CrimeStopper RS-800.IV Manual de usuario

RS800 Series IV

Remote Engine Starting System

OPERATING INSTRUCTIONS

OPERATION CAUTIONS & WARNINGS

CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from

the use of this equipment. This system is designed to be professionally installed onto a vehicle in which all items, such

as parking brake and all associated components, door switches, transmission shift linkage, throttle linkage, and all

engine safety features, are in perfect working condition. This is a basic remote start system only; there are no keyless

entry functions built into the RS-800 IV. We recommend keeping your vehicle locked for safety when remote starting.

DO NOT install this Remote Engine Starting System on MANUAL TRANSMISSION vehicles. If accidentally left in

gear the vehicle could become a self-propelled threat to life and property.

IT IS ABSOLUTELY THE OWNER’S SOLE RESPONSIBILITY TO: A) Understand the operation of this system and its

safety features. B) Check for proper operation of these safety features prior to accepting delivery of the vehicle from the

installation facility. C) Check and maintain the condition of the vehicle and all items relative to the proper operation of

this system and its safety features. D) Always leave the doors and windows closed and locked to protect against

accident and theft.

DO NOT remote start the vehicle in a closed garage. Make sure that the garage door is open or there is adequate

ventilation. Failure to observe this rule could result in injury or death from poisonous Carbon Monoxide fumes.

This device complies with FCC Rules part 15. Operation is subject to the following two conditions: 1)

This device may not cause interference, and (2) this device must accept any interference that may be

received, including interference that may cause undesired operation. The manufacturer is not

responsible for any radio or TV interference caused by unauthorized modification to this equipment.

Such modification could void the user's authority to operate the equipment.

REV. A 08/2003

OPERATIONOPERATION

REMOTE ENGINE STARTING - SUCCESSFUL START:

1. Press start button for at least one second, then release.

2. Parking lights flash once, then turn ON along with the IGN/ACC circuits

3. After a few seconds the Starter Motor engages. (Parking lights and Acc

circuits turn off while cranking.)

4. Engine Starts and Runs. Parking Lights and Acc turn back on.

5. Engine will remain running for programmed run time or until reset with

Brake pedal.

REMOTE ENGINE STARTING - UNSUCCESSFUL START

In the event that the engine does not start on the first attempt, the system

shuts down for a few seconds, and then attempts to restart the engine a 2nd

and 3rd time. For hard starting engines, the unit will allow a starter crank time

of up to a maximum of 13 seconds. This should provide ample cranking time

for difficult starts, but is limited to help prevent damage to the starter from over cranking in the case of a problem with the

system.

1. If engine starts on 2nd or 3rd attempt, see steps 4 & 5 above of "Successful Start".

2. If Third attempt fails to start engine the system will abort. NO FURTHER ATTEMPTS WILL BE MADE

AUTOMATICALLY

TURNING OFF A REMOTE STARTED ENGINE:

1. Engine is running in Remote Start (Parking lights are ON).

2. Press start button for at least one second and release.

3. Engine and parking lights turn off.

VALET MODE

Before servicing your vehicle or handing the keys over to a Valet we recommend putting the unit into valet mode. The

remote start function WILL NOT operate when in Valet mode. To enter Valet mode, turn the key to the ON position,

press and hold Program/Valet switch for 6 seconds. The LED will turn on solid and the system is now in valet. Perform

this procedure again to exit of Valet mode.

HOOD OPEN SAFETY SWITCH (WITH INSTALLED HOOD PIN SWITCH)

A safety hood pin switch (when installed along with the remote start system) helps eliminate the risk of injury to someone

working under the hood. If will prevents the engine from being remote started while the hood is open. It will also abort a

remote started engine.

OPERATION

ANTI-GRIND / STARTER DISABLE (OPTIONAL)

Prevents the driver from accidentally grinding the starter if the Ignition key is turned too far (to the start position) while

engine is already running from the remote starter.

BRAKE PEDAL RESET CIRCUITRY

Prevents starting or shuts off a remote started vehicle when this circuit is active or activated. Prevents unauthorized

tampering. This circuit shuts the system down immediately when brake pedal is pressed if key is not in ignition and

turned to the run position.

LED (OPTIONAL)

The optional LED (if installed) is used as a indicator for Valet mode and also lights solid during programming options.

NOTE:

In the event of a malfunction, jumpstarting or performing electrical service you should remove the main Power Fuses.

TRANSMITTER PROGRAMMING

Note: All transmitter codes must be learned at time of programming!! The RS800 allows storage of up to 4

different transmitter codes.

1. Open Hood (Ground Gray hood pin wire if no hood pin is installed).

2. Turn key to the ON position.

3. Press Programming button 4 times. After a few seconds, the unit will flash the parking lights 4 times.

4. Press the Start Button of the transmitter to be coded. You should get 2 light flashes indicating the unit is waiting for a

2nd code, then press start button of a second transmitter, the unit will flash 3 times indicating its waiting for the 3rd

code and 4 flashes for the 4th code. If all 4 codes are learned, the unit will automatically exit code-learning mode,

otherwise turn key off and close hood.

2-VEHICLE OPERATION

The RS-800 IV system can be used for 2-car operation. A single RS800 IV remote control can operate two independent

vehicles with RS800 IV systems installed.

SETUP:

1. Using the switch on the side of the remote set your controller to Car II.

2. At Car II: Simply follow the transmitter programming steps listed above. Learn YOUR remote, along with Car 2’s

existing remotes.

ONLINE TECHNICAL SUPPORT

www.crimestopper.com/techweb03.html

www.crimestopper.com

[email protected]

Phone (800) 998-6880

FAX (805) 581-9500
