Code Alarm Ca5153 Manual de usuario

12012AudiovoxElectronicsCorporation.Allrightsreserved.

PROFESSIONAL

SERIES

Automatic / Manual Transmission

Remote Start with Keyless Entry

Installation Guide

for models:

ca5153

ca5153sst

2ca5153/5153sstrevA

Before You Begin ......................................................................................3

Wire Connection Guide ...........................................................................4

11 Pin Main Harness .................................................................................5

3 Pin Parking Light Harness .....................................................................8

6 Pin Start Harness ...................................................................................9

4 Pin Alternate Harness..........................................................................10

2 Pin Door Lock Harness........................................................................ 11

Additional Ports ......................................................................................15

Antenna / LED / Programming Port .......................................................15

DBIPort....................................................................................................15

Telematic Interface Port..........................................................................15

Set Up & Programming..........................................................................16

Transmitter Programming........................................................................16

Manual Feature Programming.................................................................16

Programming Feature Banks ..................................................................17

Tach Programming ..................................................................................19

Smart Tachless Mode .............................................................................19

Feature Descriptions ............................................................................. 20

Transmitter Button Functions .............................................................26

Remote Start Shutdown Diagnostics ................................................27

System Layout.........................................................................................28

Table of Contents

32012AudiovoxElectronicsCorporation.Allrightsreserved.

PROFESSIONALINSTALLATION

STRONGLYRECOMMENDED

Installation Precautions:

Roll down window to avoid locking keys in vehicle

during installation

Avoid mounting components or routing wires near

hot surfaces

Avoid mounting components or routing wires near

moving parts

Tape or loom wires under hood for protection and

appearance

Technical Support (800) 421-3209

or go to

http://techservices.codesystems.com

Use a Digital Multi Meter for testing and verifying

circuits. DO NOT USE ATEST LIGHT, OR

"COMPUTER SAFE PROBE" as these can set off air

bags or damage vehicle computers.

Use grommets when routing wires through metal

surfaces

BEFORE YOU BEGIN

4ca5153/5153sstrevA

6 Pin Start Harness

11 Pin Main Harness

3 Pin Parking Light Harness

1PURPLE STARTER OUTPUT - MOTOR SIDE

2RED BATTERY 12V ( + )

3ORANGE ACCESSORY 1 ( + )

4PINK/WHITE IGNITION 2 ( + )

5RED/WHITE BATTERY 12V ( + )

6PINK IGNITION 1 ( + )

6 PIN START

1GRAY/RED PARKING BRAKE INPUT ( - )

2PURPLE DOOR INPUT ( + )

3GREEN DOOR INPUT ( - )

4BLACK/WHITE ILLUMINATED ENTRY OUTPUT ( - )

5BROWN/BLACK HORN OUTPUT ( - )

6RED/WHITE TRUNK RELEASE OUTPUT ( - )

7BLUE/BLACK START STATUS / ACTIVE OUTPUT ( - )

8PURPLE/WHITE TACH INPUT

9GRAY HOOD PIN INPUT ( - )

10 BROWN/RED BRAKE INPUT ( + )

11 VIOLET/BLACK AUX 1 OUTPUT ( - )

11 PIN MAIN

52012AudiovoxElectronicsCorporation.Allrightsreserved.

11 Pin Main Harness

4 Pin Alternate Harness

2 Pin Door Lock Harness

2 PURPLE DOORTRIGGERINPUT( +)

Locate the vehicle’s dome light or door pin switch wire.

Verification: This wire will register positive voltage (POS) when the door is

opened and the interior light is on. This wire will

off.

Connect the PURPLE wire to the vehicle’s positive door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide.

1 GRAY/RED PARKING BRAKE INPUT( -)

Locate the vehicle’s parking brake wire.

Verification: This wire will register ground when the vehicle’s PARKING

BRAKE is engaged.

NOTE: The following connection is required for Manual Transmission

Mode.

1BLACK/YELLOW PULSE DURING CRANK ( - )

2GREEN/WHITE PULSE AFTER SHUTDOWN ( - )

3LT BLUE FACTORY ARM / PULSE AFTER START ( - )

4LT GREEN/BLACK FACTORY DISARM / PULSE BEFORE START ( - )

4 PIN

ALTERNATE

OUTPUT

6ca5153/5153sstrevA

4 BLACK/WHITE ILLUMINATEDENTRYOUTPUT(-)

This wire provides a ( - ) 500mA output for 30 seconds when the system is

disarmed capable of driving relays.

Locate the vehicle’s dome light or pin switch wire.

Verification: This wire will register positive voltage or ground when the

vehicle's dome light is turned ON.

