Code Alarm Ca5354 Manual de usuario

PROFESSIONAL

SERIES

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

Deluxe Vehicle Remote Start System

with 900Mhz 2 Way Conrming LED

Remote Control

Owner’s Guide

for models:

ca5354

2ca5354 Owners rev A

Table of Contents

Using Your Remote Control.................................................................... 3

Using the Keyless Entry .................................................................... 3

Two Stage Door Unlock (optional)..................................................... 3

Activating Trunk Release (optional)................................................... 3

Activating AUX 1 (optional)................................................................ 3

Using the Progressive Car Finder Feature........................................ 3

Using the Personal Protection Alarm................................................. 3

Programmed Transmitter Notication................................................ 4

Valet Mode ........................................................................................ 4

Eliminating Lock / Unlock Notication Chirps .................................... 4

Using Your Remote Starter..................................................................... 5

Remote Start Ready Mode................................................................ 5

Cancelling Remote Start Ready Mode .............................................. 5

Remote Starting Your Vehicle............................................................ 6

Remote Start Shutdown .................................................................... 6

Entering Your Vehicle while it is Running via Remote Start .............. 6

Preheating or Precooling the Vehicle’s Interior ................................. 6

User Programmable Run Time / Run Time Extension....................... 7

Using the Quick Stop Feature ........................................................... 7

Operating the Daily Start Timer ......................................................... 7

Temperature Start Mode.................................................................... 8

Remote Start Safety Features........................................................... 8

Transmitter Button Functions ................................................................ 9

 2WayLEDTransmitterNotications................................................... 10

Replacing Remote Control Batteries................................................... 11

Warranty Information ............................................................................ 12

Using Your Remote Control

Using the Keyless Entry

The button is used to lock the vehicle’s doors, the button is used to unlock the

vehicle’s doors. To lock or unlock the doors simply press and release the desired

function button one time. For your convenience, the parking lights will ash once when

the doors are unlocked and twice when the door are locked.

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the or button to activate an audible locking/

unlocking response from the vehicle. If your system is set up for 2 step unlock, a third

press of unlock will activate the audible response.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will ash the parking lights

and sound 5 times at low volume, increasing in volume each time the button is

pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection alarm.

During panic mode, the normal function of the transmitter buttons will be suspended.

The transmitter’s and buttons can be used to lock and unlock the door (if the

option is installed). To stop the alarm, press and hold the button on the transmitter

again for 3 seconds. The system will automatically stop after 30 seconds.

Activating the Trunk Release Feature (Optional)

The button is used to open the trunk of the vehicle. To open the vehicle’s trunk

press and hold the button for 3 seconds.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will unlock

only the driver’s door. Press again within three seconds to unlock the remaining

doors.

Activating AUX 1 (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed for a

wide range of functions like power window or sunroof automation, please consult your

installing dealer to determine the functionality of your system.

4ca5354 Owners rev A

Valet Mode

Valet Mode is used to disable the system from remote starting. To enter or exit valet

mode simply follow the 4 steps outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

Eliminating Lock / Unlock Notication Chirps

System lock and unlock notication chirps can be toggled ON or OFF without

entering the programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Programmed Transmitter Notication

As a security precaution each time the vehicle’s ignition is turn on the status LED

light with ash the number of transmitters programmed into the system. This helps

to identify unauthorized transmitters from accessing your vehicle. If you believe an

unauthorized transmitter has been programmed to your system, contact your installing

dealer for assistance.

Using Your Remote Starter

Remote Start Ready Mode - Manual Transmission Vehicles Only

To activate the remote start function, the system must rst be in Remote Start Ready

Mode. Follow the steps below to enter remote start ready mode.

1. While the engine is running by the ignition key;

a. Set the parking brake

b. Place the transmission in neutral.

2. With your foot off the brake pedal, press and release the button 2

times within 2 seconds. The LED will ash 3 times and the parking

lights will turn on to conrm the system has entered quick stop mode.

3. Remove the keys from the ignition, the vehicle will remain running in

quick stop mode.

