Cornelius Nordic CCU0300 Series Guía
Nordic
Model CCU0300***1
Service Parts Manual
(Includes 50Hz. Units)
IMI CORNELIUS INC.
www.cornelius.com
Publication Number: 631806062
Revision Date: July 1, 2008
Revision: B
Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.
CCU0300 1 Service Parts Manual Manual Number 631806062
*
CCU Series Service Parts Table Of Contents
This parts list contains the service parts available for the CCU series icemakers listed below.
CCU0300**1 1 Air and Water Cooled
CCU0300**5 1 Air and Water Cooled
Engineering Revision Level
Check the model number on the data plate and refer to the correct listing for the specific component.
Check carefully that the correct part is identified and ordered.
Table of Contents Page 1
Bin and Exterior Components Page 2 - 3
Refrigeration System Page 4 - 5
Harvest Assist Assembly Page 6
Control Box Page 7
Evaporator Page 8
Water Pump Page 9
E-Mail: tech.service @cornelius.com
Website: www.cornelius.com
Telephone Number
800-238-3600 All Departments
The CCU Series Service Manual is available seperately, Part Number 631806061
Note: Model Number Suffix Indicates Machine Voltage As Follows:
1=115/60/1
2=208-230/60/1
3=208-230/60/3
5=230/50/1
Page 1
CCU0300 1 Service Parts Bin and Exterior Components
Page 2
CCU0300 1 Service Parts Bin and Exterior Components
Item CCU0300 1 1 CCU0300 5 1 Description
1 620204400 620204400 Trim Strip RH
2 620204399 620204399 Trim Strip LH
3 620204333 620204333 Panel Rear Access
4 620204562 N/A Bushing, Strain Relief
5 620204561 N/A Power Cord 115 Volt Only
6 620204519 620204519 Front Grill Large
7 620204520 620204520 Front Grill Small
8 620204327 620204327 Bin Assembly (Includes Item 10)
9 620204446 620204446 Hex Head Machine Screw
10 620204538 620204538 Drain Elbow
11 620204420 620204420 Clamp
12 620204912 620204912 Bin Door Assembly
620204913 620204913 Bin Door
620204455 620204455 Thumb Screw
620204380 620204380 Door Stop
13 620204914 620204914 Bin Top Assembly Stainless Steel
620204915 620204915 Plastic Corner Cap Left Side
620204916 620204916 Plastic Corner Cap Right Side
620204444 620204444 Truss Head Sheet Metal Screw-Plastic Corner
14 620204440 620204440 Top Panel Screw
15 620204442 620204442 Screw
16 620204460 620204460 Bin Fastener Thumb Nut Three Prong
17 620204368 620204368 Control Box Cover
18 620204909 620204909 Leg Set (4 each)
19 620204485 620204485 Ice Scoop
20 620204288 620204288 Rear Panel
21 620204397 620204397 Left Side Panel
22 620204397 620204397 Right Side Panel
23 620204813 620204813 Plastic Drain Fitting
24 N/A 620204917 Water Pump Cover
25 N/A 620204918 Cover Base Panel
Page 3
CCU0300 1 Service Parts Refrigeration
Page 4
CCU0300 1 Service Parts Refrigeration
Item CCU0300 1 1 CCU0300 5 1 Description
1 620204699 620204700 Compressor
2 620204618 620204618 Expansion Valve
3 620204601 620204601 Drier-Air Cooled
620204604 620204604 Drier-Water Cooled
4 620204534 620204534 Service Valve Core
620204535 620204535 Service Valve Cap
5 620204615 620204615 Hot Gas Valve Body
6 620204613 620204614 Hot Gas Valve Coil
7 620204468 620204469 Purge Valve
8 620204428 620204428 Flat Washer
9 620204742 620204742 Grommet
10 620204448 620204448 Lock Nut
11 620204743 620204743 Sleeve Compressor Mounting
12 620204435 620204435 Lock Nut (Leg)
13 620204763 620204763 Base Assembly
14 620204595 620204595 Water Condenser
15 620204326 620204326 Water Trough Assembly
16 620204443 620204443 Water Trough Screws
620204429 620204429 Rubber Washer
620204919 620204919 Water Trough Support Bracket
17 620204764 620204764 Fan Bracket
18 620204644 620204645 Fan Motor
19 620204579 620204579 Fan Blade
20 620204367 620204367 Fan Shroud
21 620204599 620204599 Air Condenser
22 620204420 620204420 Hose Clamp
23 620204528 620204528 Barbed Tee
24 620204813 620204813 Drain Adapter
25 620204288 620204288 Rear Panel
26 620204465 620204465 Water Regulator
27 620204529 620204529 Drop Adapter Fitting
28 620204539 620204539 Water Inlet Fitting
29 620204450 620204450 Flanged Lock Nut
30 620204471 620204471 High Temperature Safety Control
31 620204397 620204397 Side Panel S/S
32 620204397 620204397 Side Panel S/S
33 620204560 620204560 Water Pump Connector
34 620204294 620204294 Water Distribution Tube
Compressor Components
CCU0300 1 1 CCU0300 5 1 Description
620204699 620204700 Compressor
620204663 620204664 Overload
620204656 620204657 Start Capacitor
620204660 620204680 Compressor Relay
N/A 620204667 Run Capacitor
Page 5
CCU0300 1 Service Parts Harvest Assist Assembly
Item CCU0300 1 1 CCU0300 5 1 Description
1 620204366 620204366 Bracket, Probe Motor
2 620204630 620204631 Gear Motor
3 620204570 620204570 Clutch Assembly, 60 Degree
4 620204483 620204483 Snap Bushing
5 620204481 620204481 Snap Bushing
6 620204439 620204439 #6-32 x 1/2 Screw
7 620204484 620204484 Connecting Rod
8 620204424 620204424 Probe, Single Length
9 620204427 620204427 Flat Washer
10 620204451 620204451 Shoulder Screw
11 620204516 620204516 Spacer, Cam Switch
12 620204556 620204556 Cam Switch
13 620204407 620204407 Insulator
14 620204434 620204434 Pan Head Screw
15 620204452 620204452 Speed Nut Plate
620204314 620204315 Harvest Assist Assembly
Page 6
CCU0300 1 Service Parts Control Box
Item CCU0300 1 1 CCU0300 5 1 Description
1 620204479 620204479 Thermostat-Bin Control
2 620204557 620204557 Ice/Off/Wash Switch
3 620204553 620204553 Switch-Purge
4 620204477 620204477 High Pressure Control
5 620204476 620204476 Low Pressure Control (Timer Initiate)
6 N/A 620204667 Run Capacitor
7 620204656 620204657 Start Capacitor
8 620204660 620204680 Relay
9 620204555 620204555 Timing Module
10 620204471 620204471 High Temperature Safety Control
11 620204548 620204548 Relay
12 620204550 620204551 Socket-Relay
13 620204549 620204549 Hold Down Spring - Relay
Page 7
CCU0300 1 Service Parts Evaporator
Item CCU0300 1 1 CCU0300 5 1 Description
1 620204766 620204766 Evaporator Assembly-Half Cube (Shown)
1 620204765 620204765 Evaporator Assembly-Full Cube
2 620204294 620204294 Water Distribution Tube
3 620204453 620204453 Thumbscrew
4 620204429 620204429 Rubber Washer
5 620204709 620204709 Spillway
6 620204489 620204489 Left Side Evaporator Mounting Panel
7 620204490 620204490 Right Side Evaporator Mounting Panel
8 620204486 620204486 Water Return
Page 8
