Crestron TPMC-9

9” Tilt Touch Screen

Operations Guide

The specific patents that cover Crestron products are listed at patents.crestron.com.

Crestron, the Crestron logo, CresCAT, Cresnet, Crestron Home, Crestron Studio, Crestron Toolbox, Smart Graphics, SmartObjects, TouchPoint and

VT Pro-e are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Microsoft and

Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Other trademarks,

registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.

This document was written by the Technical Publications department at Crestron.

Regulatory Compliance

As of the date of manufacture, the TPMC-9 has been tested and found to comply with specifications for CE

marking and standards per EMC and Radiocommunications Compliance Labelling.

Federal Communications Commission (FCC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:

(1) This device may not cause harmful interference and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and receiver

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

•Consult the dealer or an experienced radio/TV technician for help

Industry Canada (IC) Compliance Statement

CAN ICES-3(B)/NMB-3(B)

Crestron TPMC-9 9” Tilt Touch Screen

Operations Guide – DOC. 6965E Contents •i

Contents

9” Tilt Touch Screen: TPMC-9 1

Introduction ............................................................................................................................... 1

Features and Functions ................................................................................................ 1

Applications.................................................................................................................4

Specifications ..............................................................................................................5

Physical Description....................................................................................................7

Setup ........................................................................................................................................ 10

Network Wiring......................................................................................................... 10

Identity Code ............................................................................................................. 10

Configuring the Touch Screen................................................................................... 11

Hardware Hookup ..................................................................................................... 22

Tilt Adjustment.......................................................................................................... 23

Recommended Cleaning............................................................................................ 24

Uploading and Upgrading........................................................................................................ 25

Establishing Communication..................................................................................... 25

Programs, Projects and Firmware.............................................................................. 27

Program Checks ........................................................................................................ 27

Problem Solving ...................................................................................................................... 28

Troubleshooting......................................................................................................... 28

Check Network Wiring.............................................................................................. 29

Reference Documents................................................................................................ 30

Further Inquiries ........................................................................................................ 30

Future Updates .......................................................................................................... 30

Return and Warranty Policies .................................................................................................. 31

Merchandise Returns / Repair Service ...................................................................... 31

Crestron Limited Warranty........................................................................................ 31

Crestron TPMC-9 9” Tilt Touch Screen

Operations Guide – DOC. 6965E 9” Tilt Touch Screen: TPMC-9 •1

•Sleek, contoured design for tabletop use

•Elegant smooth black or white or textured black finishes

•Generous 9” (~229 mm) widescreen color touch screen

•800 x 480 WVGA display resolution

•Smart Graphics™ support

•High performance H.264 streaming video

•Wired composite video input

•Crestron IP intercom

•Customizable audio feedback

•Built-in microphone and speakers

•Crestron Home®CAT5 video connectivity

•High speed Ethernet and Cresnet®communications

•Built-in USB port for direct program upload

•Up to 45 degree tilt adjustment*

•Low profile single wire connection

9” Tilt Touch Screen: TPMC-9

Introduction

The TPMC-9 Tilt Touch Screen from Crestron®delivers high end style and

performance in a striking tabletop design. Sleek and compact, the TPMC-9 features a

generous 9” (~229 mm) widescreen display with advanced touch screen graphics, IP

intercom, audio feedback and high performance H.264 video.

Features and Functions

* The tilt angle must be set to a fixed position for normal use. Adjustment of the tilt angle requires a

5/32” hex wrench (included).

9” Tilt Touch Screen Crestron TPMC-9

2•9” Tilt Touch Screen: TPMC-9 Operations Guide – DOC. 6965E

Advanced Touch Screen Control

A Crestron touch screen offers an ideal user interface for controlling all the

technology in a home, boardroom, classroom, courtroom or command center. Touch

screens do away with piles of remote controls, cluttered wall switches and cryptic

computer screens, simplifying and enhancing the technology. For controlling audio,

video, lighting, shades, HVAC, security and other systems, Crestron touch screens

are fully customizable with easy to use controls and icons, true feedback and real

time status display, full-motion video windows and advanced navigation of digital

media servers, tuners and other devices.

