Comeup WT-180 Manual de usuario

Electric Winch

Model: WT-180

PN : 151800 400V50Hz

151830 380V50Hz

Introduction

XFeature

Lifting capacity: 180 kg wire rope top layer

Lifting height: 98 m

Lifting speed: 17-23 m/min at 50Hz

Brake: Electromagnetic spring-applied failsafe brake

Control: Pendant switch powers the winch

XUnpacking

．Winch assembly 1pc

．Wire rope 5 mm x 100 m 1pc

．Weight hook CHW-0033 1pc

．Low voltage control ass’y LV-320 1pc

．Pendant switch PB-306 w/cord 1.25 mm2

x 3C x 3 m 1pc

XRead this manual carefully

You should carefully read and understand this manual before operating it.

Careless winch operation may result in personal injury hazards or property

damage.

XInformation requesting or parts ordering

Please specify the followings information:

．Winch PN

．Serial number

．Part description

．Replacement part number

．Quantity for each part

Installation

Before using the winch, make sure all electrical components have no

corrosion or damaged; the environment should be clear and dry.

XPerformance

XWiring Diagram

Warning

．The winch is not intended to be used in any manner for the movement or

lifting of personnel.

．The lifting capacity shown is based on the top layer of rope on the drum.

．The rope winding on the drum shall remain 5 wraps from the drum.

Winch Model WT-180

Motor kw x p 0.75 x 4

Size (mm) 5

Recommend

Wire Rope Breaking (kg) 1,230

Rated Load

(kg) 50Hz 252 Rated Load

(kg) 50Hz 233.3 Rated Load

(kg) 50Hz 217.2

Speed

(m/min) 50Hz 17.0 Speed

(m/min) 50Hz 18.3 Speed

(m/min) 50Hz 19.7

1st

Layer

Rope-Winding Cumulating

Sum

(

)

14.5

2nd

Layer

Rope-Winding

Cumulatin

Sum

(

)

30.2

3rd

Layer

Rope-Winding

Cumulatin

Sum

(

)

47.1

Rated Load

(kg) 50Hz 203.2 Rated Load

(kg) 50Hz 190.2 Rated Load

(kg) 50Hz 180

Speed

(m/min) 50Hz 21.0 Speed

(m/min) 50Hz 22.4 Speed

(m/min) 50Hz 23

4th

Layer

Rope-Winding Cumulating

Sum (m) 65.1

5th

Layer

Rope-Winding

Cumulating Sum (m) 84.3

6th

Layer

Rope-Winding

Cumulating Sum (m) 100

Parts List

Part No. configurations:

Item No. Description Part No. Qty

1 Motor kit As arranged 1

2 Gear box kit 882116 1

3 Motor coupling 882117 1

4 1st stage carrier 882118 1

5 2nd stage carrier 882119 1

6 Connecting base kit 882120 1

7 Support rack A kit 882121 1

8 Drum kit 882122 1

9 Support rack B kit 882124 1

10 Bearing base kit 882126 1

11 Over-winding bracket kit 882128 1

12 Transmitting plate 882129 2

13 Stopper kit 882130 2

14 Up limit lever shaft kit 882131 1

15 Left returning spring kit 882132 1

16 Right returning spring kit 882133 1

17 Base plate kit 882134 1

18 Limit switch kit 882135 2

19 Low voltage control ass’y LV-320 882136 1

20 Wire rope 882139 1

21 Weight hook CHW-0033 880505 1

Cycle Voltage kw x p Motor

50 Hz 400 / 230 V 0.75 x 4 882113

50 Hz 380 / 230 V 0.75 x 4 882115

Winch Assembly
