Crestron WPR-DS Manual de usuario

Crestron WPR-DS

Docking Station for WPR-48

Operations Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names, and trademarks are the property of their respective owners.

Crestron WPR-DS Docking Station for WPR-48

Contents

Docking Station for WPR-48: WPR-DS 1

Introduction ...............................................................................................................................1

Functions and Features................................................................................................1

Specifications ..............................................................................................................2

Physical Description....................................................................................................2

Industry Compliance ................................................................................................... 4

Setup ..........................................................................................................................................4

Power Source...............................................................................................................4

Docking Station to PC Serial Communication ............................................................5

Problem Solving ........................................................................................................................ 5

Troubleshooting ..........................................................................................................5

Further Inquiries..........................................................................................................6

Future Updates ............................................................................................................6

Return and Warranty Policies....................................................................................................7

Merchandise Returns / Repair Service ........................................................................7

CRESTRON Limited Warranty .................................................................................. 7

Operations Guide – DOC. 6255A Contents •i

Crestron WPR-DS Docking Station for WPR-48

Operations Guide – DOC. 6255A Docking Station for WPR-48: WPR-DS •1

Docking Station for WPR-48:

WPR-DS

Introduction

Functions and Features

The Crestron®WPR-DS docking station is a companion product for the Crestron

WPR-48 waterproof wireless handheld remote. The WPR-DS is also available in an

international version, the WPRI-DS. All features are identical with the exception of

the supplied power pack (PWI-1210) for the international version. Refer to “Power

Source” on page 4 for more information.

NOTE: For simplicity, information in this guide applies to both the WPR-DS and

the WPRI-DS, except where noted.

The WPR-DS functions primarily as a charging station for the WPR-48’s built-in

lithium-ion battery. Recharge of the WPR-48 battery takes up to 1.5 hours. As long

as the contacts of the WPR-48 and the WPR-DS remain together, the WPR-DS

“trickle charges” the WPR-48 in an attempt to maintain the handheld remote at full

charge for optimum performance. The duration of a “trickle charge” is continuous as

long as the WPR-48 is not fully charged.

The WPR-DS also functions as an interface to a PC via the RS-232 port, for

uploading of new firmware and configuring the WPR-48.

Functional Summary

• Fast charge of lithium-ion battery

• Connects to PC via RS-232

• Enables upload of new firmware and configuring

PR-48

Docking Station for WPR-48 Crestron WPR-DS

Specifications

The following table provides specifications for the WPR-DS.

Specifications for the WPR-DS

SPECIFICATION DETAILS

Power Requirements 0.5A @ 12 VDC external power pack (PW-1205 supplied

with WPR-DS)

0.5A @ 12 VDC external power pack (PWI-1210 supplied

with WPRI-DS)

Dimensions and weight

Height

Width

Depth

Weight

1.27 in (3.23 cm)

3.29 in (8.36 cm)

5.08 in (12.90 cm)

8.3 oz (232.4 gm)

Physical Description

The WPR-DS, shown below and on the next page, is constructed of blue high-

impact -plastic with labeling on the front and rear surfaces. Three LEDs on the front

panel indicate the unit’s status. The cavity accommodates the WPR-48 wireless

handheld remote. Power and RS-232 communication are connected at the rear of the

unit. Four rubber feet on the base of the WPR-DS provide stability and prevent

slippage while on a flat surface.

CAUTION: Do not place a wet remote or liquids in the docking cavity.

A label in the cavity and a statement on the product label on the bottom of the unit

notify the user not to place metal objects, a wet remote, or liquids in the docking

cavity to prevent damage to the docking station and to the wireless remote.

WPR-DS Docking Station with WPR-48 Docked

2 •Docking Station for WPR-48: WPR-DS Operations Guide – DOC. 6255A

Crestron WPR-DS Docking Station for WPR-48

Physical View

Ports

12 VDC .5A (DC Power Connector) Port

This port supplies power via the PW-1205 (110v USA and Canada) or PWI-1210

(220v International) external power pack supplied with the docking station.

RS-232

This port provides serial interface between the WPR-DS and the PC.

Operations Guide – DOC. 6255A Docking Station for WPR-48: WPR-DS •3

Docking Station for WPR-48 Crestron WPR-DS

Indicators

(Power)

Illuminates green when 12 VDC power is provided to the WPR-DS via the external

power pack.