Smart Graphics

Crestron touch screens use Smart Graphics to deliver the ultimate user experience

and the ultimate value, by enabling the creation of dynamically rich user interfaces

with incredible efficiency and unparalleled functionality. Using Smart Graphics,

programmers can swiftly integrate fluid gesture-driven controls, animated feedback,

metadata, embedded apps and full-motion video for a deeply engaging and

ultra-intuitive touch screen experience.

Crestron Smart Graphics include the following enhancements:

•Cool looking graphical buttons, sliders, knobs and gauges are intuitive and

fun to use.

•Kinetic effects enhance the feeling of realism with lists and toolbars that

scroll with momentum at the flick of a fingertip.

•Drag and drop objects snap into place offering an easy way to switch

sources.

•Dashboard widgets personalize the touch screen with clocks, weather, news

and other information.

•Customizable themes allow a completely different look and feel for every

user, event or season.

•Fully developed SmartObjects™ enable sophisticated control over complex

devices with minimal programming.

Integrated Video

High performance streaming video capability makes it possible to view security

cameras and other video sources over the network right on the touch screen. Native

support for H.264 and MJPEG formats allows the TPMC-9 to display live video

images from IP cameras and servers such as the Crestron CEN-NVS200 Network

Video Streamer (sold separately). A wired video input is also provided to allow

viewing of a composite video source. Video images can be displayed full frame or in

fully scalable windows anywhere on the touch screen.

IP Intercom

Equipped with integrated speakers and microphone, the TPMC-9 allows touch screen

to touch screen voice communication and room monitoring via IP over Ethernet,

eliminating the need for any special audio wiring, switchers or programming.

Audio Feedback

Customized audio files can be loaded on the TPMC-9 to add another dimension to

the touch screen graphics using personalized sounds, button feedback and voice

prompts.

Crestron TPMC-9 9” Tilt Touch Screen

Operations Guide – DOC. 6965E 9” Tilt Touch Screen: TPMC-9 •3

High Speed Connectivity

Both Cresnet and Ethernet are standard on the TPMC-9, providing for easy network

integration and seamless communications with Crestron control systems and other

network devices.

Versatile Install Options

With its integral tilting base, the TPMC-9 provides a very clean and stylish touch

screen solution for small countertops, desks, podiums and bedside tables. The screen

tilt is installer adjustable at up to a 45 degree angle for optimal viewing and

operation.1

A single cable exits the rear of the base. The 10 foot (3 meter) cable extends to a

separate interface module (TPS-6X-IMCW2), which may be discreetly mounted on a

flat surface or in a flush wall box, providing full connectivity for power,

communications and video signals. Control system communication is afforded

through Cresnet and Ethernet ports. Wired video connectivity is handled through a

choice of balanced or unbalanced composite inputs, allowing compatibility with both

conventional coaxial and Crestron Home Balanced AV distribution systems.

1. The tilt angle must be set to a fixed position for normal use. Adjustment of the tilt angle requires a

5/32” hex wrench (included).

2. Item included, refer to product specifications for additional information.

9” Tilt Touch Screen Crestron TPMC-9

4•9” Tilt Touch Screen: TPMC-9 Operations Guide – DOC. 6965E

Applications

The following diagram shows a TPMC-9 in a typical application.

TPMC-9 in a Typical Application

Crestron TPMC-9 9” Tilt Touch Screen

Operations Guide – DOC. 6965E 9” Tilt Touch Screen: TPMC-9 •5

Specifications

Specifications for the TPMC-9 are listed in the following table.

TPMC-9 Specifications

SPECIFICATION DETAILS

Touch Screen Display

Display Type TFT active matrix color LCD

Size 9 inch (229 mm) diagonal

Aspect Ratio 15:9 WVGA

Resolution 800 x 480 pixels

Brightness 350 nits

Contrast 700:1

Color Depth 24-bit, 16.7 M colors

Illumination Edgelit fluorescent

Viewing Angle ± 88º horizontal, ± 88º vertical

Touch Screen Resistive membrane

Memory

DDR SDRAM 256 MB

Flash 2 GB

Maximum Project Size 60 MB

Graphics Engine Supports Smart Graphics or “traditional” GUI

projects

Communications

Ethernet 10/100, auto-switching, auto-negotiating,

auto-discovery, full/half duplex, DHCP, for

control and console

Cresnet Cresnet slave mode for control and console

USB USB client for console

Video

Analog Input Signal Types Composite

Analog Formats NTSC 480i or PAL 576i

Analog Color Depth 24-bit, 16.7 M colors

Streaming Formats H.264 (MPEG-4 part 10 AVC, MJPEG

Audio

Features Built-in microphone and speakers, Crestron

IP Intercom

Audio Feedback Formats MP3 using Smart Graphics,

WAV using “traditional” graphics

Power Requirements

Power Pack 0.75 amps @ 24 Vdc;

