Overview

DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

1. 14.1-in or 13.1-in TFT 1024 x 768 display

2. Microphone

3. Power Switch

4. Integrated RJ-11 Jack, 56K V.90 Mini PCI modem;

Optional RJ-11 and RJ-45 Jack with Intel PRO+

Mini PCI (not shown)

5. MultiBay

6. PC Card Slots

7. Battery Power Light

8. AC Power Light

9. Microphone Jack

10. Stereo Speaker/Headphone Jack

11. Primary Battery

12. Primary Hard Drive

13. Left/Right/Third Mouse Buttons

14. 3D Point Stick

15. Stereo Speakers

16. Cable Lock Connector

17. NTSC/PAL Connector

18. Lid Switch

19. Suspend Button

20. Status LED’s

21. Display Latch

A G

LANCE

• Immediateout-of-box productivity

with pre-installed software like

Microsoft Office Small Business,

and access to convenient

Compaq Online Services

• 8-MB Video SDRAM

• Weight starting at 5.3 lbs

• 1.1 inches thin

• Integrated 56K V.90 Mini PCI

modem

• Full-size keyboard

• User removable hard drive

• Dual battery support

• MultiBay technology supports an

additional 6-cell Battery, Second

Hard Drive, 24X Max CD-ROM,

4X DVD-ROM drive, or LS-120

drive

• AGP 2X Graphics

– 8-MB Video SDRAM

– 66-MHz graphics BUS

– Dual-view display support

– NTSC/PAL output

• Magnesium LCD display

enclosure

• Docking solutions

• Compaq Services including a

three-year, Worldwide Limited

Warranty

with a free one-year

second business day pick-up and

delivery service — Certain

restrictions and exclusions apply.

Consult the Compaq Customer

Support Center for details.

ONFIGURABLE

OMPONENTS

• Choice of Intel Pentium



III 500 or

450

• Choiceof 14.1 or13.3 TFT

1024 x 768 display

• Choice of 6, 12 or 18-GB

removable hard drives

• Choice of 24X Max CD-ROM or

4X DVD-ROM

• 64 MB standard SDRAM

upgradable to 320 MB

• Integrated Mini PCI V.90

data/14.4 Kb/s fax modem or

V.90

fax/modem Intel PRO+

Ethernet combination card)

• Choice ofPointing Stick or Touch

Pad

• Choice of Microsoft Office 2000

Small Business, Office 2000

Professional or Word 2000

• Other components available

UICK

PECS

Standard Features

2 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Flexible Solutions Configure to Order

Order the Prosignia Notebook 170 the way the customer wants it by selecting the processor, hard drive,

memory, and more. Purchase directly from Compaq or a Compaq Authorized Agent. Configurable components

and Options change frequently. Check Q-View or www.compaq.com for the latest options available from

Compaq.

Processor

Intel Pentium III processor 500 or 450 MHz

Cache Memory

256K Integrated

Memory

Standard 64 MB

Maximum 320 MB

Primary Storage

Diskette Drives 1.44 MB (All Models)

Hard Drives 18-, 12-, or 6-GB Ultra ATA

MultiBay Devices

4XDVD-ROM

24X Max CD-ROM

SuperDisk LS-120

MultiBay Battery

Secondary Hard Drive

Communications

Integrated Mini-PCI 56K V.90 modem or Mini PCI 56K V.90 modem and Ethernet NIC combination

Keyboard

102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special feature

hotkeys for instant access to power conservation, QuickLock/QuickBlank, toggle between internal and external,

or simultaneous displays, battery gauge, speaker volume control, brightness and contrast

Pointing Device

Touch Pad or Pointing Stick

PC Card Slots

Two Type II/One Type III PC Card Slot(s) which support both 32-bit CardBus (Full support in Windows 9.x)

and

16-bit PC Cards; zoomed video support in both slots

Multimedia

Compaq Premier•Sound™ for enhanced stereo audio

Integrated 16-bit Sound Blaster Pro-compatible stereo audio

Integrated stereo speakers and microphone

Ported Speaker Enclosure

Software/hardware volume control

Headphone out jack – supports stereo out

Microphone in jack

Software MPEG1 support

DVD movie playback software (optional)

Internal 4X DVD-ROM drive or 24X Max CD-ROM Drive

RCA TV-out port (NSTC/PAL)

2X AGP graphics with 8-MB SDRAM

ODELS

Configured to Order

Prosignia Notebook 170

Select the following to configure

your own Prosignia Desktop:

