Code Alarm CA1B5 Manual de usuario

1CA1B5 / AS9234E 4280844 Owners rev A.

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

PROFESSIONAL

SERIES

Owner’s Guide

For Model:

CA1B5

AS9234E

RF Upgrade Kit

Table of Contents

Using Your Remote Control .......................................................3

Transmitter Programming..........................................................6

Replacing Remote Control Batteries ........................................6

3CA1B5 / AS9234E 4280844 Owners rev A.

Remote Starting Your Vehicle

To activate the remote start, press and release the button 2 times within 2

seconds. The vehicle will start and run the predetermined time set up during

installation (5 to 60 minutes selectable).

Remote Start Shutdown

To cancel the remote vehicle start function, press and release the button 2 times

within 2 seconds.

Entering the Vehicle while it is Running via Remote Vehicle Start

1. Unlock the vehicle’s doors. (If equipped, press and release the button

2 times within 2 seconds while the vehicle is remote started)

2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!

3. Insert the key into the ignition switch and turn to the ON or RUN

position.

4. Press the brake pedal. The remote vehicle starter will disengage and

the vehicle will operate normally.

Preheating or Precooling the Vehicle’s interior

Before exiting the vehicle, set the temperature controls to the desired setting and

operation. After the system starts the vehicle, the heater or air conditioner will

activate and heat or cool the vehicle’s interior to your setting.

Using Your Remote Control

Unlocking the Vehicle (optional)

During the run cycle, enter the vehicle using your door key or, if the unlock option is

installed, once you are within range of the vehicle, press and hold the transmitter

button for 3 seconds to unlock the vehicle doors.

Using the “Quick-stop” Feature

With vehicle running, if you wish to make a quick stop and leave the vehicle running,

once you arrive at your destination:

a) place the gear selector in Park,

b) set the parking brake,

c) with your foot off the brake, press the transmitter button two times

in succession.

The vehicle will now be under control of the remote start system. Turn your

ignition switch off, WITHOUT, stepping on the brake, and exit the vehicle. Lock

the doors with the key to insure security.

Timed Start Program:

The Remote Start unit has the ability to start the vehicle automatically at timed

intervals. This feature is useful in extremely cold climates where starting the engine

is the only means to keep the battery charged and uids warm. The operator has the

option to have the unit start every 2 or 4 hours for a maximum of 48 hours. Factory

preset is to start at 4 hour intervals. To select 2 or 4 hour automatic start timer:

1. Start By Holding the Push Button Switch found on the windshield mount

receiver on.

2. While Holding the Push Button Switch Turn The Ignition Switch On Then

Off

3a) Within 10 seconds of turning the ignition switch off, Release and then

Push On and release the Push Button Switch 2 times holding it on the

second time until the siren and or lights ash and chirp 2 times indicating

that the 2 Hour Start Interval has successfully been set.

- OR -

3b) Within 10 seconds of turning the ignition switch off, (Step 2) Release

and then Push On and release the Push Button Switch 4 times holding

it on the fourth time until the siren and or lights ash and chirp 4 times

indicating that the 4 Hour Start Interval has successfully been set.

NOTE: Once selected, 2 or 4, this timer interval will remain in memory until it is

manually changed. To change, the above sequence will have to be followed.

5CA1B5 / AS9234E 4280844 Owners rev A.

Timed Start Operation:

To begin the start timer, within 10 seconds of turning off the ignition switch, activate

the RF command to start 2 times. (Press the start button four times). The lights

will ash and the siren will chirp 4 times. Indicating timed interval mode has been

initiated. The vehicle will automatically start every 2 or 4 hours as programmed. To

cancel the timed start mode start the vehicle either by RF or by the ignition key.

Remote Start Override Mode (Valet Mode) - AS9234E

The intent of the remote start override / manual shut down circuit is to allow the

vehicle operator to prevent operation of the Remote Start Unit regardless of the RF

transmitter operation.

Enter Remote Start Override:

1. With the system disarmed/unlocked, and the ignition switch off Press and

Hold the PBLED push button switch (dash mounted).

2. Turn the ignition switch on, off, on, off, on, off.

3. The LED begins to ash two short ashes followed by one long ashes

and continues this pattern until returned to normal mode of operation.

The action above puts the unit into the Remote Start Override mode or vehicle service

mode and will not start from the RF transmitter or any other input.

Exit Remote Start Override:

1. With the system disarmed, Press and Hold the PBLED push button

switch (dash mounted) on.

2. Turn the ignition switch on, off, on, off, on, off.

3. The LED turns off indicating that the R/S unit is fully functional one again.

1 Way Remote Control, CAT1:

The battery (model CR2032) inside each remote control should last approximately 1

year under normal use. When the battery becomes weak you will notice the remote

control range (the distance from the vehicle the remote control will work) deteriorate

and the small LED on the remote control will dim. To replace the battery in the remote

control:

1. Unsnap and disassemble the halves of the remote control.

2. Remove the old battery, observing the +/- symbols on the battery

and replace with new CR2032 battery.

3. Reassemble the halves of the remote control.

4. Test operation of the remote control.

Replacing Remote Control Batteries

Transmitter Programming

1. Turn the ignition ON.

2. Press and hold the valet/override button located on the antenna.

3. Within 10 seconds the LED’s will begin to ash.

4. Press 1 button of each transmitter you wish to program, the LED’s will

ash to conrm each transmitter.

5. Turn the ignition OFF

NOTE: This system has 1 button programming which programs all channels of the

system.

NOTE: The system will hold up to 4 transmitters in memory, programming a 5th

transmitter will erase the oldest transmitter in memory.

7CA1B5 / AS9234E 4280844 Owners rev A.

Voxx Electronics Corporation.

Customer Service 1-800-421-3209

WWW.CODE-ALARM.COM

FCC COMPLIANCE

This device complies with Part 15 of the FCC rules and with RSS-210 of

Industry Canada. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including any interference that

may cause undesired operation.

Warning!

Changes or modications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.