5 BROWN/BLACK HORNOUTPUT ( -)

Locate the vehicle’s horn wire.

Verification: This wire will register at positive voltage and register

ground when the horn switch is pressed.

Connect the BROWN/BLACK wire to the vehicle’s horn wire. This is a low current

output, 500mA.

6 RED/WHITE TRUNK RELEASEOUTPUT (- )

Locate the vehicle’s trunk release wire at the trunk release switch.

Verification: This wire will register either positive voltage or ground when

the trunk release is activated.

This is a low current output, 500mA and is configurable in option programming.

3 GREEN DOORTRIGGERINPUT (-)

Locate the vehicle’s dome light or door pin switch wire.

Verification: This wire will register ground (NEG) when the door is opened

and the interior light is on. This wire will register positive voltage when the

door is closed and the interior light is off.

Connect the GREEN wire to the vehicle’s negative door input wire(s).

NOTE: Certain vehicles may require multiple connections. Refer to vehicle

application guide.

72012AudiovoxElectronicsCorporation.Allrightsreserved.

7 BLUE/BLACK START STATUS /ACTIVE OUTPUT ( - )

This wire provides a ground output when the remote start function is activated

and remains until 4 seconds after the remote start is shutdown. If this wire will

be used for multiple application's a 1 amp diode is required in-line with the stripe

facing the control module.

9 GRAY HOODPIN INPUT(- )

Install a Hood Pin Switch and connect to the GRAY wire. This connection is

required for Remote Start.

Verification: This wire when connected will register ground when the

vehicle's hood is opened.

Connect the GRAY wire to the hood pin.

NOTE: Be sure to loom the wire, and seal the grommet.

10 BROWN/RED BRAKE INPUT ( + )

Locate the vehicle’s brake light wire at the brake pedal mounted switch. This

connection is required for Remote Start.

Verification: This wire registers positive voltage when the brake pedal is

pressed.

Connect the BROWN/RED wire to the vehicle’s brake light wire.

8 PURPLE/WHITE TACHINPUT

Locate the vehicle’s ignition coil or fuel injector in the engine compartment.

Verification: Test using the following procedure:

1. Set voltmeter to AC VOLTS.

2. Attach positive lead of a volt meter to a constant 12-volt source.

3. Attach negative lead of a volt meter to the wire to be tested.

4. Start the engine.

5. Have someone press on the gas pedal slightly as you monitor the meter. If

connected to the correct wire, the voltage reading will increase as the engine’s

RPM increases.

Connect the PURPLE/WHITE wire to the negative side of the vehicle ignition coil

or fuel injector.

8ca5153/5153sstrevA

1 BLACK GROUND

Connect the BLACK wire to a solid chassis ground point using a ring terminal and

self tapping screw (not supplied). Scrape away paint from the grounding point to

ensure a good connection. The recommended grounding point is a metal surface

in the driver’s side kick panel area.

NOTE: Do not ground the BLACK wire with any other vehicle components.

3 Pin Parking Light Harness

2 WHITE/RED PARKINGLIGHTINPUT

3 WHITE PARKINGLIGHTOUTPUT

Locate the parking light output wire at the vehicle’s light switch.

Verification: This wire registers positive voltage when the parking lights are

turned on.

Positive switching Parking Lights:

Connect the WHITE/RED wire to a 15 Amp max fused battery source.

Connect the WHITE wire to the parking light output wire.

Negative switching Parking Lights:

Connect the WHITE/RED wire to a good chassis ground.

Connect the WHITE wire to the parking light output wire.

11 VIOLET/BLACK AUX 1

This wire provides a ( - ) 500mA output capable of driving relays. For Control of

optional accessories (i.e. Power Window/Sunroof, etc.).

To activate refer to the transmitter button configuration chart. Please refer to the

selectable options for timing.

92012AudiovoxElectronicsCorporation.Allrightsreserved.

6 Pin Start Harness

1 PURPLE STARTER OUTPUT ( + )

Locate the vehicle starter wire.

Verification: This wire registers voltage only when the key is turned to the

START position.

Verification:

The starter wire registers voltage when the key is turned to the

START position.

Connect the PURPLE wire to the vehicle starter wire.

2 RED BATTERY 12V ( + )

Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch.

Verification: This wire will register ( + ) voltage in all positions of the ignition

switch.

Connect the RED wire to the constant 12 Volt battery wire.

NOTE: Remove all fuses until all connections are made.

3 ORANGE ACCESSORY 1 ( + )

Locate the vehicle’s accessory wire at the ignition switch.

Verification: This wire registers voltage when the key is turned to ACC

(Accessory) and the ON (or RUN) position. The voltage drops out when the

key is turned to the START(or CRANK) position.