Processor

Memory

Hard Drive

Removable Storage

Optical Storage

Software

Modem

Network Interface

Controller

ODELS

Configure to Order

Prosignia Notebook 170

Select the following to configure

your own Prosignia Notebook:

Processor

Memory

Hard Drive

Removable Storage

Optical Storage

Modem or Modem/NIC

Combination Card

Software

UICK

PECS

Standard Features

3 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Interfaces

PC Card Two Type II/One Type III

Enhanced Parallel 1

Serial 1

TV out connector 1

External Monitor 1

External Keyboard/

Pointing Device 1

Expansion Base 1

Speaker/Headphone out 1

Microphone in 1

AC Power 1

RJ-11 1

RJ-45 1 (With optional Intel PRO+ Mini-PCI card)

Infrared 1 (4 Mb/s support)

(IrDA 4 MB compliant. IR performance will vary depending on performance

of IR peripherals and application used.)

USB 1

Graphics

2X AGP implementation with dedicated 66-MHz AGP graphics bus. ATI Mobility-P™ graphics controller with 8

MB of 125 MHz SDRAM. Up to 100 Hz external refresh at SVGA resolution up to 16.8M colors. Supports dual-

view display, with two different images on two different displays at different refresh rates. NTSC & PAL TV-out

support (integrated) up to 1024 x 768 resolution

Display

14.1-inch colorTFT with 1024 x 768 resolution (up to 16M colors internal)

13.3-inch colorTFT with 1024 x 768 resolution (up to 16M colors internal)

Operating System

Windows 98 Second Edition

Software

Microsoft Office 2000 Small Business, or

Microsoft Office 2000 Professional, or

Microsoft Word 2000

Norton AntiVirus

WinFAX Basic

Compaq Online Services

CompuServe and AOL

Diagnostics for Windows

Compaq Power Management

Online Safety and Comfort Guide

Reference Guide

Compaq Online Services

A full suite of Internet-powered solutions that provide reliable Internet access, online office management tools,

and

e-commerce capabilities – all designed to lower technology and staffing costs, and increase productivity for

growing businesses

Access the Internet

Briefcase

Backup

Courier

Delivery

Postage

All-in-One eBusiness Center

Message Center Lite

Message Center

RingMeNow

Small Business Resource Center

Online Training

UICK

PECS

Standard Features

4 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Security

Configuration Control Hardware

Memory Change Alert

Ownership Tag

Setup Password

Power-On Password

DriveLock

QuickLock

QuickBlank

Power Supply

External AC adapter, 10-foot power cord included

Battery

The Prosignia Notebook 170 offers an 8-cell standard Li-Ion battery, and an optional 6-cell MultiBay battery.

Typical battery life is over 2 hours for the 6-cell and over 3 hours for the 8-cell, depending on the exact

configuration and usage

Note: Actual results may vary with individual usage. When tested in standard configuration, using the Ziff-Davis

BatteryMark Test v2.0, the battery life of the Prosignia 170 will range up to 2.3 hours (6-cell) and 3.1

hours (8-cell). Standard configuration tested is considered to be one battery, a 1024 x 768 (64K colors)

14.1-in panel set at 50% brightness, 64-MB RAM and no drives other than the hard drive active.

Power Conservation

Hibernation

Instant-on via Standby

Pop-ups with three presets

One custom level of power conservation

Service and Support

Compaq Services provide a range of services including a three-year, Limited Worldwide Warranty, with 7 x 24

toll-free service line at 1-877-456-7878 and a free one-year, second business day pick-up and delivery service

from Compaq. All shipping and handling materials are supplied by Compaq.

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.

Note: Pick-up and delivery service is available in 48 contiguous US States and Canada. Eligibility for priority

pick-up (second business day return) is limited to certain geographic locations. Carry-in service available

outside the US and Canada.

UICK

PECS

Configurable Components

5 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Solutions Configure to Order

Configurable components are available directly from Compaq or through a Compaq Agent and are for first time

configurations only.

Base Unit (Choose one of the following)

All base units include Li-Ion Battery, AC Adapter, Diskette Drive and MultiBay Weight Saver

Intel Pentium III 500-MHz processor

Intel Pentium III 450-MHz processor

TFT Display Screen (Choose one of the following)

14.1″Panel

13.3″Panel

Primary Hard Drives (Choose one of the following)

18-GB SMART Hard Drive

12-GB SMART Hard Drive

6-GB Hard Drive

Memory (Optional Memory upgrade)

128-MB SDRAM

64-MB SDRAM

32-MB SDRAM

MultiBay Options (Choose one of the following)

4X - DVD-ROM Drive with software decoder

(Data transfer rates will vary from 150 KB/s to 5520 KB/s.)

