CrestronIsys™TPS-2000L

CompactVideoTouchpanel

TheIsys™TPS-2000LCompactVideoTouchpanelsets

newstandardsintouchpaneltechnology.Itincorpo-

ratesfeaturesfoundonlyinour top-of-the-lineIsys

panelsyetit’ssocost-effective,youcanputonein

everyroom.Acoloractive-matrixvideotouchpanel

combinedwithteneasy-to-usepushbuttonsmakes

anincrediblyversatilechoiceforcontrollingthe

entirehome.

The5”diagonaldisplaypresentsbeautifulcolor

controlgraphicsandfull-motionvideowithaclarity

previouslynotfoundinthissize.Alightsensor

automaticallybrightensordimsthedisplaywith

roomlightsoit'seasytoseeanytimeofdayor

night.Withanexceptionalviewingangle,you’llenjoy

anoutstandingpicture. Bestofall,itsexclusive

VirtualDigitalPanandZoomfeatureisasusefulasit

isfuntouse.ThankstoCrestron’sadvanceddigital

videoprocessorcircuitry,justtouchthescreenwith

yourfingertopanacrossthevideopictureandzoom

inforthebestview.Youcanwatchvideoina

windowatthesametimeyouareusingyour

controlpanel.

TheTPS-2000Laudiocapabilitiesarejustas

impressive.WAVsoundfilestorageandplayback

provideaudiofeedback,fromsoundeffectstothe

soundofyourownvoice.Amicrophone,amplifier

andspeakersletyoutalkwitharrivingguests,as

youviewthemonthescreen.Adjustmentsarealso

availableforvolumeandtone.

TheTPS-2000Lcanbethecentralcontrolpointin

anypartofthehouseoruseitinlargersystemsto

complementotherIsyspanels.

Itscompactsizeletsyoumountitonthewallfor

wholehousecontrolorinasofaorchairarm,forthe

idealcommandcenterinyourhometheater.Inlays

forpaint,wallpaper,anddesignermetalfinishesare

available.

>Isystechnologyinaversatile,compactsize

>5”diagonaltouch-sensitiveLCDscreen

>Ten(10)easy-to-usepushbuttons

>Highqualitycontrolgraphicsandfull-motion

video

>Alightsensorautomaticallybrightensordimsthe

displaywithroomlight

>Digitalvideoprocessorcircuitryprovidesexclusive

VirtualPanandZoomfeature

>Storageandplaybackof.wavfiles provides

audiofeedback

>Builtinmicanddualpoweredspeakers

withvolumeandtonecontrol

>Choosefromavarietyofstandardcolorsand

designerfinishes

>Graphicsdisplayrotates180°foroptimum

viewingangleforwallorflushmounting

All brand names, product names and trademarks are the property of their respective owners.

NEW YORK

LOS ANGELES

ATLANTA

DALLAS

CHICAGO

TORONTO

MEXICO CITY

BRUSSELS

MUNICH

LONDON

PARIS

HONG KONG

BEIJING

SINGAPORE

TAIWAN

MELBOURNE

Crestron Electronics, Inc. 15 Volvo Drive • Rockleigh, NJ 07647

Tel: 800.237.2041 / 201.767.3400 • Fax: 201.767.7576 • www.crestron.com

Cover photo montage: Installations by AVWashington, Inc.(www.avwashington.com) and Midwest

Visual Communications (www.midwestvisual.com)

Specifications subject to change without notice. Printed in USA Doc.6027 2/02

NEW YORK

LOS ANGELES

ATLANTA

DALLAS

CHICAGO

TORONTO

MEXICO CITY

BRUSSELS

MUNICH

LONDON

PARIS

HONG KONG

BEIJING

SINGAPORE

TAIWAN

MELBOURNE

Crestron Electronics, Inc. 15 Volvo Drive • Rockleigh, NJ 07647

Tel: 800.237.2041 / 201.767.3400 • Fax: 201.767.7576 • www.crestron.com

Cover photo montage: Installations by AVWashington, Inc.(www.avwashington.com) and Midwest

Visual Communications (www.midwestvisual.com)

5”Wall Model

Touchscreen

DisplayType:Touch-sensitiveactivematrixcolor LCD

Screen Dimensions: 5"/12.7cm diagonal

Screen Resolution: 320x234pixels

Color:16Bitnon-palettegraphics

Enclosure: Injection-molded plasticenclosurefaceplate

andkeysinwhite;Auto-LightSensor,Built-in10“Quick”

pushbuttons

GraphicsDisplay:Rotates180°viasoftwareforoptimum

viewingangleinflushmount

Connectors

•4-positionmini-phoenixforCresnet

•8-positionmini-phoenixforaudio and video.

Audio

•Balanced&unbalancedline levelmonoinput,balanced

linelevelmicrophoneoutput,and built-inWAV file

capability(8KHz)

•Halfduplexintercomcapable

•Dualamplifiedspeakers(2Wper spkr)w/volume&

tonecontrol

Video

•Balanced(CAT5)/unbalancedcompositevideo

inputsupporting NTSC/PALformatsandbuilt-intime

basecorrection.Video can bedisplayedeither full

screenorina window.

•2xdigitalzoomw/pan featurebuilt-in

Memory

2MBinternalflashmemory,8MBofDRAM

CPU

63MIPsColdfireprocessorrunning Isys generation

firmware

Power Requirements

13W,24VDC,0.54A

Additional Options

BB-2000:Back boxforwallmounting

PMK-2000L:Pre-ConstructionMount

MMK-2000L:Mud mount kit forusew/BB-2000

orPMK-2000L

TMK-2000L:Trimmount kit for usew/BB-2000

orPMK2000L

WMKM-2000L:Wallmountkit-with Mud Ring

WMKT-2000L:Wallmountkit-withTrimRing

TPS-FP:Designer Series faceplates

TPS-WPK:WaterResistant CoverKit

Dimensions

4.77”(12.10cm)Hx6.73”(17.10 cm)Wx3.43”(8.71cm) D

Weight

1.41.lb (0.64kg)

4.765 in

(12.103 cm)

6.731 in

(17.097 cm)

3.066 in

(7.788 cm) 3.43 in

(8.714 cm)

RearView

FrontView BottomView

CrestronIsys™TPS-2000L CompactVideoTouchpanel
