Code Alarm Ca5154 professional Series Manual de usuario

CCCc~LA~m

i=)r:lOFESSIONAI

SEr:liES

Automatic

I Manual Transmission

Remote Start

with

Keyless

Entry

Installation Guide

for

models:

ca5154

Table

Contents

Before You Begin.........................................................................................3

Wire

Connection

Guide...............................................................................4

Pin Main Harness .................................................................................5

Parking Light Harness......................................................................8

6 Pin Start Harness ...................................................................................9

4 Pin Alternate Harness...........................................................................1

Door Lock Harness ........................................................................

Additional

Ports

.........................................................................................15

Antenna

LED

Programming Port........................................................15

OBI

Port...................................................................................................15

Telematic Interface Port...........................................................................15

Set Up &

Programming

.............................................................................16

Transmitter Programming........................................................................16

Manual Feature Programming.................................................................16

Programming Feature Banks ..................................................................17

Tach

Programming ..................................................................................20

Smart Tachless Mode..............................................................................20

Feature

Descriptions

.................................................................................

Transmitter

Button

Functions

..................................................................29

Remote Start

Shutdown

Diagnostics

......................................................

System

Layout

...........................................................................................

2 ca5154 Install rev A

•

...

BEFORE YOU BEGIN

PROFESSIONAL INSTALLATION

STRONGLY RECOMMENDED

Roll down window to avoid locking keys

vehicle

during installation

Avoid mounting components or routing wires near

hot surfaces

Avoid mounting components or routing wires near

moving parts

Tape or loom wires under hood for protection and

appearance

Use a Digital Multi Meter for testing and verifying

circuits. DO NOT USE A TEST LIGHT, OR

"COMPUTER SAFE PROBE" as these can set off air

bags or damage vehicle computers.

Technical Support (800) 421-3209

orgoto

http://avxtech1.com

a..

"r"

(/)

ZI-

-I

a..(!)

('t')-

0:::

(/)

a..

<.0

Pin Main Harness

GRAY/RED PARKING BRAKE INPUT ( - )

PURPLE DOOR INPUT (

GREEN DOOR INPUT

)

BLACK/WHITE ILLUMINATED ENTRY OUTPUT ( - )

BROWN/BLACK HORN

OUlPUT

( - )

RED/WHITE TRUNK RELEASE OUTPUT ( - )

BLUE/BLACK START STATUS I ACTIVE OUTPUT ( - )

PURPLE/WHITE TACH INPUT

GRAY HOOD PIN INPUT ( - )

BROWN/RED BRAKE INPUT (

+ )

VIOLET/BLACK AUX 1

OUlPUT

( - )

3 Pin Parking Light Harness

BLACK GROUND

WHITE/RED PARKING LIGHT INPUT

WHITE PARKING LIGHT OUTPUT

6 Pin Start Harness

PURPLE STARTER

OUTPUT-

MOTOR SIDE

RED BATTERY 12V (

ORANGE ACCESSORY 1 ( + )

PINK/WHITE IGNITION 2 ( + )

RED/WHITE BATTERY 12V (

PINK IGNITION 1 ( + )

ca5154 Install rev A

-o

a..o

N.....J

4 Pin Alternate Harness

BLACK/YELLOW PULSE DURING CRANK

(-)

GREEN/WHilE

PULSE

AFlER

SHUIDOWN

( - )

LTBLUE FACTORY ARM

PULSE

AFlER

START

)

LT GREEN/BLACK FACTORY DISARM

PULSE BEFORE START

)

2 Pin Door Lock Harness

BLUE UNLOCK

(-)

GREEN LOCK

(-)

Pin Main Harness

GRAY/RED PARKING BRAKE INPUT ( - )

Locate the vehicle's parking brake wire.

Verification: This wire will register ground when the vehicle's PARKING

BRAKE is engaged.

NOTE: The following connection is required for Manual Transmission Mode.

2 PURPLE DOOR TRIGGER INPUT ( + )

Locate the vehicle's dome light

door pin switch wire.

Verification: This wire will register positive voltage (POS) when the

door

opened and the interior light is on. This wire will

"0" Volts when the door is closed and the interior light is

off.

Connect the PURPLE wire to the vehicle's positive door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide.