4. Exit the vehicle and close all vehicle doors.

5. Within 1 minute of step 1, press the button to lock the vehicle’s

doors. The vehicle will shutdown and sound 2 short chirps then 1 long

chirp to conrm ready mode is set.

Remote Start Ready Mode must be enabled if your vehicle is equipped with a

manual transmission.

Cancelling Remote Start Ready Mode

The system will exit remote start ready mode if any of the following occur:

Open any door

Open the hood or trunk (if connected)

Press the brake

Release the parking brake

Turn the ignition ON

6ca5354 Owners rev A

Remote Starting Your Vehicle

To activate the remote start function, press and release the button 2 times within 2

seconds. The system will sound, the parking lights will ash 1 time and the system

will check the vehicle to ensure it is safe to start. If all safety parameters are correct,

the vehicle will start within 5 seconds. The vehicle’s parking lights will turn on (or ash

depending on system settings) as a visual indication that the vehicle has started and is

running.

If your vehicle stalls or does not start, the system will pause 5 seconds, then try

2 more times to start the vehicle (a total of 3 attempts). The system will pause

5 seconds between each start attempt. If the vehicle does not start after the 3rd

attempt, the system will abort the remote vehicle start process.

Note: Do not leave children or animals unattended in the vehicle when using the

remote start feature.

Note: Manual transmission vehicles - Remote Start Ready Mode must be set.

Preheating or Precooling the Vehicle’s interior

Before exiting the vehicle, set the temperature controls to the desired setting and

operation. After the system starts the vehicle, the heater or air conditioner will activate

and heat or cool the vehicle’s interior to your setting.

Remote Start Shutdown

Press and hold the button for 3 seconds to turn the vehicle off.

Entering the Vehicle while it is Running via Remote Vehicle Start

1. Unlock the vehicle’s doors.

2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!

3. Insert the key into the ignition switch and turn to the ON or RUN

position.

4. Press the brake pedal. The remote vehicle starter will disengage and

the vehicle will operate normally.

Using the “Quick-stop” Feature - Automatic Transmission Vehicles

If you want to make a short stop and keep your vehicle running (to keep the interior

warm or cool), the quick-stop feature allows you to do this while keeping your vehicle

secure and your keys with you.

To engage quick stop:

1. Stop the vehicle and place the transmission in PARK.

2. With your foot off the brake pedal, press and release the button 2

times within 2 seconds. The LED will ash 3 times to conrm quick

stop is entered.

3. Remove the keys from the ignition and exit the vehicle. Press the

button to lock the vehicle’s doors if desired.

Note: Do not leave children or animals unattended in the vehicle when using the

quick-stop feature.

Operating the Daily Start Timer

The system has the ability to start your vehicle based on a 24-hour countdown timer.

This feature requires a two-part activation sequence. From the remote, while in range

of the vehicle, pressing both the & buttons together will activate the 24 hour

countdown timer (the vehicle will start 24 hours from this time). Next, When you are

nished operating the vehicle for the day, perform the following steps to complete the

process.

1. Turn the ignition ON/OFF (vehicle must be disarmed).

2. Within 10 seconds, while pressing the brake, press and release the

button twice.

3. The vehicle will emit 2 chirps and ash the parking lights 4 times.

User Programmable Run Time / Run Time Extension

The system has the ability to allow the user to extend the time the vehicle will be

running under control of the remote start. This will only extend the run time back to the

current run time setting during the current remote start cycle. If your system is set to

run 15 minutes and the time remaining is 4 minutes, extending the run time will reset

the countdown timer to 15 minutes and your vehicle will continue to run for another 15

minutes. Follow the steps below to extend the vehicle’s run time.

1. The remote start must already be active.

2. Press and release the button 4 times.

3. The system will chirp 1 time and ash the parking lights 4 times to

conrm that the run time has been reset.

8ca5354 Owners rev A

Remote Start Safety Features

For safety and security reasons, the system will shutdown or prevent the remote

vehicle starter from activating if any of the following occur:

1. The vehicle hood is open.

2. The brake pedal is pressed prior to turning the ignition key to the ON

position.

