Coffee Queen Harmony Manual de usuario

Yourretaildealer

...............................................................................

User manual

”...WITH A PASSION FOR COFFEE”

Rev. 080215

U / GB

Harmony

COFFEE QUEEN

...............................................................................

1. Table (list) of contents.

1. Tableofcontents page. 2

2. General 3

3. Overviewofcomponentsfront 4

3. Overviewofcomponentsmixingsystem 5

4. SERVICE:Installationandstart 6 - 7

Placethe brewer

Connections:Electricity/Water

Startingupmachine

Fillcanisters with ingredients

Fillbean container with coffee beans

5. Operation

Brewingof coffeein cup 8

Brewingof jug 9

6. Cleaningprogram

Automaticcleaning of mixingbowls 10

AutomaticcleaningofIn/Outletvalves 11

Rotatebrewmechanism withoutwater or ingredients 12

Automaticcleaning of brewmechanism, mixingbowl 13-14

7. Weeklycleaning

dismantlemixersystem 15

washtheseparts 15

assemblemixer system 16

8. Cleaningandmaintenance

Outwardcleaningandwhen needed 17

Cleaning,grinder 17

Cleaningand dismantlingof coffee filter 18

8. Maintenance,grinder 19

9. Cup counterand Easyaccess 20

10. Safetyfunctions 21

11. Failure messages 21

12. Storage/Transport. 21

13. Dimensionsketch 22

14. Circuit diagram. 23

15. Installationofcoinmechanism 24

2. General. Harmony

We congratulate toyour choiceofa CoffeeQueen Harmony Freshbrewmachine.

Please read this manual before you take the machine into operation for the first time.

Themanualcontains importantinstructions for asafe andproperuse ofthe machine.

Alwayskeepthis manualwithin reach forthe user!

Coffee Queen / Harmony

- Makingfreshlycoffee cupbycup

- Withan internalgrinder for grinding of coffee beans

- Jugfacilitywith key switch

- 10 choices of drinks,

- 3ingredientscanisters +bean container,

- Brewingmechanismwith coffeefilter

- Electronicallytemperaturecontrolled

- Adjustablecoffeestrength

- Illuminatedcupwhilebrewing

- Clockfunctions

Facts:

Height 925 mm

Width 420 mm

Depth 580 mm

Weight 43kg(+groundcabinet 25kg) packing approx.5kg

Tankage 2,4 litre

Electricity 230V/2200W

Waterconnection ½”outside thread (enclosed)

Ingredientscanisters 1. espresso

1.chocolate

1.topping

1.coffee beans

3. Overview of components, front Harmony

Outlet for drinks

Cupholder

Drip tray insert

Drip tray

Drinks

Door lock

Display

Strength of drinks ++ / - -

Key switch

Bean container

Lid, bean container

Optional:

Base cabinet with storage and

largewaste bin.

3. Overview of components, mixer system. Harmony

Detail;Ingredients; Width; Height; Capacity./cups Volume/litre Amount/unit

Canister; coffee beans 165 190 2,5kg / 208 7,3 1

Canister; espresso 67 250 0,5kg / 220 2,55 1

Canister; chocolate 67 250 1,5kg / 50 2,55 1

Canister; topping 67 250 1,1kg / 120 2,55 1

Brewing

mechanism

Outlet

drinks Waste box

Bean

container

ON/OFF

switch

FUSE holder

Grinder

Mixer bowls

Chute

Ingredients-

canister

Door lock

ON / OFF

switch

4. Service. Installation and start Harmony

1. Placethe breweron aflat Connect theelectrical plugto aseparate

levelandwaterproofsurface. grounded wall socket230V 10A

OBSERVE!

Make sure there is a space behind

the machine for free flow of air.

( minimum 10cm ).

2. Connectattached watertube to coldwater withan R 1/2”.

Makesurethat thewater hose notare kinkedanywherewhen machineis

pushedinto place.

Please flush water tube before connecting it to machine, this to avoid any

particles to damage the inlet valve.

3. Openthewaterinlet.

4. Turnon the ON-OFFswitchinside thedoor.

Water is beenfilled intothetankautomatically with

2,4 litresof water.Theheatingwill not startbefore

thewaterlevelreaches thelevelsensor.

Set temperature is approx 97ºC.

5. Close door.

90º

4. Service. Installation and start Harmony

6. Fill canisters with ingredients.

Takeout(this toavoidunnecessary

spillagein the machine)ingredient

canistersandfill themwithingredients.

7. When placing the ingredient canisters;

Makesure that theoutlet pipeson the

ingredientcanisters are touchingthe steam

traps(A).

(A).

8. Fill bean container with coffee beans.

1.Remove lidon beancontainer and fill bean

containerwith coffeebeans without

additives (as tasted oils or sugar).

2.Openclosing hatchon bean container.

When water in tank have the right temperature

the message ”Low temp.” will disappear and ”please wait”

the machine is ready to use.

Brewing of coffee in cup, etc.

1. Placea cup in the centreof thecup holder..

2. The strength has a standard setting,

if you wish to increase or decrease it, do as follows

ifnot continue topoint 3.

Stronger drink;

Increase by pushing + or ++ for 5% or 10%

alternative

Weaker drink;

Decrease by pushing - or -- for 5% or 10%

(theindication lampwill goup ordown

dependingof choice).

3. Choosedrinkby pushingonthe buttontothe right

ofeachmenu.

The display will show; ”Please wait”, and the cup

willbeilluminated.

Wait until thelight oncup andmessage

”Please wait”

hasbeenturned offbeforeyou take yourcup.

Enjoyyourdrink.

5. Operation: Brewing of coffee in cup Harmony

Brewing of jug.

1. Liftupthecupholder.

Placea jugin thecentre of drip tray.

2. Turnonthe keywithjugsymboleclockwise.

3. 6cups of brewing is standardsettings,

Changeamountof cupsbypushing + or- button.

Optionalup to12 cups ordown to1 cup brewing.

4. Pushthebutton for drink1.

Wait until the light and message ”Pleasewait” has

beenturnedoff beforeyoutake out thejug.

Servea jugwith goodcoffee.

5. Operation: Brewing of jug Harmony

Serving pot 1, 8L

art.nr.110001

Servingpot 1,2L

art.nr.1103091

2. 3.

10.

6. Cleaning program. Harmony

By cleaning means that water is flushed and whipper motor rotates.

Themixer bowls caneasily becleaned with thekey switch

in”cup”(normal) position.

Automatic cleaning of mixer bowl No:2

Weekly cleaning! Automatic cleaning of mixing bowls 2 or 3.

Ifyouonly wish tocleanthe mixer bowlandwhipper house;Followthese

instructions:

1. Place a jug in the drip tray.

2. Turnthe key (1)slowly ninety degreesandback again.

3. Push button (3) for 6 seconds.

After4seconds thesignal willgo faster.

After6 seconds the mixer bowland thewhipper houseno.2

startsto be cleaned for5 seconds.

The display shows: ”Cleaning 2”.

Automatic cleaning of mixer bowl No:3

1. Place a jug in the drip tray.

2. Turnthe key slowlyninetydegrees andbackagain.

4. Push button (4) for 6 seconds.

After4seconds thesignal willgo faster.

After6 seconds the mixer bowland thewhipper houseno.3

startsto be cleaned for5 seconds.

The display shows: ”Cleaning 3”.