GREEN DOOR TRIGGER INPUT ( - )

Locate the vehicle's dome light or door pin switch wire.

Verification: This wire will register ground (NEG) when the door

opened

and the interior light

on. This wire will register positive voltage when the

door is closed and the interior light is off.

Connect the GREEN wire to the vehicle's negative door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide.

4 BLACK/WHITE ILLUMINATED ENTRY OUTPUT ( - )

This wire provides a ( - ) 200mA output for 30 seconds when the system is disarmed

capable

driving relays.

Locate the vehicle's dome light or pin switch wire.

Verification: This wire will register positive voltage or ground when the

vehicle's dome light

turned ON.

BROWN/BLACK HORN OUTPUT ( - )

Locate the vehicle's horn wire.

Verification: This wire will register at positive voltage and register

ground when the horn switch is pressed.

Connect the BROWN/BLACK wire to the vehicle's horn wire. This is a low current

output, 200mA.

6 RED/WHITE TRUNK RELEASE OUTPUT ( - )

Locate the vehicle's trunk release wire at the trunk release switch.

Verification: This wire will register either positive voltage or ground when

the trunk release is activated.

This is a low current output, 200mA and is configurable

option programming.

ca5154 Install rev A

7 BLUE/BLACK START STATUS

ACTIVE OUTPUT ( - )

This wire provides a ground output when the remote start function is activated and

remains

until4

seconds after the remote start is shutdown. Ifthis wire will be used

for multiple application's a 1 amp diode is required in-line with the stripe facing the

control module.

PURPLE/WHITE TACH INPUT

Locate the vehicle's ignition coil or fuel injector

the engine compartment.

Verification: Test using the following procedure:

Set voltmeter to AC VOLTS.

Attach positive lead

a volt meter to a constant 12-volt source.

Attach negative lead

a volt meter to the wire to be tested.

Start the engine.

Have someone press on the gas pedal slightly as you monitor the meter. If

connected to the correct wire, the voltage reading will increase as the engine's

RPM increases.

Connect the PURPLE/WHITE wire to the negative side

the vehicle ignition coil or

fuel injector.

9 GRAY HOOD PIN INPUT ( - )

Install a Hood Pin Switch and connect to the GRAY wire. This connection is required

for Remote Start.

Verification: This wire when connected will register ground when the

vehicle's hood is opened.

Connect the GRAY wire to the hood pin.

NOTE: Be sure to loom the wire, and seal the grommet.

10 BROWN/RED BRAKE INPUT ( + )

Locate the vehicle's brake light wire at the brake pedal mounted switch. This

connection is required for Remote Start.

Verification: This wire registers positive voltage when the brake pedal

pressed.

Connect the BROWN/RED wire to the vehicle's brake light wire.

VIOLET/BLACK AUX 1

This wire provides a ( - ) 200mA output capable

driving relays. For Control

optional accessories (i.e. Power Window/Sunroof, etc.).

activate refer to the transmitter button configuration chart. Please refer to the

selectable options for timing.

3 Pin Parking Light Harness

BLACK GROUND

Connect the BLACK wire to a solid chassis ground point using a ring terminal and

self tapping screw (not supplied). Scrape away paint from the grounding point to

ensure a good connection. The recommended grounding point is a metal surface

the driver's side kick panel

area:

NOTE: Do not ground the BLACK wire with any other vehicle components.

2 WHITE/RED PARKING LIGHT INPUT

3 WHITE PARKING LIGHT OUTPUT

Locate the parking light output wire at the vehicle's light switch.

Verification: This wire registers positive voltage when the parking lights are

turned on.

Positive switching Parking Lights:

Connect the WHITE/RED wire to a 15Amp max fused battery source.

Connect the WHITE wire to the parking light output wire.

Negative switching Parking Lights:

Connect the WHITE/RED wire to a good chassis ground.

Connect the WHITE wire to the parking light output wire.

ca5154 Install rev A

6 Pin Start Harness

1 PURPLE STARTER OUTPUT ( + )

Locate the vehicle starter wire.

Verification: This wire registers voltage onlywhen the key is turned to the

START position.

Verification: The starter wire registers voltage when the key is turned to the

START position.