3. The engine is over-revved (tach checking only).

4. Valet mode is active.

Temperature Start Mode

The system has the ability to start the vehicle if the temperature drops below a preset

temperature threshold. Once activated, the system will only start the vehicle one time

based on the temperature setting and will be cancelled if the vehicle is started with the

key or remote started by the transmitter. Temperature is read from the module, located

below the dashboard in most instances, and the vehicle’s interior temperature may

vary from the ambient temperature.

1. The vehicle must be armed.

2. Press and release both the & buttons together.

3. The vehicle will emit 1 chirp and ash the parking lights 1 time.

Note: This feature is defaulted OFF and must be set in option programming.

Transmitter Button Functions

1 Way

Transm itterLock Unlock Car Find /

PanicStart N/AOperation Method

Lock XPress and Release

Unlock X Press and Release

Trunk XPush and Hold (3 Sec)

Car FinderX

Press and Release

PanicX

Push and Hold (3 Sec)

Remote Start XPress and Release (1 or 2 times depending

on selectable option)

Remote Start

Shut DownXPush and Hold (3 Sec)

Run Time

ExtentionXPress and Release 4 times.

Daily Start

TimerX X Press Lock + Start

Temperature

StartX X Press Unlock + Start While Armed

2 Way

Transm itterLock Unlock Car Find /

PanicStart N/AOperation Method

Lock XPress and Release

Unlock XPress and Release

Trunk XPush and Hold (3 Sec)

Car FinderX

Press and Release

PanicX

Push and Hold (3 Sec)

Remote Start XPress and Release (1 or 2 times depending

on selectable option)

Remote Start

Shut DownXPush and Hold (3 Sec)

Run Time

ExtentionXPress and Release 4 times.

Daily Start

TimerX X Press Lock + Start

Temperature

StartX X Press Unlock + Start While Armed

10 ca5354 Owners rev A

2 Way Transmitter Notications

FUNCTION BEEPS / LED FLASHES

Lock 2 Beeps / Flashes

Unlock 1 Beep / Flash

Trunk Release 1 Beep / Flash if vehicle is currently locked.

Remote Start Activation 1 Beep / Flash

Conrm Remote Start 4 Beeps / Flashes (repeats 3 times)

Remote Start Running 1 Flash per 3 seconds for duration run time

Remote Start Shutdown 3 Long Beep / Long Flashes (repeats 3 times)

Car Find / Panic 1 Beep / Flash

Low Battery 2 Beeps / Flashes when button is pressed

Tabla de contenidos

Otros manuales de Arranque remoto de Code Alarm

Code Alarm

Code Alarm ca5554 Professional series Manual de usuario

Code Alarm

Code Alarm ca5554 Professional series Manual de usuario

Code Alarm

Code Alarm CA1BTW5 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 4050 Manual de usuario

Code Alarm

Code Alarm ca5553sst Manual de usuario

Code Alarm

Code Alarm Professional Series CA 6550 Manual de usuario

Code Alarm

Code Alarm ca4054 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL CASECRS Manual de usuario

Code Alarm

Code Alarm ca 1051 Manual de usuario

Code Alarm

Code Alarm CA 6150 Manual de usuario

Code Alarm

Code Alarm CA611 Manual de usuario

Code Alarm

Code Alarm PC 4400 Manual de usuario

Code Alarm

Code Alarm CA2LCD5 Manual de usuario

Code Alarm

Code Alarm ca 4552 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 5050 Manual de usuario

Code Alarm

Code Alarm ca5154 professional Series Manual de usuario

Code Alarm

Code Alarm CA 5051MT Manual de usuario

Code Alarm

Code Alarm CA 1055 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA-520 Manual de usuario

Code Alarm

Code Alarm ca5153 Manual de usuario

Code Alarm

Code Alarm CSM-3 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 1050 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual

Rooboost

Rooboost RB-1750WP Manual de usuario

Code Alarm ca5354 Manual de usuario

Manuales populares de Arranque remoto de otras marcas
