 0 for non-inverted

• 1 for inverted

Enable Remote # Just # sign

Disable Remote {aaCR0}* {CR and zero}

* PLEASE NOTE: The Address (aa) should only be used when RS-485 is selected (option -Q ONLY)

2017-1727-140 Manual, Rev. 0 Page 7 02/14/18

2.0 Installation

2.1 Mechanical

The 2017-1727-140 consists of one RF/Controller PCB housed in a 1 RU (1 3/4 inch high) by 16 inch deep

chassis. A switching, ± 12, +5, +24 VDC power supply provides power for the assemblies. The 2017-1727-140

can be secured to a rack using the 4 holes on the front panel. Figure 2.0 shows how the 2017-1727-140 is

assembled.

POWER

SUPPLY

Figure 2.0 Model 2017-1727-140 Mechanical Assembly

2017-1727-140 Manual, Rev. 0 Page 8 02/14/18

2.2 Rear Panel Input/Output Signals and Control - Figure 2.1 shows the input and output connectors

on the rear panel.

J10 - MONITOR AND CONTROL

DB9 female connector.

See Table 2.1.

RF OUT

J4 J5J3

10 MHZ IF IN

EXT REF

J3 - 10 MHz EXT REF INPUT (Option E)

10 MHz, +3 ± 3 dBm external reference input,

75ΩBNC female connector.

J5 - RF OUT

0.95 - 1.75 GHz

-20 to 0 dBm out, see Table 2.2.

J4 - IF IN

140 ±10 MHz input, -40 to -10 dBm in,

see Table 2.2.

J20 - ETHERNET

CONNECTION

RJ45 Ethernet Connector

UPCONVERTER

INPUT

GND

J18J2

RF IN 10 MHZ REF

OUTPUT

AC1 - POWER IN

AC input for switching

power supply. 100-240

±10% VAC, 47-63 Hz.

J2 - RF IN

2.0 to 2.7 GHz input,

-70 to -20 dBm,

See Table 2.2.

J1 - IF OUT

140 ±10 MHz

-30 to -10 dBm,

See Table 2.2.

J10

AND

MONITOR

CONTROL

DOWNCONVERTER

IF OUT

J18 - 10 MHz REF OUTPUT (option E)

10 MHz, +3 ± 3 dBm reference output.

75ΩBNC female connector.

J20

Figure 2.1 Model 2017-1727-140 Rear Panel I/O’s

TABLE 2.1 J110

2.1 J10 Pinouts (RS-232C/422/485*)

Pin Function

1 Rx-

2 Rx+ (RS-232C)

3 Tx+ (RS-232C)

4Tx-

5GND

6 Alarm Relay: Common

7 Alarm Relay: Normally Open

8 Not Used

9 Alarm Relay: Normally Closed

*Remote Serial Interface

Interface: DB-9 Male

Protocol: RS-232C (RS-232C/422/485 option -Q), 9600 baud rate, no parity,

8 data bits, 1 start bit, 1 stop bit.

TABLE 2.2 IFF/RF

2.2 IF/RF Connector Options

Options

Option IF RF

STD BNC, 75ΩType F, 75Ω

-D BNC, 50ΩBNC, 50Ω

-N BNC, 75ΩType N, 50Ω

-M BNC, 50ΩType N, 50Ω

-S BNC, 50ΩSMA, 50Ω

-SS SMA, 50ΩSMA, 50Ω

2017-1727-140 Manual, Rev. 0 Page 9 02/14/18

2.3 Front Panel Controls and Indicators - The following are the front panel controls and indicators.

S3 - HORIZ. TOGGLE

Horizontal toggle switch that

controls which values are being

adjusted. Does not function in the

normal display mode

EXECUTE

U F=1725 G=+10.0

MUTE

REMOTEALARM POWER

LCD DISPLAY

Display shows Up and

Downconverter frequency in MHz

and Gain in dB

S1 - MENU/EXECUTE BUTTON

Press this to get into Program mode

and to execute any changes.