CHG (Charge)

Illuminates (red) when a WPR-48 is inserted in the WPR-DS cavity and their

contacts meet. The LED remains ON while the rechargeable battery is charging.

Recharge of the WPR-48 battery takes up to 1.5 hours. As long as the contacts of the

WPR-48 and the WPR-DS remain together, the WPR-DS “trickle charges” the

WPR-48 in an attempt to maintain the handheld remote at full charge for optimum

performance. The duration of a “trickle charge” is continuous as long as the WPR-48

is not fully charged.

RDY (Ready)

Illuminates (red) when the WPR-48 in the charging cavity is fully charged.

Industry Compliance

As of the date of manufacture, this unit has been tested and found to comply with

specifications for CE marking and standards per EMC and Radiocommunications

Compliance Labelling (N11785)

NOTE: This device complies with part 15 of the FCC rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interference that

may cause undesired operation.

Setup

Power Source

CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to

do so could cause equipment damage or void the Crestron warranty.

The DC power socket connector on the rear of the unit is used to supply power via

the PW-1205 (110V USA and Canada) or PWI-1210 (230V International) external

power pack supplied with the docking station.

4 •Docking Station for WPR-48: WPR-DS Operations Guide – DOC. 6255A

Crestron WPR-DS Docking Station for WPR-48

Power Pack Specifications

CRESTRON POWER

PACK

INPUT SPECS OUTPUT SPECS

PW-1205 120 VAC, 60 Hz 12 VDC, 0.5 A

PWI-1210 230 VAC, 50 Hz, 110 ma 12 VDC, 1.0 A, 12 VA

Power Pack Polarity

Docking Station to PC Serial Communication

Use an RS-232 cable (RJ-11 – DB-9, such as the Crestron STCP-502 (not supplied)

to connect the WPR-DS to the serial port of the PC. This connection can also be

made with a modular RJ-11 cable and a DB9F to RJ-11 adapter. (Refer to the

following illustration.)

CONNECTOR,

6 PIN, RJ-11

(TAB FACING

AWAY)

STCP-502 PINOUT

CONNECTOR,

DB9, FEMALE

(REAR VIEW)

Pin 1

SIGNAL DB9

PINS

RJ-11

PINS

1CTS

RTS

n/c

Problem Solving

Troubleshooting

The table below provides corrective action for possible trouble situations. If further

assistance is required, please contact a Crestron customer service representative.

WPR-DS Troubleshooting

TROUBLE POSSIBLE

CAUSE(S)

CORRECTIVE ACTION

Green power LED

(Swirl Logo) does not

illuminate.

WPR-DS is not

receiving power.

Confirm that power pack is

plugged into outlet, and connector

is plugged into the WPR-DS

power input port.

Power pack not

functioning

Verify output (12 VDC minimum).

Replace power pack if necessary.

Power LED

illuminates, but battery

does not charge.

Incorrect power

pack being

used.

Verify that the power pack is

correct - PW-1205 (120 VAC) or

PWI-1210 (230 VAC).

Operations Guide – DOC. 6255A Docking Station for WPR-48: WPR-DS •5

Docking Station for WPR-48 Crestron WPR-DS

Further Inquiries

If, after reviewing this Operations Guide, you cannot locate specific information or

have questions, please take advantage of Crestron's award winning customer service

team in your area. Dial one of the following numbers.

• In the US and Canada, call Crestron's corporate headquarters at

1-888-CRESTRON [1-888-273-7876].

• In Europe, call Crestron International at +32-15-50-99-50.

• In Asia, call Crestron Asia at +852-2341-2016.

• In Latin America, call Crestron Latin America at +5255-5093-2160.

• In Australia and New Zealand, call Crestron Control Solutions at

+61-2-9737-8203.

You can also log onto the online help section of the Crestron website

(www.crestron.com) to ask questions about Crestron products. First-time users will

need to establish a user account to fully benefit from all available features.

Future Updates

As Crestron improves functions, adds new features, and extends the capabilities of

the WPR-DS, additional information and programming examples may be made

available as manual updates. These updates are solely electronic and serve as

intermediary supplements prior to the release of a complete technical documentation

revision.

Check the Crestron website (www.crestron.com) periodically for manual update

availability and its relevance. Updates are available from the Downloads | Product

Manuals section and are identified as an “Addendum” in the Download column.

6 •Docking Station for WPR-48: WPR-DS Operations Guide – DOC. 6255A