100 – 240 Vac, 50/60 Hz

power pack included

Cresnet Power Usage 18 watts (0.75 amps @ 24 Vdc) including

TPS-6X-IMCW interface module1, 2

Default IP ID

(Continued on following page)

9” Tilt Touch Screen Crestron TPMC-9

6•9” Tilt Touch Screen: TPMC-9 Operations Guide – DOC. 6965E

TPMC-9 Specifications (Continued)

SPECIFICATION DETAILS

Environmental

Temperature 32º to 95º F (0º to 35º C)

Humidity 10% to 90% RH (non-condensing)

Heat Dissipation 61 Btu/h

Enclosure Plastic, 0° to 45° adjustable tilt mechanism

low profile base, integral 10 foot (3 meter)

cable assembly

Dimensions

Height 7.09 in (180 mm) maximum

6.91 in (176 mm) minimum

Width 10.72 in (273 mm)

Depth 7.02 in (179 mm),

6.48 in (165 mm) without grommet

Weight 4.1 lb (1.9 kg)

Available Models

TPMC-9-B 9” Tilt Touch Screen, Black Smooth

TPMC-9-B-T 9” Tilt Touch Screen, Black Textured

TPMC-9-W-S 9” Tilt Touch Screen, White Smooth

Included Accessories

Power Pack 24 Volt Power Pack, Universal

TPS-6X-IMCW Interface Module

Available Accessories

CEN-NVS200 Network Video Streamer

CRESCAT

Crestron Home CAT5 AV Cable

CRESNET Cresnet Control Cable

VMK-WIN Touchpoint

Virtual Mouse & Keyboard

Software for Windows®

1. Item included; refer to product specifications for additional information.

2. May be powered by power pack or Cresnet network power but not both. All power connections are

made via the included TPS-6X-IMCW interface module.

3. Refer to “Identity Code” which starts on page 10 for details.

4. The tilt angle must be set to a fixed position for normal use. Adjustment of the tilt angle requires a

5/32” hex wrench (included).

Tabla de contenidos

Otros manuales de Panel táctil de Crestron

Crestron

Crestron Isys TPS-4000L Manual de usuario

Crestron

Crestron ST-1550 Manual de usuario

Crestron

Crestron Lsys TPS 2000L Manual de usuario

Crestron

Crestron Isys TPS-4500 Manual de usuario

Crestron

Crestron Isys TPS-3100L Manual de usuario

Crestron

Crestron TS-770-GV Manual de usuario

Crestron

Crestron TPS-4500IMW Manual de usuario

Crestron

Crestron Isys TPS-12 Manual de usuario

Crestron

Crestron TSW-70 Series Manual de usuario

Crestron

Crestron IM-WCCV Cómo utilizar

Crestron

Crestron TSCW-730 Dibujo dimensional

Crestron

Crestron Smart Touch C2N-IRGW Manual de usuario

Crestron

Crestron TPS-FPAR3100L Manual de usuario

Crestron

Crestron CT-3000 Manual de usuario

Crestron

Crestron TPMC-V12 & TPMC-V15 Manual de usuario

Crestron

Crestron TSS-770 Manual de usuario

Crestron

Crestron TPMC-4XG Manual de usuario

Crestron

Crestron DualTouch DTT-17 Manual de usuario

Crestron

Crestron Isys TPS-4500LV Manual de usuario

Crestron

Crestron Isys TPS Series Manual de usuario

Crestron

Crestron Isys TPS-4L Cómo utilizar

Crestron

Crestron Isys TPS-12B Manual de usuario

Crestron

Crestron Isys TPMC-4SM Instrucciones de funcionamiento originales

Crestron

Crestron QM-FTCC Cómo utilizar

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