DS3 - DOWN ALARM LED

Red LED indicates

downconverter alarm.

DS6 - POWER LED

Green LED indicates

presence of DC power.

DS1 - REMOTE LED

Yellow LED indicates

remote operation.

S2 - VERT. TOGGLE

Vertical toggle switch that controls

values in the Menu items when in

program mode. Does not function

in the normal display mode

UPCONVERTER

ALARM

DOWNCONVERTER

D F=2675 G=+25.0

DS5 - UP MUTE LED

Yellow LED indicates

upconverter mute.

DS2 - UP ALARM LED

Red LED indicates

upconverter alarm.

Figure 2.2 Model 2017-1727-140 Front Panel Controls and Indicators

2017-1727-140 Manual, Rev. 0 Page 10 02/14/18

Tabla de contenidos

Otros manuales de Convertidor de medios de Cross Technologies

Cross Technologies

Cross Technologies 2016-8085 Manual de usuario

Cross Technologies

Cross Technologies 3116-7786-2150 Manual de usuario

Cross Technologies

Cross Technologies 3117-3338 720 Series Manual de usuario

Cross Technologies

Cross Technologies 2009-2425-1750 Manual de usuario

Cross Technologies

Cross Technologies 3016-2124 Manual de usuario

Cross Technologies

Cross Technologies 2015-05 Manual de usuario

Cross Technologies

Cross Technologies 2016-02-1200 Manual de usuario

Cross Technologies

Cross Technologies 2016-12 Manual de usuario

Cross Technologies

Cross Technologies 2117 Manual de usuario

Cross Technologies

Cross Technologies 2415-02 Series Manual de usuario

Cross Technologies

Cross Technologies 2415-x02 Manual de usuario

Cross Technologies

Cross Technologies 2016-03A Manual de usuario

Cross Technologies

Cross Technologies 3115-21-109 Manual de usuario

Cross Technologies

Cross Technologies 2016-75-213 Manual de usuario

Cross Technologies

Cross Technologies 4115-300 Manual de usuario

Cross Technologies

Cross Technologies 2416 25 Series Manual de usuario

Cross Technologies

Cross Technologies 2115-275-1845 Manual de usuario

Cross Technologies

Cross Technologies 2116-140T120 Manual de usuario

Cross Technologies

Cross Technologies 2415 0925 Series Manual de usuario

Cross Technologies

Cross Technologies 4115-41-212 Manual de usuario

Cross Technologies

Cross Technologies 2117-7172 Manual de usuario

Cross Technologies

Cross Technologies 2116-300-1600 Manual de usuario

Cross Technologies

Cross Technologies 1584-29 Manual de usuario

Cross Technologies

Cross Technologies 2016-25 Manual de usuario

Manuales populares de Convertidor de medios de otras marcas

SoundTraxx

SoundTraxx Blunami BLU-2200 Manual de usuario

SPROLINK

SPROLINK VA1 Manual de usuario

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manual de usuario

Nikon

Nikon AF-S TC-20E III Manual de usuario

Axis

Axis AXIS Q7406 Manual de usuario

Omega

Omega TAC80B-J Manual de usuario

Zoom

Zoom Thunderbolt TAC-2R Manual de usuario

OST

OST iConverter 10/100M Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

birddog

birddog MINI Manual de usuario

Roland

Roland GI-10 Manual de usuario

Wallenstein

Wallenstein WX310 Manual de usuario

Pace

Pace MSS 200-1 Manual de usuario

Solar Converters

Solar Converters EQ 12/24-50 Manual de usuario

CYP

CYP EL-7400V Manual de usuario

TIE

TIE MIDI 1i1o Manual de usuario

DCS

DCS Vivaldi Upsampler Manual de usuario

Westermo

Westermo MCW-211 SERIES Manual de usuario