Connect the ORANGE wire to the vehicle’s accessory wire.

4 PINK/WHITE IGNITION 2 ( + )

Locate the vehicle’s 2nd ignition wire at the ignition switch (if equipped).

Verification: This wire registers voltage when the key is turned to the ON (or

RUN) position, but not the ACC (Accessory) position. The voltage does not

drop out when the key is turned to the START(or CRANK) position.

Connect the PINK/WHITE wire to the vehicle’s ignition 2 wire.

Programmable output: IGN, ACC, Start.

10 ca5153/5153sstrevA

1 BLACK/YELLOW PULSEDURING CRANK (- )

Locate the vehicle’s second starter (crank) wire at the ignition switch. (if equipped)

Verification: This wire registers voltage only in the start (crank) position of

the ignition switch.

Connect the BLACK/YELLOW wire as shown in the diagram below. Use an SPDT

relay (not supplied).

This output is configurable in option programming.

2 GREEN/WHITE PULSE AFTER SHUTDOWN (- )

This wire will supply a ( - ) 500mA pulse after the remote start shuts down. This

is typically used to re-lock the vehicle’s doors if they unlock upon remote start

shutdown. It can also be used to pulse a door pin-switch wire to prevent the

vehicle’s accessories from remaining on after remote start shutdown.

This output is configurable in option programming.

6 PINK IGNITION1( + )

Locate the vehicle’s ignition wire at the ignition switch.

Verification: This wire registers voltage when the key is turned to the ON (or

RUN) position. The voltage does not drop out when the key is turned to the

START(or CRANK) position.

Connect the PINK wire to the vehicle’s Ignition wire.

This wire is also used for Ignition 1 Output.

5 RED/WHITE BATTERY 12V ( + )

Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch.

Verification: This wire will register ( + ) voltage in all positions of the ignition

switch.

Connect the RED/WHITE wire to the constant 12 Volt battery wire.

NOTE: Remove all fuses until all connections are made.

4 Pin Alternate Harness

Otros manuales para ca5153

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Arranque remoto de Code Alarm

Code Alarm

Code Alarm ca6554 Manual de usuario

Code Alarm

Code Alarm CA 1055 Manual de usuario

Code Alarm

Code Alarm SRT 6700 Manual de usuario

Code Alarm

Code Alarm CA-630 Manual de usuario

Code Alarm

Code Alarm CA 5051MT Manual de usuario

Code Alarm

Code Alarm Professional Series CA 4050 Manual de usuario

Code Alarm

Code Alarm CA-630 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm SRT 9000 Manual de usuario

Code Alarm

Code Alarm CA 4051 Manual de usuario

Code Alarm

Code Alarm ca5554 Professional series Manual de usuario

Code Alarm

Code Alarm Professional ca5054 Manual de usuario

Code Alarm

Code Alarm PC 4400 Manual de usuario

Code Alarm

Code Alarm CA 5150 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA 411 Manual de usuario

Code Alarm

Code Alarm ca6554 Manual de usuario

Code Alarm

Code Alarm ca6154 Professional Series Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA 4055 Manual de usuario

Code Alarm

Code Alarm Professional Series CA6555 Manual de usuario

Code Alarm

Code Alarm PROFESSIONAL SERIES Manual de usuario

Code Alarm

Code Alarm CA-630 Manual de usuario

Code Alarm

Code Alarm CA-500 Manual de usuario

Manuales populares de Arranque remoto de otras marcas

AstroStart

AstroStart 803U Manual de usuario

Durite

Durite 0-649-20 Manual

EINHELL

EINHELL BT-PS 1000 Manual

Linear

Linear ACCESS AK-21 Especificaciones técnicas

Soundstream

Soundstream TARANTULA RS.2 Manual de usuario

Jaycar Electronics

Jaycar Electronics MB3752 Manual de usuario

Ultra Start

Ultra Start 72 Series Manual de usuario

ADS

ADS FLASHLOGIC FLRSVW1 Manual de usuario

Selecta

Selecta JS012 Manual de usuario

Black Widow Security

Black Widow Security BW RAS 400 Manual de usuario

Vector

Vector Power City DK080706 Suplemento

Ozito

Ozito OJS-800 Manual de usuario

Profi-Partner

Profi-Partner 46387 Manual de usuario

EZ STARTER

EZ STARTER EZ-45 Manual de usuario

Viper

Viper 4204 Manual de usuario

Essex Electronics

Essex Electronics KE-1701 Manual de usuario

EINHELL

EINHELL EGS 3600 Manual

Rooboost

Rooboost RB-1750WP Manual de usuario

Code Alarm ca5153 Manual de usuario

Manuales populares de Arranque remoto de otras marcas