24X Max CD ROM Drive

(Data transfer rates will vary from 150 KB/s to 3600 KB/s.)

MultiBay Devices (Optional)

SuperDisk LS-120

Second SMART Hard Drive (with Adapter)

Second 6-Cell Li-Ion Battery

Communications Options

Compaq Mini PCI 56K Modem

Compaq 56K (V.90) plus Intel PRO/100+ Mini PCI (Modem and Ethernet NIC)

Note: Designed only to allow faster downloads from 56K V.90 compliant sources. Maximum achievable download

transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem only supports

Windows 9.x and Windows NT 4.0.

Pointing Devices (Choose one of the following)

Touch Pad

Pointing Stick

Business Software (Choose one of the following)

Microsoft Office 2000 Professional

Microsoft Office 2000 Small Business

Microsoft Word 2000

UICK

PECS

Configurable Components

6 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Software (Optional)

Norton Utilities for Windows

Symantec Act

Symantec WinFax PRO

Symantec Mobile Essentials

Carbon Copy (complete version)

PcAnywhere 32

Intuit Quicken Deluxe 98

Microsoft Project 98 Upgrade

Corel WordPerfect Suite 8 Professional Upgrade

CorelDRAW 8 Upgrade

Netscape Communicator Internet Access Edition

Nestscape Communicator Deluxe Edition

Netscape Publishing Suite

Lotus 1-2-3 97 Upgrade

Lotus SmartSuite 97 Upgrade

Microsoft Front Page 98 Upgrade

Intuit Quick Books 5.0

Adobe Pagemaker 6.5

Adobe Photoshop 5.0

Adobe Illustrator 7.0

UICK

PECS

Options

7 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Enhancements

Enhancements are available through Compaq Authorized Resellers for first time configurations or upgrades, or

directly from Compaq or a Compaq Agent for upgrades.

Memory

128-MB Memory Upgrade 144547-B21

64-MB Memory Upgrade 144546-B21

32-MB Memory Upgrade 144545-B21

Monitors

TFT8000 Flat Panel 307906-001

TFT5000 Flat Panel 325700-001

P1610 Color 305708-001

P110 Color

(May not be compatible with the Monitor Support Stand, or Convenience Bases due to weight

limitations.)

284956-001

P75 Color 307806-001

V1000 Color

(May not be compatible with the Monitor Support Stand, or Convenience Bases due to weight

limitations.)

351757-001

V900 Color

(May not be compatible with the Monitor Support Stand, or Convenience Bases due to weight

limitations.)

303500-001

V75 Color (carbon) 307710-002

V500 Color 325900-001

S900 Color

(May not be compatible with the Monitor Support Stand, or Convenience Bases due to weight

limitations.)

360562-001

S700 Color 360512-001

MultiBay Devices

18-GB SMART Hard Drive 153927-B21

12-GB SMART Hard Drive 153926-B21

6-GB SMART Hard Drive 153925-B21

4X DVD-ROM Drive

(Data transfer rates will vary from 150 KB/s to 5520 KB/s.) 153952-B21

24X Max

CD-ROM

(Data transfer rates will vary from 150 KB/s to 3600 KB/s.) 146812-B21

SuperDisk LS-120 144557-B21

Li-Ion 6-cell Battery 144558-B21

UICK

PECS

Options

8 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Docking Solutions

Port Replicator

144488-004

Convenience Base with Intel NIC 144487-004

Convenience Base Monitor Stand 122931-B25

PC Cards/Communications/Multimedia

Wireless LAN 2 Mb/sec 134711-001

Compaq M420 56KGlobal Modem

(Designed only to allow faster downloads from V.90 and/or K56flex compliant sources.

Maximum achievable download transmission rates currently do not reach 56 KB/s, and will

vary with line conditions. Modem only supports Windows 9.x and Windows NT 4.0.)