Connect the PURPLE wire to the vehicle starter wire.

2 RED BATTERY 12V (

Locate 1

the vehicle's constant

Volt battery wires at the ignition switch.

Verification: This wire will register ( + ) voltage

all positions ofthe ignition

switch.

Connect the RED wire to the constant

Volt battery wire.

NOTE: Remove all fuses until all connections are made.

3 ORANGE ACCESSORY 1 ( + )

Locate the vehicle's accessory wire at the ignition switch.

Verification: This wire registers voltage when the key is turned to ACC

(Accessory) and the

(or RUN) position. The voltage drops out when the

key is turned to the START (or CRANK) position.

Connect the ORANGE wire to the vehicle's accessory wire.

Programmable output: IGN, ACC, Start.

4 PINK/WHITE IGNITION 2 ( + )

Locate the vehicle's 2nd ignition wire at the ignition switch (if equipped).

Verification: This wire registers voltage when the key is turned to the ON (or

RUN) position, but not the ACC (Accessory) position. The voltage does not

drop out when the key

turned to the START (or CRANK) position.

Connect the PINK/WHITE wire to the vehicle's ignition 2 wire.

Programmable output: IGN, ACC, Start.

5 RED/WHITE BATTERY 12V (

Locate 1

the vehicle's constant 12 Volt battery wires at the ignition switch.

Verification: This wire will register ( + ) voltage in all positions

the ignition

switch.

Connect the RED/WHITE wire to the constant 12 Volt battery wire.

NOTE: Remove all fuses until all connections are made.

6 PINK IGNITION 1 ( + )

Locate the vehicle's ignition wire at the ignition switch.

Verification: This wire registers voltage when the key is turned to the ON (or

RUN) position. The voltage does not drop out when the key is turned to the

START (or CRANK) position.

Connect the PINK wire to the vehicle's Ignition wire.

This wire is also used for Ignition 1 Output.

4 Pin Alternate Harness

1 BLACK/YELLOW PULSE DURING CRANK ( - )

Locate the vehicle's second starter (crank) wire at the ignition switch. (if equipped)

Verification: This wire registers voltage only

the start (crank) position

the ignition switch.

This wire will supply a ( - ) 200mA output and can be configured

option

programming.

2 GREEN/WHITE PULSE AFTER SHUTDOWN ( - )

This wire will supply a ( - ) 200mA pulse after the remote start shuts down. This

is typically used to re-lock the vehicle's doors if they unlock upon remote start

shutdown. It can also be used to pulse a door pin-switch wire to prevent the vehicle's

accessories from remaining

after remote start shutdown.

This output is configurable

option programming.

ca5154 Install rev A

Otros manuales para ca5154 professional Series

Tabla de contenidos

Otros manuales de Arranque remoto de Code Alarm

Code Alarm

Code Alarm ca5554 Professional series Manual de usuario

Code Alarm

Code Alarm F40 Manual de usuario

Code Alarm

Code Alarm ca6154 Professional Series Manual de usuario

Code Alarm

Code Alarm CA2LCD5 Manual de usuario

Code Alarm

Code Alarm CA 440SS Manual de usuario

Code Alarm

Code Alarm Professional ca5054 Manual de usuario

Code Alarm

Code Alarm PC 7600 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 4050 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 5050 Manual de usuario

Code Alarm

Code Alarm CA 5150 Manual de usuario

Code Alarm

Code Alarm CA-630 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 1050 Manual de usuario

Code Alarm

Code Alarm CA 5053 Manual de usuario

Code Alarm

Code Alarm F60 Manual de usuario

Code Alarm

Code Alarm CA-520A Manual de usuario

Code Alarm

Code Alarm RCS2 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 4050 Manual de usuario

Code Alarm

Code Alarm CA611 Manual de usuario

Code Alarm

Code Alarm Professional Series CA 5050 Manual de usuario

Code Alarm

Code Alarm CA 5051 Manual de usuario

Code Alarm

Code Alarm CA-520 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA 521 Manual de usuario

Code Alarm

Code Alarm ca4054 Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual

Rooboost

Rooboost RB-1750WP Manual de usuario

Code Alarm ca5154 professional Series Manual de usuario

Manuales populares de Arranque remoto de otras marcas
