Comeup DH-300 Manual de usuario

Heavy Duty Hoist

Model: DH-300

PN: 752639 12V

Introduction

XFeature

Lifting capacity: 300 kg wire rope top layer

Lifting height: 12 m

Lifting speed: 5 M/min

Motor output: 300 W x 35 A at DC12V

Brake: Electromagnetic and mechanical ratchets

Control: Pendant switch powers the hoist

XUnpacking

．Hoist assembly………………………………………………………….. 1pc

．Control ass’y……………………………………………………………… 1pc

．Pendant switch PB-306 w/cord 0.75 mm x 3C x 4.4m………………. 1pc

．Wire rope 4.8 mm x 12 m w/safety hook…………………………….... 1pc

XRead this manual carefully

You should carefully read and understand this manual before operating it.

Careless hoist operation may result in personal injury hazards or property

damage.

XInformation requesting or parts ordering

Please specify the followings information:

．Hoist PN

．Serial number

．Part description

．Replacement part number

．Quantity for each part

Installation

Before using the hoist, make sure all electrical components have no

corrosion or damaged; the environment should be clear and dry.

XWire rope replacement

．Insert the wire rope into the hole of drum and fix it with a P. T. screw, then

press the "UP" button of switch for rotate the drum in the lifting direction.

．Wind the wire rope accurately around the drum, and an irregular winding

will cause the load to be swing, thus damaging the wire and reducing the

life of hoist.

XWiring Diagram

Warning

．The hoist is not intended to be used in any manner for the movement or lifting

of personnel.

．The lifting capacity shown is based on the top layer of rope on the drum.

．The rope winding on the drum shall remain 5 wraps from the drum.

Parts List

V

er:0

Item

No. Description Part No. Qty

1 Gearbox rear cover kit 880546 1

2 Ratchet stopper kit 880547 2

3 2nd shaft 880548 1

4 3rd gear kit 880549 1

5 Brake kit 881516 1

6 Tie bar kit 880552 1

7 Tie bar kit A 880553 2

8 Gearbox support rack kit 880555 1

9 Output shaft kit 880556 1

10 Drum kit 881518 1

11 Motor coupling kit 881515 1

12 Motor support rack kit 880558 1

13 Torque shaft kit 881517 1

14 Motor housing kit 881908 1

15 Motor kit 12V 881909 1

16 Control ass’y 881913 1

17 Wire rope w/hook 881926 1

Hoist Assembly