317900-001

10/100 TX PC Card UTP Controller 335506-B21

10 T PC Card UTP Controller 292806-B21

10 2 PC Card Coax Controller 292807-B21

10/100 TX PC Card UTP Controller Upgrade 292813-B21

Margi DVD-to-Go PC Card 202861-B21

16/4 TR PC Card IBM UTP/STP Controller 301208-B21

For additional compatible PC Cards, view the Compaq PC Card Solutions List on the Compaq website at:

http://www.compaq.com/support/techpubs/pcmcia/pccardlist.html

Power

Primary Battery (8-cell) 153922-B21

External Battery Charger 135555-001

AC Adapter 120765-001

AC Line Cord (4 ft) 213379-007

Auto Adapter 401043-B25

Aircraft Adapter 386504-B21

Input Devices

External Enhanced III Keyboard (carbon) 118003-008

Compaq Mouse (carbon) 103180-B21

Compaq/Microsoft Intellimouse 294306-B21

Numeric Keypad (carbon) 294317-B21

Other

Compaq Security Lock 294316-B21

Portable Video Conferencing 296954-001

Headset with Microphone 220460-001

MP1600 Microportable Projector 386202-001

Universal Monitor Stand (opal) 316246-B21

Carrying Cases

Compaq Value Case 294266-B21

Compaq Workstation Case 294267-B21

Compaq Global Case 294268-B21

Compaq Executive Case 294269-B21

Compaq Professional N Case 401366-B21

Compaq Professional L Case 401367-B21

UICK

PECS

Memory

9 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

Compaq Prosignia 170

TANDARD

EMORY

64 MB SDRAM installed on the System Board

Standard Slot

1 2

64 MB

Empty

TANDARD

EMORY

LUS

PTIONAL

EMORY

Support for up to 320 MB of SDRAM memory is available with the installation of optional

SDRAM Memory Kits in addition to the 64 MB SDRAM on the System Board.

Up To Slot

1 2

320 MB

256 MB

192 MB

160 MB

128 MB

This chart does not represent all possible memory configurations. The following memory

options are available from Compaq:

•

128-MB Memory Upgrade

•

64-MB Memory Upgrade

•

32-MB Memory Upgrade

UICK

PECS

Storage

10 DA-10472-00A-004 — 04.12.2000

Compaq Prosignia

Notebook 170

Configure to Orde

OMPAQ

ROSIGNIA

OTEBOOK

170 D

RIVE

UPPORT

RIVE

UPPORT

Quantity

Supported Drive Bay

Supported

Removable Media

1.44-MB Diskette Drive Up to 1 MultiBay

24X Max

CD-ROM Drive

4X DVD-ROM

SuperDisk LS-120

Second HDD

18-GBSMART Hard Drive

12-GBSMART Hard Drive

6-GB SMART Hard Drive

Note: Each Prosignia 170 unit ships with a 1.44-MB diskette drive and cable, allowing itto be plugged externally to the parallel

port if the customer desires.

Note: Second drive in MultiBay requires the Hard Drive Adapter (included).

Hard Drives

18-GB SMART Hard Drive

12-GB SMART Hard Drive

6-GB SMART Hard Drive

1 Dedicated hard drive bay

1 MultiBay

2 Dedicated hard drive bay

Otros manuales para Prosignia 170

Tabla de contenidos

Otros manuales de Computadora portátil de Compaq

Compaq

Compaq EVO NOTEBOOK N410C Instrucciones de uso

Compaq

Compaq Armada E500 Series Manual de usuario

Compaq

Compaq Presario R3000 - Notebook PC Guía de inicio rápido

Compaq

Compaq 7400 - Armada - PII 366 MHz Manual de usuario

Compaq

Compaq Armada 4200 Manual de usuario

Compaq

Compaq 6530s - Notebook PC Manual de usuario

Compaq

Compaq Armada M300 Series Instrucciones de uso

Compaq

Compaq Evo N200 Instrucciones de instalación

Compaq

Compaq Presario R3000 - Notebook PC Manual de usuario

Compaq

Compaq Presario 1246 Manual de usuario

Compaq

Compaq Presario CQ41-200 - Notebook PC Manual

Compaq

Compaq Evo Notebook N800c Manual

Compaq

Compaq Personal Computer Guía del usuario

Compaq

Compaq 1700 - Armada - PII 266 MHz Manual de usuario

Compaq

Compaq Armada M300 Series Instrucciones de uso

Compaq

Compaq Evo Notebook N400c Series Manual de usuario

Compaq

Compaq Armada E500 Series Manual de instrucciones

Compaq

Compaq Presario X1000 - Notebook PC Manual de instrucciones

Compaq

Compaq Presario R3000 - Notebook PC Manual de uso y cuidado

Compaq

Compaq Presario R3000 - Notebook PC Guía

Compaq

Compaq Armada 7800 Guía de referencia rápida

Compaq

Compaq Presario CQ45 Manual

Compaq

Compaq Presario 1850 Manual de usuario

Compaq

Compaq Presario 1900 XL1 Manual de usuario

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
